Page 1
User guide SonoSelect and SonoSafe Energy Meters www.heating.danfoss.com...
Page 2
User guide SonoSelect and SonoSafe Note: To ensure latest version of declaration, please visit danfoss.com. 2 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 3: Table Of Contents
Local Importer name and address ............18 BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 3...
Page 4: General
• At media temperatures above 95°C (SonoSelect heating) the calculator must be mounted separately from the flow sensor to secure electronics lifetime • Avoid installation stress from pipes and fittings. • Flush the system. • No outside installation and no flooding allowed. 4 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 5: Identification Of Installation: Supply/Return Pipe Installation
Rotation in pipe axis: Flow sensor should be angled in 45 can be collected. to 315° to avoid air collection in flow sensor. 2.4 Mounting orientation, calculator 4 x 90° BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 5...
Page 6: Mounting Of O-Ring And Temperature Sensor
30.5 mm G1¼ 39mm Note: • Tolerance on machined dimensions = ± 0.5 mm. • Pipe fittings for use with probe type DS (Direct Short). : Provision for security sealing. 6 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 7: Bifunctional Meters
M-Bus supply Baud rate supported 300, 2400, 4800, 9600 Communication protocol According to EN1434-3 & EN13757-3 Battery life time 16+1 year Serial number: sssssvvNNyyWW Addressing ss: Primary address, yWWsssss: Secondary address BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 7...
Page 8: Pulse Input Module
≤ 5 Hz Pulse inputs According to EN1434-2, section 7.1.5 (Classification of pulse input devices Class IB)* Battery life time 16+1 year * Suitable for both electronic switch and Reed contact. 8 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 9: Pulse Output Module
• Month log 1 (last month log) • Difference temperature • ReturnTemperature • Enclosure temperature • CurrentTime • Current time • Hour counter factory • Hour counter OK * Can be changed via SonoApp BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 9...
Page 10
Mains power meters are delivered with M12x1.5 cable gland suitable for outside cable Mains power cable diameter Ø3-Ø6.5mm 2x0.75 mm . In case stranded wire is used Ferrules are required. Pre fuse of max 6A must be used 10 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 11: Installation Of Module/Cable
SonoApp user guide. terminals matching colour and terminal numbers. Fix cable(s) to cable relief. Outer jacket no longer than 9 mm from cable relief (line). Press down. BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 11...
Page 12: Battery
(and reset tamper alarm E13). If no Sonoapp is available a long press of 5 seconds when display shown “use app” will also confirm the battery change. Note that date and time will not be updated. 12 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 13: Mains Supply
5. Insert cable through cable gland hole to secure 6. Connect cable and fix it to screw terminals. IP class and strain relief. In case stranded wire is Tighten the cable gland. used Ferrules are required. BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 13...
Page 14
1) Use SonoApp to set up. Confirm mains supply parts. Power up the meter. and set date & time. 2) Hold button for 5 seconds to continue without setting date & time. 14 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 15: Commissioning
Factory seal 3.4 IP class Calculator IP65 Flow sensor IP68 (SonoSelect) / IP65 (SonoSafe) Temperature sensor IP65 Note: The IP class can be compromised if cables are subjected to angled tension. BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 15...
Page 16: Function Overview
Bifunctional heat/cool: energy heat, volume heat, energy cool, volume cool Current Supply temp. Return temp. Display test/All on Power Flow click LOOP 2 History log Accounting date Monthly date 1 >> Monthly date 12 click LOOP 3 16 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 17: Display Explanation
High flow > qss Supply Temperature Error Battery consumption too high Return Temperature Error Display overflow (energy/volume) Bifunctional meter dead band error Absolute/Difference temperature outside accumulated range Communication module error Low transducer signal BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 17...
Page 18: Device Overview
Other plastic parts PC, PPS, PEI, TPE Plastic recovery 7. Local Importer name and address For goods delivered to UK, importer name and address is: Danfoss Ltd. 22 Wycombe End HP9 1NB 18 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
Page 19
User guide SonoSelect and SonoSafe BC189986476699en-011005 © Danfoss | Energy Meters | 2022.04 | 19...
Page 20
20 | © Danfoss | Energy Meters | 2022.04 BC189986476699en-011005...
