MULTISPAN VOLT 23 Quick Start Manual

TECHNICAL SPECIFICATION
INPUT SPECIFICATION :
30 to 300V AC (L - N)
Direct Voltage AC
50 to 520V AC (L - L)
100V to 520kV AC (L-L) (Selectable)
Primary PT
100V to 520V AC (L-L) (Selectable)
Secondary PT
45.0 Hz to 65.0 Hz
Frequency
1 Volt
Resolution
Accuracy
Class 0.5
DISPLAY AND KEY :
Display
4 digit, 1line, 7 seg, 0.56" RED LED
Keys SET/ENT, INC, DEC
L1, L2, L3, Avg, L-L, L-N, Hz
LED Indication
Dimension :
Dimension (mm)
72 (H) x 72 (W) x 35 (D) mm
Panel Cutout 72 (H) x 72 (W) mm
ACCURACY
Class 0.5 (Standard) Class 0.5 (Standard)
AUXILIARY SUPPLY :
Supply voltage
100 to 270V AC,50/60Hz
Power consumption
3 VA MAX
(VA RATING)
ENVIRONMENT CONDITION :
Operating Temp. 0°C to 55°C
UP to 95% RH
Relative Humidity
(non-condensing)
Protection Level
IP-65 (Front side) As per IS/IEC
(As per request)
60529 : 2001
3 PHASE VOLT METER
VOLT 23
NETWORK CONNECTION :
3Ø-3W/3Ø-4W/1Ø-2W 3Ø-3W/3Ø-4W/1Ø-2W
MECHANICAL INSTALLATION
Outline Dimension (mm)
VOLT 23
L1 L2 L3 KV V V Hz
LL LN
72
AVG
SET
ENT
72 3
TERMINAL CONNECTION
Range:
Voltage (L-L) : 50-520V AC
Made in India :
PT Primary: 100V to 520KV AC
~ PT Secondary: 100V to 520V AC
100
270V AC
50/60 Hz
!
3VA
N
L
1 2 3
DISPLAY PAGE
3Ø-4W 3Ø-4W
1) Voltage L1-L2 1) Voltage L1-L2
1) Voltage L1-N 1) Voltage L1-N
240
L1 L2 L3 L1 L2 L3
KV V KV V V V Hz Hz
LL LL LN LN
2) Voltage L2-L3 2) Voltage L2-L3
2) Voltage L2-N 2) Voltage L2-N
241
L1 L2 L3 L1 L2 L3
KV V KV V V V Hz Hz
LL LL LN LN
3) Voltage L3-L1 3) Voltage L3-L1
3) Voltage L3-N 3) Voltage L3-N
250
L1 L2 L3
KV V V H
LL LN Z
4) Frequency
4) Frequency 4) Average 4) Average
243
L1 L2 L3
KV V V H
LL LN Z
4) Frequency 5) Frequency
4) Frequency 5) Frequency
500 500
L1 L2 L3
KV V V H
LL LN Z
Panel Cutout
Dimension (mm)
68
68
35
VOLT-23-A2-00
System:
1P-2W/3Ph-3W/3Ph-4W
(L-N) : 30-300V AC
Accuracy Class: 0.5
www.multispanindia.com
L1 L2 L3 N
4 5 6 7
3Ø-3W 3Ø-3W
1Ø-2W 1Ø-2W
1) Voltage L1-N 1) Voltage L1-N
415 240
L1 L2 L3 L1 L2 L3
KV V V H
KV V
LL LN Z
2) Frequency 2) Frequency
400
500
L1 L2 L3
L1 L2 L3
KV V V H
KV V
LL LN Z
430
L1 L2 L3
KV V V H
LL LN Z
415
L1 L2 L3
KV V V H
LL LN Z
500 500
L1 L2 L3
KV V V H
LL LN Z
V H
LL LN Z
V H
LL LN Z
Page -1
