OPERATING MANUAL
DC AMPERE METER
AV-24DZ
Technical Specification
Model
Display
Size(HXWXD)
Panel Cutout
Range
Power Supply
Protection Level
(As per request)
Operating
Temperature
Connection Diagram
AV-24DZ
100 To 270V AC/DC, 50/60 Hz, Approx 2VA
IP-65(Front side) AS per IS/IEC 60529:2001
0°C To 55°C
AV 24DZ-E3-00
A+ A -
Range : 20.0A DC CAT III
Made in India
100 270V AC/DC
!
50/60 Hz, 2VA
L/+
N/-
1
2
AV 24DZ
AV 24DZ
4 Digit, Single Display
72 X 72 X 36 mm
68 X 68 mm
20.0A DC
Relative
Up to 95% RH Non Condensing
Humidity
-
A+
A
Accuracy: ±1% of Full Range ±1 Count
Page-1
www.multspanindia.com
Advertisement
Related Manuals for MULTISPAN AV-24DZ
Summary of Contents for MULTISPAN AV-24DZ
- Page 1 OPERATING MANUAL DC AMPERE METER AV-24DZ AV 24DZ Technical Specification Model AV 24DZ Display 4 Digit, Single Display Size(HXWXD) 72 X 72 X 36 mm 68 X 68 mm Panel Cutout Range 20.0A DC 100 To 270V AC/DC, 50/60 Hz, Approx 2VA...
- Page 2 1) The equipment should be cleaned regularly to avoid blockage of ventilating parts. 2) Clean the equipment with a clean soft cloth. Do not use isopropyl alcohol or any other cleaning agent. 3) Fusible resistor must not be replaced by operator. AV-24DZ Page - 2 www.multispanindia.com...
