Uplus Lighting W1925 User Manual

Hide thumbs Also See for W1925:

Advertisement

Quick Links

Download this manual
User manual
W1925
Please read the instructions carefully before use

Advertisement

loading
Need help?

Need help?

Do you have a question about the W1925 and is the answer not in the manual?

Questions and answers

Related Manuals for Uplus Lighting W1925

Summary of Contents for Uplus Lighting W1925

  • Page 1 User manual W1925 Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels ……………………………………………………………………………………7-14 Dimension …………………………………………………………………………………………14 Trouble Shooting…………………………………………………………………………………15 Fixture Cleaning………………………………………………………… ………………………15 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...

  • Page 4: Technical Specifications

    •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.

  • Page 5: Control Menu

    3.Control Menu 1. Function Display: Shows the various menus and the selected functions 2.LED： POWER ON Power On DMX input present 3. Button: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions 4.

  • Page 7: Dmx Channels

    4.DMX Channels 10 CH Mode 10CH Function DMX Values Details CH 1 0-255 0-540° CH 2 Pan Fine 0-255 16 bit CH 3 Tilt 0-255 0-270° CH 4 Tilt Fine 0-255 16 bit CH 5 P/T Speed 0-255 Fast to slow 0-69 NULL 70-79...
  • Page 8 132 - 139 LED_EFFECT_THUNDER 140 - 181 LED_EFFECT_PULSE_CLOSE_FADE_OPEN CH 9 Shutter 182 - 189 LED_EFFECT_OPEN 190 - 231 LED_EFFECT_PULSE_OPEN_FADE_CLOSE 232 - 239 LED_EFFECT_OPEN 240 - 247 LED_EFFECT_RANDOM_FLASH 248 - 255 LED_EFFECT_OPEN CH10 Dimmer 0-255 Linear dimmer （dark to brightness) 15 CH Mode 15CH Function DMX Values...
  • Page 9 97-134 Red->up, Green=full, Blue=0, White=0 Yellow (Red=full, Green=full, Blue=0, White=0) 136-174 Red=full, Green->down, Blue=0, White=0 CH 12 Virtual Color Wheel Red(Red=full, Green=0, Blue=0, White=0) 176-214 Red=full, Green=0, Blue->up, White=0 Magenta (Red=full, Green=0, Blue=full, White=0) 216-246 Red -> down, Green=0, Blue=full, White=0 Blue (Red=0, Green=0, Blue=full, White=0) 248-255 NULL...
  • Page 10 CH12 Blue fine 0-255 CH13 White 0-255 CH14 White fine 0-255 CH15 NULL 1-255 2700K-8000K No function (0=default) White 2700 K White 3200 K White 4200 K 10-12 White 5600 K 13-15 White 8000 K Blue (Blue=full, Red+Green+White=0) 17-55 Red=0, Green->up,Blue =full, White=0 Light Blue (Red=0, Green=full, Blue =full, White=0) CH 16 Virtual Color Wheel...
  • Page 11 0-69 NULL 70-79 Moving Blackout Open 80-89 Moving Blackout Off 90-99 PanInvert Open 100-109 TiltInvert Open 110-119 PanTiltInvert Off Special Function 120-139 NULL 140-149 PanTilt Reset 150-179 NULL 180-189 Zoom Reset 190-199 NULL 200-209 All Reset 210-255 NULL Zoom 0-255 Zoom fine 0-255 0 - 15...
  • Page 12 CH13 Virtual Color Wheel Blue (Red=0, Green=0, Blue=full, White=0) 248-255 NULL CH14 Red 1 0-255 CH15 Red 1 fine 0-255 CH16 Green 1 0-255 CH17 Green 1 fine 0-255 CH18 Blue 1 0-255 CH19 Blue 1 fine 0-255 CH20 White 1 0-255 CH21 White 1 fine...
  • Page 13 Special Function 210-255 NULL Red 1 0-255 Red 1 fine 0-255 Green 1 0-255 CH10 Green 1 fine 0-255 CH11 Blue 1 0-255 CH12 Blue 1 fine 0-255 CH13 White 1 0-255 CH14 White 1 fine 0-255 CH15 Red 2 0-255 CH16 Red 2 fine...

  • Page 14: Dimension

    CH32 Virtual Color Wheel 248-255 NULL CH33 Zoom 0-255 CH34 Zoom fine 0-255 0 - 15 LED_EFFECT_OPEN 16 - 131 LED_EFFECT_FLASH 132 - 139 LED_EFFECT_THUNDER 140 - 181 LED_EFFECT_PULSE_CLOSE_FADE_OPEN CH35 Shutter 182 - 189 LED_EFFECT_OPEN 190 - 231 LED_EFFECT_PULSE_OPEN_FADE_CLOSE 232 - 239 LED_EFFECT_OPEN 240 - 247 LED_EFFECT_RANDOM_FLASH...

  • Page 15: Trouble Shooting

    6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
