- Page 1 USER MANUAL MODEL: EXT3-H-T Transmitter / EXT3-H-R Receiver P/N: 2900-301821 Rev 1 www.kramerav.com...
-
Page 2: Table Of Contents
Kramer Electronics Ltd. Contents Introduction Getting Started Overview Typical Applications Defining EXT3-H-T / EXT3-H-R Defining EXT3-H-T Defining EXT3-H-R Mounting EXT3-H-T/R Connecting the EXT3-H-T/R Connecting to EXT3-H-T/R via RS-232 Wiring RJ - 45 Connectors Controlling EXT3-H-T/R Technical Specifications EXT3-H-T/R – Contents... -
Page 3: Introduction
Kramer Electronics Ltd. Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we... -
Page 4: Recycling Kramer Products
EXT3-H-T is a high−performance, HDBaseT 3.0 transmitter for 4K60 4:4:4 HDR HDMI, RS−232 and IR signals over twisted pair. EXT3-H-T converts the HDMI signal and outputs it to its HDBaseT and control ports. It enables extending video signals to up to 40m (130ft) over Kramer copper CAT cables at up to 4K@60Hz (4:4:4) video resolutions. -
Page 5: Typical Applications
4K@60Hz (4:4:4) AV extension in conference rooms, boardrooms, control rooms, hotels and large church facilities End units for systems deploying Kramer’s matrices and switchers with integrated HDBaseT 3.0 ports EXT3-H-T/R – Introduction... -
Page 6: Defining Ext3-H-T / Ext3-H-R
Connect to an external infrared emitter / sensor. The IR signal is IR 3.5mm Mini Jack Connector sent over the HDBaseT link. Set the operation DIP-switches. Refer to Controlling EXT3-H-T/R SETUP DIP-switches page 9. 12V DC Power Connector 12V DC connector for powering the unit. EXT3-H-T/R – Defining EXT3-H-T / EXT3-H-R... -
Page 7: Defining Ext3-H-R
ON LED Lights green when the device receives power. HDBT IN RJ-45 Connector Connect to a transmitter (for example, EXT3-H-T). HDMI OUT Connector Connect to an HDMI acceptor. This port has two functions selectable by the SETUP DIP-switches: RS-232 (G, Rx, Tx) 3-pin Terminal Block 1. -
Page 8: Mounting Ext3-H-T/R
Kramer Electronics Ltd. Mounting EXT3-H-T/R This section provides instructions for mounting EXT3-H-T/R. Before installing, verify that the environment is within the recommended range: • Operation temperature – 0° to 40°C (32 to 104°F). • Storage temperature – -40° to +70°C (-40 to +158°F). -
Page 9: Connecting The Ext3-H-T/R
EXT3-H-T/R To connect EXT3-H-T/R as illustrated in the example in Figure 1. On EXT3-H-T connect an HDMI source (for example, a Blu-ray player) to the HDMI IN connector 2. On EXT3-H-R connect the HDMI OUT connector to an HDMI acceptor (for example, a display). -
Page 10: Connecting To Ext3-H-T/R Via Rs-232
You can extend an RS-232 signal by connecting RS-232 equipment on both sides of the HDBaseT 3.0 link Connect the RS-232 terminal block on the rear panel of EXT3-H-T/R to a PC/controller, as follows: From the RS-232 9-pin D-sub serial port connect:... -
Page 11: Controlling Ext3-H-T/R
All the DIP-switches are set to OFF (up) by default. DIP-switch Settings Feature Off (up) – IR pass-through ON (down) – Add 38kHz modulation RS-232 Off (up) – RS-232 pass-through ON (down) – Valens programming EXT3-H-T/R – Connecting the EXT3-H-T/R... -
Page 12: Technical Specifications
We recommend that you use Kramer shielded cables to achieve optimum extension ranges Extension (see www.kramerav.com/product/EXT3-H-T / Up to 40m (130ft) at 4K@60Hz (4:4:4), when using Kramer HDBaseT cables Up to 70m (230ft) at up to 4K@30Hz (4:4:4), when using Kramer HDBaseT cables Compliance HDBaseT 3.0 Extended Baud Rate... - Page 13 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our website where updates to this user manual may be found. We welcome your questions, comments, and feedback.
