- Page 1 User manual BSW 380 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-7 DMX Channels …………………………………………………………………………………7-10 Trouble Shooting…………………………………………………………………………………11 Fixture Cleaning………………………………………………………… ………………………11 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Menu Operation On the base of the control panel offers a number of features, such as setting DMX fixture address, switch the lamp, run the test program, the mode selection. Menu features Level 1 second- level menu Three- level menu Four- level menu Five- level menu menu... - Page 6 Automati Scene mode c / 1-10 Automatic Master- slave mode / host/ Running slave mode Scene selection 01-10 Manual control lamps Scene time 0.00S Drop out 01X axis 0-255 Scenario settings ..0-255 24 Reset 0-255 function Lamp reset Running Manual control lamps X axis Y axis Yes/ No...
-
Page 7: Dmx Channels
Half power delay 0-535 Reset lamp time Yes/ No Light lamp Internal use 0-255 Light lamp timing control Remaining maintenance Heavy/ No maintenance time Drop out Service contact information Equipment maintenance Equipment fine calibration Application Equipment data removal service Equipment usage records Drop out 4.DMX Channels Model - CH20/CH24... - Page 8 20-24 Orange 25-29 Purple 30-34 Light yellow 35-39 Plum red 40-44 Pale blue purple Colour wheel 45-49 Cold colour 50-54 Blue Green 55-59 Yellow green 60-64 CTO5600K 65-69 Fluorescence 70-76 White light → red 77-83 Red → blue 84-90 Blue → green 91-97 Green →...
- Page 9 52-55 Pattern 10 Jitter effect from slow to fast 56-59 Pattern 9 Jitter effect from slow to fast Fixed wheel 60-63 Pattern 8 Jitter effect from slow to fast 64-67 Pattern 7 Jitter effect from slow to fast 68-71 Pattern 6 Jitter effect from slow to fast 72-75 Pattern 5 Jitter effect from slow to fast 76-79...
- Page 10 Rotation pattern 146- 150 Stop rotation 151-231 Rotate forward and backward from slow to fast 232-255 Reverse rotation, from slow to fast Rotation pattern 16 bit Adjustable rotation fine- 000-255 tuning Prism 1 0- 15 No functioning 16-255 Eight prisms 0- 127 Eight prism rotation position 128- 189...
-
Page 11: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
