F2450-2 Classic™ Freestanding Woodstove
Model
Cordwood BTU's
Emissions (grams/hr) EPA Certified
Efficiency (EPA HHV)*
Efficiency (EPA LHV)
Flue Size
US Biomass Tax Rebate Eligible
Maximum Log Size
Firebox Size
*US Biomass Tax Rebate eligibility is based on the HHV value being
greater than or equal to 75%.
UNIT DIMENSIONS WITH BOTTOM HEAT SHIELD
& CAST LEGS
UNIT DIMENSIONS WITH PEDESTAL
Images for OUTSIDE AIR DIMENSIONS
OUTSIDE AIR DIMENSIONS
Rear
With Pedestal
Front
F2450-2
75,000 BTU's
1.6 grams/hr
70.3%
76%
6" (152mm)
No
18" (457 mm)
2.3 cu.ft.
6"
152mm
1
25
"
4
641mm
25"
635mm
23"
584mm
4-9/16" (115mm)
Images for OUTSIDE AIR DIMENSIONS
5
22
"
8
575mm
1
27
"
8
689mm
13
24
"
16
630mm
7
6
"
16
163mm
4-9/16" (115mm)
Rear
7
21
"
8
556mm
Front
6-13/16"(173mm)
Rear
With Bottom Heat Shield & Legs
F2450 Wood Stove |
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Classic F2450-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Regency Fireplace Products Classic F2450-2

  • Page 1 F2450-2 Classic™ Freestanding Woodstove Model F2450-2 Cordwood BTU’s 75,000 BTU’s Emissions (grams/hr) EPA Certified 1.6 grams/hr Efficiency (EPA HHV)* 70.3% Efficiency (EPA LHV) Flue Size 6" (152mm) US Biomass Tax Rebate Eligible Maximum Log Size 18” (457 mm) Firebox Size 2.3 cu.ft.
  • Page 2 MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALS Please read the section below carefully as clearances depend on whether the airmate or the rear heat deflector is installed on the stove. Measurements "From Unit" are from the side heat shields of the stove to a side wall or to a corner, and from the rear heat shield to a back wall.
  • Page 3 FLOOR PROTECTION (EMBER PROTECTION ONLY REQUIRED) A combustible floor must be protected by a non-combustible material (like tile, concrete board, or certified to UL-1618 Type 1, or as defined by local codes). Type 1 Hearth Pads typically provide protection from embers only, but won't provide thermal protection from the heat of the appliance. Canada: Beneath the heater and extending to at least 18"...
  • Page 4 FLOOR PROTECTION (CORNER INSTALLATION) A combustible floor must be protected by non-combustible material (like tile, concrete board, or certified to UL-1618 or as defined by local codes) extending beneath the heater and a minimum of 8" (203 mm) from each side and minimum 16" (406 mm) from the front face of the stove and minimum 8"...
  • Page 5 STEP-BY-STEP CHIMNEY This stove may be connected to a lined masonry chimney or a listed factory built chimney suitable 8. If you are using a horizontal connector, for use with solid fuels and conforming to ULC629 the chimney connector should be as high CONNECTOR INSTALLATION in Canada or UL-103HT in the USA.
  • Page 6 MOBILE HOME INSTALLATION (USA ONLY) In addition to standard installation instructions the following requirements are mandatory for For USA Installations : see Outside Air Kit installation in a mobile home. - Part # 846-502. 1. The stove must be permanently bolted to the floor of the Mobile Home using the Once you have properly marked the position of floor screws provided.
  • Page 7 MASONRY CHIMNEY Ensure that a masonry chimney meets the minimum standards of the National Fire Protection Association (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated.
  • Page 8 COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS Minimum chimney clearance to brick Method A: 12" (304.8 mm) Clearance to Combustible Wall Member: and combustibles 2 in. (50.8mm) Using a minimum thickness 3.5" (89 mm) brick and a 5/8" (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The Minimum clearance clay liner must conform to ASTM C315 (Standard Specification for 12 in.
  • Page 9 TABLE 1 MINIMUM RECOMMENDED FLUE HEIGHTS IN FEET (Measured from the top of the unit) # OF ELBOWS ELEVATION (FT) ABOVE SEA LEVEL 2 x 15 4 x 15 2 x 30 4 x 30 2 x 45 4 x 45 0-1000 12.0 13.0...
