Summary of Contents for Uplus Lighting B420
- Page 1 User manual B420 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions…………………………………………………………………………………3 Technical Specifications……………………………………………………………………………4 Control Menu ………………………………………………………………………………………5-9 DMX Channels …………………………………………………………………………………10-15 Dimension ……………………………………………………………………………………15 Lumen data ……………………………………………………………………………………16 Trouble Shooting……………………………………………………………………………………18 Fixture Cleaning………………………………………………………… …………………………18 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Input Voltage: 100-240V, 50/60Hz Power consumption: 560 W Power supply: 600W Light source: USHIO NSL420S (4000 hours) Color temperature: 7600K Diameter of optic lens: 200mm Beam angle: 1.2° Color wheel: 1 color wheel, 13 fixed colors+4 color effects+white, two-way rainbow effect Static gobo: 18 gobos + 1 white circle Electronic frost effect Prisms: equipped with 8 prisms, 6 rows of prisms, 16 prisms, 48 prisms, and achieving 8... -
Page 5: Control Menu
3.Control Menu 1level menu 2 level menu 3 level menu 4 level menu 5 level menu DMA address 1 - 497/492 DMX SET mode1（16） Channel mode mode2（21） Pan reverse Tilt reverse P/T Feedback open Power ON LAMP open LAMP OFF/NO open Straight line Square law... - Page 6 PAN/TILT head Effect reset prism reset Focus reset Motor sleep ALL test test... tilt dimmer strobe color Fixed gobo Effect test Prism 1 prism1 rotation Prism 2 Prism 2rotation focus frost 0 - 255 Pan fine 0 - 255 tilt 0 - 255 Tilt fine 0 - 255...
- Page 7 Prism 1rotion 0 - 255 fine Prism 2 0 - 255 Prism 2rotion 0 - 255 Prism 2rotion 0 - 255 fine focus 0 - 255 Focus fine 0 - 255 frost 0 - 255 function control 0 - 255 0 - 255 Pan fine 0 - 255...
- Page 8 Gradient 000 - 255 speed 000 - 255 Effect8 Gradient 000 - 255 -128 -> 127 calibration Tilt -128 -> 127 calibration Color -128 -> 127 calibration Gobo -128 -> 127 calibration Prism 1 Overall -128 -> 127 calibration 8Prism -128 ->...
-
Page 9: Dmx Channels
Off lamp 0 - 255 Fixture xxxxxH running time Lamp xxxxxH running time 1U：Vx.x Device version 2U：Vx.x 3U：Vx.x 0x07EF-XXXXXX RDM UID lamp fan Fan1 Fan speed Fan2 Color Fan 4.DMX Channels CH16 Function Value Effect Pan scan Pan Fine Pan Scan fine tilt tilt scan Tilt fine... - Page 10 Rose red Rose red + light green light green light green + Purplish red Purplish red Purplish red + Blue Green Blue Green Blue Green + Light blue purple Light blue purple Light blue purple+ fluorescence fluorescence Fluorescence + Cool color Cool color Cool color + 4500K 4500K...
- Page 11 GOBO 2 shake，slow-fast GOBO 3 shake，slow-fast GOBO 4 shake，slow-fast GOBO 5 shake，slow-fast GOBO 6 shake，slow-fast GOBO 7 shake，slow-fast GOBO 8 shake，slow-fast GOBO 9 shake，slow-fast GOBO 10 shake，slow-fast GOBO 11 shake，slow-fast GOBO 12 shake，slow-fast GOBO 13 shake，slow-fast GOBO 14 shake，slow-fast GOBO 15 shake，slow-fast GOBO 16 shake，slow-fast GOBO 17 shake，slow-fast GOBO 18 shake，slow-fast...
- Page 12 Fast Dimmer（3s） Slow Dimmer（3s） No function ALL Reset（5s） XY Reset （5s） Head reset (5s) No function No function No function No function Lamp open（5s) Lamp off（5s) No function CH21 Function Value Effect Pan scan Pan Fine Pan Scan fine tilt tilt scan Tilt fine Tilt Scan fine...
- Page 13 light green + Purplish red Purplish red Purplish red + Blue Green Blue Green Blue Green + Light blue purple Light blue purple Light blue purple+ fluorescence fluorescence Fluorescence + Cool color Cool color Cool color + 4500K 4500K 4500K + orange orange orange + Four colors Four colors...
- Page 14 GOBO 4 shake，slow-fast GOBO 5 shake，slow-fast GOBO 6 shake，slow-fast GOBO 7 shake，slow-fast GOBO 8 shake，slow-fast GOBO 9 shake，slow-fast GOBO 10 shake，slow-fast GOBO 11 shake，slow-fast GOBO 12 shake，slow-fast GOBO 13 shake，slow-fast GOBO 14 shake，slow-fast GOBO 15 shake，slow-fast GOBO 16 shake，slow-fast GOBO 17 shake，slow-fast GOBO 18 shake，slow-fast Forward rotation, fast to slow stop...
-
Page 15: Dimension
Square Law（3s） Inverse Square Law（3s） S-Curve（3s） No function Fast Dimmer（3s） Slow Dimmer（3s） No function ALL Reset（5s） XY Reset （5s） Head reset (5s) No function No function No function No function Lamp open（5s) Lamp off（5s) No function 5.Dimension... -
Page 16: Lumen Data
6.Lumen data COLOR Wheel STATIC GOBO Wheel... - Page 17 Prisms Effect frost...
-
Page 18: Trouble Shooting
7.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
