- Page 1 User manual W1925 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels ……………………………………………………………………………………7-11 Dimension …………………………………………………………………………………………11 Trouble Shooting…………………………………………………………………………………12 Fixture Cleaning………………………………………………………… ………………………12 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu 1. Function Display: Shows the various menus and the selected functions 2.LED： POWER ON Power On DMX input present 3. Button: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions 4. -
Page 7: Dmx Channels
4.DMX Channels 14 CH Mode 14CH Function DMX Values Details 000‐019 Shutter closed 020‐024 Shutter open 025‐064 Strobe 1 (fast - slow) 065‐069 Shutter open 070‐084 Strobe 2: opening pulse (fast - slow) 085‐089 Shutter open 090‐104 Strobe 3: closing pulse (fast - slow) 105‐109 Shutter open 110‐124... - Page 8 125‐249 CH 8 Fixture control settings No function 250‐255 Illuminate display 000‐009 Open. RGBW color mixing enabled 010‐014 LEE 790 - Moroccan pink 015‐019 LEE 157 - Pink 020‐024 LEE 332 - Special rose pink 025‐029 LEE 328 - Follies pink 030‐034 LEE 345 - Fuchsia pink 035‐039...
- Page 9 040-057 2400K 058-75 2800K 076-093 3200K 094-111 3600K 112-129 4200K 130-147 4800K CH 14 148-165 5600K 166-183 6500K 184-201 7500K 202-219 8500K 220-237 9500K 238-255 10000K 27 CH Mode 27CH Function DMX Values Details CH 1 0-255 0-540° CH 2 Pan Fine 0-255 16 bit...
- Page 10 CH 12 Blue 1 000‐255 RING 1 BLUE (0- 100%) CH 13 White 1 000‐255 RING 1 WHITE (0- 100%) 000‐009 Open 010‐017 Color1 018‐024 Color2 025‐032 Color3 033‐039 Color4 040‐047 Color5 048‐054 Color6 055‐061 Color7 062‐069 Color8 070‐076 Color9 077‐084 Color10 085‐091...
-
Page 11: Dimension
087-095 Macro5 CH 25 RING COLOR MACRO 096-255 Macro6 CH 26 COLOR MACRO SPEED 000‐255 Slow to fast 022-039 2200K 040-057 2400K 058-75 2800K 076-093 3200K CH 27 094-111 3600K 112-129 4200K 130-147 4800K 148-165 5600K 166-183 6500K 184-201 7500K 202-219 8500K 220-237... -
Page 12: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
