Scan for full manual
Step 1: Check what's in the box
EXT3-H-POE-T Transmitter/ EXT3-H-POE-R
Receiver
1 Power adapter and cord
Step 2: Get to know your EXT3-H-POE-T
#
Feature
1
IN LED
2
OUT LED
3
LINK LED
4
PoE► LED
5
ON LED
6
HDBT OUT PoE◄► RJ-45 Connector Connect to an HDBT receiver (for example, EXT3-H-POE-R). The port can provide or
7
HDMI IN Connector
8
RS-232 (G, Rx, Tx) 3-pin Terminal
Block Connector
9
IR 3.5mm Mini Jack Connector
10
SETUP DIP-switches
11
48V DC
EXT3-H-POE-T / EXT3-H-POE-R Quick
Start Guide Quick Start
EXT3-H-POE-T / EXT3-H-POE-R Quick Start
Guide
This guide helps you install and use your EXT3-H-POE-T / EXT3-H-POE-R for the first time.
Go to
http://www.kramerav.com/downloads/EXT3-H-POE-T
H-POE-T
to download the latest user manual and check if firmware upgrades are available.
IN
OUT
LINK
PoE
ON
EXT3-H-POE-T
EXT3-H-R
EXT3-H-R
Function
Lights blue when an active source device input signal is detected.
Lights blue when an active, far-end sink (acceptor) connection is detected via the
HDBT link.
Lights green when an HDBT link is established with the HDBaseT receiver.
Lights green when the device provides PoE to a connected HDBT receiver.
Lights green when the device receives power.
receive PoE.
Connect to an HDMI source.
This port has two functions selectable by the SETUP DIP-switches:
1. To send/receive RS-232 data over the HDBaseT link.
2. For FW Upgrade.
Connect to an external infrared emitter / sensor.
The IR signal is passed over the HDBaseT link.
Set the operation DIP-switches. Refer to
48V DC connector for powering the unit (when not powered by PoE from the receiver).
/
http://www.kramerav.com/downloads/EXT3-
1 Bracket set
4 Rubber feet
HDBT IN
HDBT IN
HDBT IN
HDMI OUT
HDMI OUT
HDMI OUT
P/N:
2900- 301829QS
1 Quick start guide
RS-232
RS-232
RS-232
IR
IR
IR
SETUP
SETUP
SETUP
1 2
O
N
G Rx
G Rx
G Rx
Tx
Tx
Tx
DIP-Switch Settings
on page
Rev:
12V DC
12V DC
12V DC
3.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kramer EXT3-H-POE-T
Summary of Contents for Kramer EXT3-H-POE-T
- Page 1 EXT3-H-POE-T / EXT3-H-POE-R Quick Start Guide This guide helps you install and use your EXT3-H-POE-T / EXT3-H-POE-R for the first time. Go to http://www.kramerav.com/downloads/EXT3-H-POE-T http://www.kramerav.com/downloads/EXT3- Scan for full manual H-POE-T to download the latest user manual and check if firmware upgrades are available.
- Page 2 Lights green when the device provides PoE to a connected HDBT transmitter. ON LED Lights green when the device receives power. HDBT IN PoE◄► RJ-45 Connector Connect to the HDBT receiver (for example, EXT3-H-POE-T). The port can provide or receiver PoE. HDMI OUT Connector Connect to an HDMI acceptor.
- Page 3 Step 5: Connect inputs and outputs Always switch OFF the power on each device before connecting it to your EXT3-H-POE-T / EXT3-H-POE-R. For best results, we recommend that you always use the Kramer high-performance cables to connect AV equipment to EXT3-H-POE-T / EXT3-H-POE-R.
- Page 4 Step 7: Connect power Connect the 48V DC power adapters to EXT3-H-POE-T and EXT3-H-POE-R and plug into the mains electricity. Alternatively, power one of the units via the 48V DC power adapter and power the paired unit with PoE via the HDBT port.
