- Page 1 OPERATING AND CARE INSTRUCTIONS AEROMAT VT system AEROMAT VT D AEROMAT VT DF...
-
Page 3: Table Of Contents
Functions AEROMAT VT D / AEROMAT VT DF ........ - Page 4 Operating and care instructions AEROMAT VT D / AEROMAT VT DF 7 TROUBLESHOOTING ................ 29 Error messages on the device .
-
Page 5: About This Documentation
Operating and care instructions AEROMAT VT D / AEROMAT VT DF About this documentation Original operating instructions These instructions are part of the original operating • assembly instructions instructions. The operating instructions consist of the • operating and service instructions... -
Page 6: Abbreviations
Operating and care instructions AEROMAT VT D / AEROMAT VT DF Abbreviations Abbreviation Explanation TVOC Total Volatile Organic Compounds: volatile organic compounds in gaseous form (e. g. ethanol, carbon monoxide, methane, butane and cigarette smoke). Carbon dioxide: a chemical compound composed of carbon and oxygen. -
Page 7: Safety
AEROMAT VT D / AEROMAT VT DF Safety Intended use • The AEROMAT VT system is a ventilation system for • Depending on the environmental conditions, the ventilating and extracting air from closed rooms. AEROMAT VT system can support dehumidification in the home. -
Page 8: Product Specifications
Operating and care instructions AEROMAT VT D / AEROMAT VT DF Product specifications Touch control Item Name Purpose ON/OFF button • Opens and closes the electronic closure. AUTO button • Switches automatic mode on and off. • Opens the menu navigation when pressed and held. -
Page 9: Operation
Sensor (optional in devices with electronic closure) Filter (optional) Supply air • AEROMAT VT D is a passive air ventilator for the ventilation of closed rooms. The air exchange is achieved by equalising pressure between the indoor and outdoor air (pressure differential principle). -
Page 10: Electric Lock
3.2.6 Air quality sensor • The air quality sensor determines a derived CO • The SIEGENIA Comfort app displays the air quality value based on human aspiration (hydrogen H using a traffic light system. • The air quality sensor optionally also determines a •... -
Page 11: Menu
Operating and care instructions AEROMAT VT D / AEROMAT VT DF Menu Menu level principle Menu level 1 Menu level 2 Press on button AUTO Description Menu level 1 Menu level 2 Explanation Change to menu level 1 LED brightness... -
Page 12: Technical Specifications
Operating and care instructions AEROMAT VT D / AEROMAT VT DF Technical specifications 3.4.1 AEROMAT VT D1 • The technical specifications were measured with the minimum ventilator length and without filter. • The technical specifications can vary according to unit configuration. -
Page 13: Aeromat Vt D2
Operating and care instructions AEROMAT VT D / AEROMAT VT DF 3.4.2 AEROMAT VT D2 • The technical specifications were measured with the minimum ventilator length and without filter. • The technical specifications can vary according to unit configuration. Extension parts... -
Page 14: Aeromat Vt D3
Operating and care instructions AEROMAT VT D / AEROMAT VT DF 3.4.3 AEROMAT VT D3 • The technical specifications were measured with the minimum ventilator length and without filter. • The technical specifications can vary according to unit configuration. Extension parts... -
Page 15: Aeromat Vt Df3
Operating and care instructions AEROMAT VT D / AEROMAT VT DF 3.4.5 AEROMAT VT DF3 • The technical specifications were measured with the minimum ventilator length. • The technical specifications can vary according to unit configuration. Extension parts none Vent duct and lintel duct EPP... -
Page 16: Initial Setup
Operating and care instructions AEROMAT VT D / AEROMAT VT DF Initial setup Removing the locking plugs 1. Open the inner panel and remove it. 2. Remove the locking plugs. 3. Turn the inner panel through 180°. 16/32 12.2024 H47.FENS206EN-01... - Page 17 Operating and care instructions AEROMAT VT D / AEROMAT VT DF 4. Place the locking plugs in the holders for storage. 5. Mount the internal panel. 6. Close the internal panel. H47.FENS206EN-01 12.2024 17/32...
-
Page 18: Operation
Operating and care instructions AEROMAT VT D / AEROMAT VT DF Operation Adjustment of menu functions 5.1.1 Adjustment of LED brightness Error messages are always displayed, regardless of the 2. To change to menu level 2, press and hold down adjusted brightness. -
Page 19: Adjusting The Led Illumination Time
Operating and care instructions AEROMAT VT D / AEROMAT VT DF 5.1.2 Adjusting the LED illumination time 3. To change to menu level 2, press and hold down Menu level 1 Menu level 2 Value the AUTO button for 3 seconds. -
Page 20: Adjustment Of Bathroom Run-On Time
Operating and care instructions AEROMAT VT D / AEROMAT VT DF 5.1.3 Adjustment of bathroom run-on time 3. To change to menu level 2, press and hold down Menu level 1 Menu level 2 value the AUTO button for 3 seconds. -
Page 21: Delete Active Faults
Operating and care instructions AEROMAT VT D / AEROMAT VT DF 5.1.4 Delete active faults 1. Call up menu level 1. To do this, hold down the 3. To change to menu level 2, press and hold down "AUTO" button for 8 seconds. -
Page 22: Setting The Device Back To Default Settings
Operating and care instructions AEROMAT VT D / AEROMAT VT DF 5.1.6 Setting the device back to default settings 1. Call up menu level 1. To do this, hold down the 4. Press the "AUTO" button according to the scheme "AUTO"... -
Page 23: Care And Maintenance
Operating and care instructions AEROMAT VT D / AEROMAT VT DF Care and maintenance Notes on cleaning and maintenance NOTE NOTE Material damage due to water in the device Material damage due to cleaning agents containing solvents Water inside the device can lead to damage of the device. - Page 24 Operating and care instructions AEROMAT VT D / AEROMAT VT DF 2. Take the old air filter out of the device and dispose of it. 3. Insert the new air filter into the rear guide groove (1) and press it into place (2).
- Page 25 Operating and care instructions AEROMAT VT D / AEROMAT VT DF 4. Mount the internal panel. 5. Close the internal panel. H47.FENS206EN-01 12.2024 25/32...
-
Page 26: Aeromat Vt Df
Operating and care instructions AEROMAT VT D / AEROMAT VT DF 6.2.2 AEROMAT VT DF Replace the air filter every 6 – 12 months (see page 15). 1. Open the inner panel and remove it. 2. Take the old air filter out of the unit and dispose of it. - Page 27 Operating and care instructions AEROMAT VT D / AEROMAT VT DF 3. Insert the new air filter. 4. Suspend the internal panel. H47.FENS206EN-01 12.2024 27/32...
- Page 28 Operating and care instructions AEROMAT VT D / AEROMAT VT DF 5. Lock the internal panel. 28/32 12.2024 H47.FENS206EN-01...
-
Page 29: Troubleshooting
Operating and care instructions AEROMAT VT D / AEROMAT VT DF Troubleshooting Contact the producer (see page 5) if this table does not describe the error. Error messages on the device Status LED Buzzer Possible cause Solution • Check the supply voltage and power supply. - Page 32 www.siegenia.com...
