Classic™ Freestanding Woodstove
Owners &
Installation Manual
F2450
French Manual Download: https://bit.ly/3rAsDW7
www.regency-fire.com
Manuel en Français : https://bit.ly/3rAsDW7
MODEL:
F2450CSA
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
0219WS026S
920-799
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
08.06.24
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Fireplace Products Classic F2450
Summary of Contents for Regency Fireplace Products Classic F2450
- Page 1 Classic™ Freestanding Woodstove Owners & Installation Manual F2450 French Manual Download: https://bit.ly/3rAsDW7 www.regency-fire.com Manuel en Français : https://bit.ly/3rAsDW7 MODEL: F2450CSA Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 0219WS026S 920-799 FPI FIREPLACE PRODUCTS INTERNATIONAL LTD.
- Page 2 Thank-you for purchasing a REGENCY FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area. "This wood heater has a manufacturer set minimum low burn rate that must not be altered.
-
Page 3: Table Of Contents
table of contents Operation Safety Decal for F2450 ..........4 Seasoned Firewood ..........23 Dimensions Operating Instructions ..........23 Draft Control ............23 Unit Dimensions ............5 Optimum Fueling & Operating Procedures ....24 Outside Air Dimensions ..........5 Fan Operation ............25 Ash Disposal ............25 Installation Ash Drawer Operating Guidelines ......25 Safety Guidelines and Warnings........25... -
Page 4: Safety Decal For F2450
safety decal This is a copy of the label that accompanies NOTE: Regency units are constantly being each Regency Freestanding Woodstove (F2450). improved. Check the label on the unit and if there is a difference, the label on the unit is We have printed a copy of the contents here for your review. -
Page 5: Dimensions
dimensions Unit Dimensions " 690mm " 630mm Images for OUTSIDE AIR DIMENSIONS 24" " 610mm 163mm 23-1/8" [587mm] (from fuel door opening) Images for OUTSIDE AIR DIMENSIONS 21-1/4" 4-9/16" (115mm) 21-1/2" [540mm] [546mm] Rear Outside Air Dimensions Front 6-13/16"(173mm) 4-9/16" (115mm) Rear Rear F2450 Regency Freestanding Woodstove... -
Page 6: Installation
installation General Guidelines Too tall a chimney may prompt excessive draft 13. A chimney connector cannot pass through an which can result in very short burn times and attic or roof space, closet or similar concealed 1. Please read this entire manual before you install space, or a floor, ceiling, wall or partition of excessive heat output. -
Page 7: Stove Assembly Prior To Installation
installation Rear Heat Deflector Stove Assembly Airmate Assembly for F2450 Prior to Installation Assembly for F2450 1. The Airmate sits on top of the stove with the The F2450 unit requires the pedestal (or heat shield The rear heat deflector is supplied with the stove slots in the sides fitting over the curved deflector and legs) to be attached to the base. -
Page 8: Pedestal Assembly Installation
installation Bottom Heat Shield and Legs Installation Pedestal Assembly Installation 1. For easier assembly, tip the stove on its back (onto a soft The instructions below apply to the painted cast leg. It will be surface to prevent scratching) and remove the front cover. easier to attach the legs to the stove if the stove is tipped on its back (preferably on a soft surface to prevent scratching). -
Page 9: Room Air - Important
installation On pedestal units there are two locations where Note: Once the knockout is removed Room Air - Important outside air may be adapted to the unit. If using there are two tabs remaining. For installation using room air for combustion, the bottom of the pedestal, do not remove remove knockout from the pedestal, and/or from Bend both tabs out for ease... -
Page 10: Minimum Alcove Clearance And Clearance To Combustible Materials
installation Minimum Alcove Clearance and Clearance to Combustible Materials The Regency Freestanding models have been alcove approved and must be installed with a listed double wall connector to the ceiling level. Note: Minimum alcove ceiling height - 83" (Measured from base of appliance) Maximum depth of alcove - 48"... -
Page 11: Floor Protection (Corner Installation)
installation Floor Protection (Corner Installation) A combustible floor must be protected by non-combustible material (like tile, concrete board, or certified to UL-1618 or as defined by local codes) extending beneath the heater and a minimum of 8" (203mm) from each side and minimum 18" (457 mm) from the front face of the stove and minimum 8"... -
Page 12: Step-By-Step Chimney And Connector Installation
installation This stove may be connected to a lined masonry Step-By-Step Chimney And 7. To complete your chimney installation, install chimney or a listed factory built chimney suitable the double wall connector pipe from the stove’s Connector Installation flue collar to the chimney support device. for use with solid fuels and conforming to ULC629 in Canada. -
Page 13: Masonry Chimney
installation Masonry Chimney Ensure that a masonry chimney meets the minimum standards by having it inspected by a WETT certified professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated. -
Page 14: Combustible Wall Chimney Connector Pass-Throughs
installation Combustible Wall Chimney Connector Pass-throughs Minimum chimney clearance to brick Method A: 12" (304.8 mm) Clearance to Combustible Wall Member: and combustibles 2 in. (50.8mm) Using a minimum thickness 3.5" (89 mm) brick and a 5/8" (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The Minimum clearance clay liner must conform to ASTM C315 (Standard Specification for 12 in. -
Page 15: Transportable Buildings Canada
installation Transportable Buildings Canada In addition to standard installation instructions the following requirements are mandatory for installation For installations, see Outside Air Kit - Part # in a transportable building. 846-502. 1. The stove must be permanently bolted to the floor of the transportable building using There are further requirements when installing the floor screws provided. -
Page 16: Recommended Heights For Woodstove Flue
installation TABLE 1 MINIMUM RECOMMENDED FLUE HEIGHTS IN FEET (Measured from the top of the unit) # OF ELBOWS ELEVATION (FT) ABOVE SEA LEVEL 2 x 15 4 x 15 2 x 30 4 x 30 2 x 45 4 x 45 0-1000 12.0 13.0... -
Page 17: Optional Outside Air Kit
installation Optional Outside Air Kit The Outside Air Kit is an option for Freestanding Stoves. Outside air for combustion can be brought in either through the bottom of the pedestal or through the rear plate of the pedestal. For both bottom and rear outside air the Pedestal Cover Plate must be installed. Loosen the 4 screws on the rear of the pedestal and slide the cover plate over them. -
Page 18: Brick Installation
installation Brick Installation Firebrick is included to extend the life of your stove and radiate heat more evenly. Check to see that all firebricks are in their correct positions and have not become misaligned during shipping. Install all firebricks (if bricks were removed at install) per the diagram below and place in their correct positions. Do not use a grate. -
Page 19: Wood Handle & Door Assembly
installation Wood Handle & Door Assembly Place the door onto the hinges and then place the door handle through the opening on the door, as shown in In preparation of installing the door handle, the nuts, Diagram 2. cam, washers and spacer must be removed as shown in Diagram 1. -
Page 20: Flue Baffle & Secondary Air Tube Installation
installation Flue Baffle & 3. Tilt the left baffle up on top of the side channel and it will leave enough Secondary Air Tube room to position the right baffle in the same manner as Step 1 above. Installation Then reposition the left baffle flat on the air tubes. The flue baffle system located in the upper area of the firebox is removable to make cleaning your chimney system easier. -
Page 21: Fan Installation
installation Fan Installation AUTOMATIC 1. Remove the two screws from the top of the fan housing. To operate the fan automatically, push the bottom switch on the side of the fan housing to "AUTO" and the top switch to either "HIGH" or 2. -
Page 22: Stainless Stell Smoke Deflector Installation
installation Stainless Steel Smoke Deflector Installation The stainless smoke deflector is located in the upper front area of the firebox. The deflector is held in place with 2 bolts. Prior to the first fire, ensure deflector is seated properly and secured with 2 hand tightened bolts. Smoke deflector installed with 2 bolts. -
Page 23: Seasoned Firewood
operating instructions Operating Seasoned Firewood Instructions Whether you burn wood in a fireplace, stove or insert, With your unit now correctly installed and safety good quality firewood is the key to convenience, inspected by your local authority, you are now efficiency and safety. -
Page 24: Optimum Fueling & Operating Procedures
operating instructions 12. Green or wet wood is not recommended for Optimum Fueling & Operating 7. Once a nice coal bed is established and there are still good sized flames, the main load of your unit. If you must add wet or green fuel, Procedures larger logs can be loaded into the firebox. -
Page 25: Fan Operation
operating instructions Fan Operation Ash Drawer Operating Safety Guidelines Guidelines and Warnings Automatic To operate the fan - turn on the rheostat. 1. Only clean ashes out of the stove when the CAUTION: Do not use chemicals or unit has cooled down. Remove the plug by fluids to start fire. -
Page 26: Maintenance
maintenance Classic Door WARNING: Do not operate without either the Ash Plug properly seated Handle Replacement or the Ash Dump Plates screwed in place, excessive temperatures will 1. To remove the wooden door handle from unit—locate the 7/64" Allen key result. -
Page 27: Maintenance
maintenance Maintenance Ways to Prevent and Keep Unit WARNING: Do not clean the glass when it is hot. Free of Creosote WARNING: Do not use abrasive cleaners, a damp It is very important to carefully maintain your cloth and glass cleaner is effective. fireplace stove, including burning seasoned wood WARNING: Do not use substitute materials. -
Page 28: Secondary Air Tube Removal/Installation
maintenance 3. Grasp front secondary air tube firmly with vise grips, using a hammer tap Secondary Air Tube Removal/Installation vise grips from right to left until air tube is released from grip. Remove. See diagram 1. Repeat step to remove second airtube from front. 1. -
Page 29: Vertical Stainless Deflector Replacement
maintenance Vertical Stainless Deflector Replacement 7/16'' Nuts 7/16'' Bolts Slide left + down to remove. Reverse to replace. Vertical Deflector Remove 2 front air tubes 1. Remove 2 front secondary air tubes / vermiculite baffles as per page 22. 2. Loosen the two 7/16'' bolts + nuts to remove / replace vertical deflector. 3. -
Page 30: Parts List
parts list Main Assembly Part # Description Left Side Heat Shield 021-006 Right Side Heat Shield 021-007 SS Smoke Deflector 021-018 021-020 Draft Control Lever Rear Air Deflector 815-557 Baffle Bricks Complete (Set Of 2) 020-957 3/4 OD x 19-1/4 Air tube 4 Per Unit (Each) 033-953 7/8"... - Page 31 parts list F2450 Regency Freestanding Woodstove...
-
Page 32: Bases
parts list Bases Part # Description 021-911 Bottom heat Shield Black Cast legs (Set Of 4) 850-126 Nickel Cast legs (Set Of 4) 850-128 Ashdrawer Bottom Heat Shield 075-914 942-110 Ashplug 820-249 Ashplug Tool Blanking Plate 021-024 5/16" x 5 1/2 " Long Hex Head Bolt (Each) 904-100 820-468F Metal Washer... -
Page 33: Brick Kit
parts list 020-960 Brick Kit Complete Brick - Regular Full Size: 1-1/4" x 4-1/2" x 9" Brick Partial: 1-1/4" x 2" x 4-1/2" Brick Partial: 1-1/4" x 4-1/2" x 3-1/2" Brick Partial: 1-1/4" x 2" x 9" NOTE: This kit contains one spare brick in case of breakage. F2450 Regency Freestanding Woodstove... -
Page 34: Warranty
warranty Indoor Wood Product Warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U S, Inc. (for US customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this Appliance provided the product remains in the original place of installation. - Page 35 warranty The authorized selling dealer, or an alternative authorized FPI dealer if pre-approved by FPI, is responsible for all in- field diagnosis and service work related to all warranty claims. FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. At all times, FPI reserves the right to inspect reported in the field/on location complaints of products claimed to be defective before processing or authorizing any claim.
- Page 36 warranty FPI has no obligation to enhance or modify any Appliance once manufactured (i.e. as products evolve, field modifications or upgrades will not be performed on existing Appliances). Any Appliance showing signs of neglect or misuse will not be covered under the terms of this warranty policy and may void this warranty, including Appliances with rusted or corroded fireboxes that have not been reported as rusted or corroded within three (3) months of installation/purchase.
-
Page 37: Warranty Registration Card
warranty Warranty Registration Card Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase. -
Page 38: Recycling
recycling PRODUCT LIFE CYCLE: By recycling your used appliances, you divert waste from your local landfills and help the environment. You also reduce the need for raw materials to manufacture new products. Contact your local municipality for appliance recycling services, local recycling programs, or appliance removal services to ensure your Regency appliance components, and packaging are properly recycled. - Page 39 dimensions F2450 Regency Freestanding Woodstove...
- Page 40 Installer: Please complete the following information Dealer Name & Address: _____________________________ _________________________________________________ Installer: _________________________________________ Phone #: _________________________________________ Date Installed: _____________________________________ Serial #: __________________________________________ Regency is a trademark of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2024, FPI Fireplace Products International Ltd. All rights reserved.
