- Page 1 O p e r a t i o n s Me d i c a l Ma n u a l E y eS u r g e r yS t r e t c h e r Mo d e l 1 0 7 9 I mp o r t a n t I n f o r ma t i o n F i l e i n y o u r...
-
Page 2: Table Of Contents
Table of Contents Introduction Specifications ................Warning / Caution / Note Definition . -
Page 3: Introduction
Introduction INTRODUCTION This manual is designed to assist you with the operation of the Model 1079 Eye Surgery Stretcher. Read it thoroughly before using the equipment or beginning any maintenance on it. SPECIFICATIONS Maximum Weight Capacity 500 pounds Overall Bed Length/Width 90”... -
Page 4: Summary Of Safety Precautions
Summary of Safety Precautions Before operating this stretcher, it is important to read and understand all information in this manual. Carefully read and strictly follow the warnings and cautions listed on this page. WARNING Always apply the caster brakes when a patient is getting on or off the stretcher. Push on the stretcher to en- sure the brakes are securely locked. -
Page 5: Operating Base Controls
Stretcher Operation OPERATING BASE CONTROLS − SIDE CONTROL FOOT END HEAD END Pump pedal (A) to raise the litter. Depress in the center of pedal (B) to lower both ends of the stretcher together. Depress the side of pedal (B) closest to the foot end of the stretcher to lower the foot end. -
Page 6: Operating Base Controls − 3−Sided Controls
Stretcher Operation OPERATING BASE CONTROLS − 3−SIDED CONTROLS FOOT END HEAD END Pump pedal (A) at the foot end or sides of the stretcher to raise the litter Depress pedal (B) or the side of pedal (C) closest to the head end of the stretcher to lower the head end of the stretcher. -
Page 7: Raising And Lowering Litter Height
Stretcher Operation RAISING AND LOWERING LITTER HEIGHT − SIDE CONTROL CAUTION To avoid damage, remove any equipment that may be in the way before raising or lowering the litter height. To raise the litter height, pump pedal (A) repeatedly until the desired height is achieved (see illustration on page To lower both ends of the litter together, depress the center of pedal (B). -
Page 8: Applying The Brake System
Stretcher Operation APPLYING THE BRAKE SYSTEM Brake/Steer Pedal (Optional) FOOT END HEAD END Brake/Steer Pedal (Optional) WARNING Always apply the caster brakes when a patient is getting on or off the stretcher. Push on the stretcher to en- sure the brakes are securely locked. Always engage the brakes unless the stretcher is being moved. Injury could result if the stretcher moves while a patient is getting on or off the stretcher. -
Page 9: Using Siderails
Stretcher Operation USING THE SIDERAILS CAUTION Be sure the siderail latching mechanism (B) is working properly at all times. If it is not, refer to your stretcher maintenance manual for ”Siderail Latch Adjustment”. When lowering the siderail to the collapsed position, keep extremities of patients and staff away from the side- rail spindles or injury could occur. -
Page 10: Using The Optional Patient Transfer Board/Arm Board
Stretcher Operation USING THE PATIENT TRANSFER BOARD WARNING When using the transfer board to transfer a patient, always lock the brakes on all stretchers, beds, etc. being used and always be certain the transfer board is placed securely on the surface of the mating stretcher or bed. -
Page 11: Operating Crank Fowler/Crank Knee Gatch
Stretcher Operation USING THE PATIENT TRANSFER BOARD/ARM BOARD (CONTINUED) Using the transfer board as an armboard: 1. Raise the support post (D) to the up position. 2. Raise the transfer board (C) from the bottom while lifting from the top. 3. -
Page 12: Operating Pneumatic Fowler
Stretcher Operation OPERATING THE PNEUMATIC FOWLER Squeeze handles (A & B) for pneumatic assistance in lifting the Fowler to the desired height. Remove hand(s) from the handles when the desired height is achieved. CAUTION Operation of the pneumatic Fowler is a manual procedure. Use caution when raising the Fowler while a pa- tient is on the stretcher. -
Page 13: Operating Enhanced Clearance Head Piece
Stretcher Operation OPERATING THE OPTIONAL ENHANCED CLEARANCE HEAD PIECE AXIS AXIS BOTTOM VIEW To operate the articulating head piece, grasp either handle under the head section and squeeze. Handle (A) releases one latch and rotates the head piece on axis ”A”. Handle (B) releases the other latch and rotates the head section on axis ”B”. -
Page 14: Using Optional Inflatable Head Support Cushion
Stretcher Operation USING THE OPTIONAL INFLATABLE HEAD SUPPORT CUSHION The optional inflatable head support cushion has two internal air blad- ders. Squeeze the bulb (A) to inflate the bladders and provide more sta- bility for the patient’s head. Press the release valve (B) to deflate the bladders. -
Page 15: Operating The Optional Foot Extension / Defibrillator Tray
Stretcher Operation USING THE OPTIONAL FOOT EXTENSION/DEFIBRILLATOR TRAY 1. To use as a defibrillator tray, pull out the top knob (A) and pivot the tray (B) over the foot extension (C) until the tray extends flat over the foot end of the stretcher. -
Page 16: Using The Optional Serving Tray
Stretcher Operation USING THE OPTIONAL SERVING TRAY Pull out on either end of the serving tray to extend it to the proper width to fit on top of the stretcher siderails. To store the serving tray in the optional serving tray holder/foot board, push in both ends of the serving tray and slide it into the holder. -
Page 17: Operating The Optional 2−Stage Permanently Attached Iv Pole
Stretcher Operation OPERATING THE OPTIONAL 2−STAGE PERMANENTLY ATTACHED IV POLE DETAIL OF I.V. POLE LATCH NOTE The 2−stage permanently attached IV pole is an option and may have been installed at either the head, foot or both ends of the stretcher. The choice was made at the time the stretcher was purchased. To use the 2−stage permanently attached IV pole: 3. -
Page 18: Operating The Optional 3−Stage Permanently Attached Iv Pole
Stretcher Operation OPERATING THE OPTIONAL 3−STAGE PERMANENTLY ATTACHED IV POLE DETAIL OF I.V. POLE LATCH DETAIL OF I.V. POLE GRIP NOTE The 3−stage permanently attached IV pole is an option and may have been installed at either the head, foot or both ends of the stretcher. -
Page 19: Preventative Maintenance
Preventative maintenance should be performed at a minimum of annually. A preventative maintenance pro- gram should be established for all Stryker Medical equipment. Preventative maintenance may need to be performed more frequently based on the usage level of the product. -
Page 20: Removal Of Iodine Compounds
If these types of products are used to clean Stryker patient handling equipment, measures must be taken to insure the stretchers are rinsed with clean water and thoroughly dried following cleaning. Failure to properly rinse and dry the stretchers will leave a cor- rosive residue on the surface of the stretcher, possibly causing premature corrosion of critical components. -
Page 21: Warranty
Stryker’s obligation under this warranty is expressly limited to supplying replacement parts and labor for, or replacing, at its option, any product which is, in the sole discretion of Stryker, found to be defective. If re- quested by Stryker, products or parts for which a warranty claim is made shall be returned prepaid to Stryker’s factory. -
Page 22: Return Authorization
Stryker will perform all service during regular business hours (9−5) * Replacement parts and labor for products under PM contract will be discounted. ** Does not include any disposable items, I.V. poles (except for Stryker HD permanent poles), mattresses, or damage re- sulting from abuse. - Page 23 European Representative Stryker EMEA RA/QA Director Stryker France ZAC Satolas Green Pusignan Av. De Satolas Green 69881 MEYZIEU Cedex France 3800 E. Centre Ave., Portage, MI 49002 (800) 327−0770 www.stryker.com JH 9/06 1079−009−001 REV A...
