- Page 1 User manual B-SLM3 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-7 DMX Channels ……………………………………………………………………………………8-9 Dimension …………………………………………………………………………………………9 Trouble Shooting…………………………………………………………………………………10 Fixture Cleaning………………………………………………………… ………………………10 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Display Mode Function Description A001 A001—A512） Address code Chnd 6 Channel Mode 8 Channel Mode 10CH 10 Channel Mode FAIL BLND DMX512 Data not maintained (black field) HOLd DMX512 data hold CL01 CL01—CL32 32 static color mixing modes with up and down keys for color selection. After confirmation, the strobe mode St00-St16 can be adjusted by pressing the up and down keys AUT0... - Page 6 B000-255 Manual blue dimming W000-255 Manual white dimming A000-255 Manual amber tone light P000-255 Manual Purple Dimming S000-255 Manual strobe speed regulation TEST Color self-test Digital display screen on Digital display screen off IRCL Infrared remote control on Infrared remote control off 2.4G Wireless 2.4G on 1、...
- Page 7 Remarks: A. One-button power on / off function. After selecting the display function to "POWR" for confirmation, select the upper and lower keys to the "ON" state. Press the menu button to turn on the device and press the menu button to turn off the device.
-
Page 8: Dmx Channels
4.DMX Channels 6 CH Mode Channel Function DMX Value Description R Dimmer 0-255 Red dimming from dark to bright G Dimmer 0-255 Green dimming from dark to bright B Dimmer 0-255 Blue dimming from dark to bright W Dimmer 0-255 White dimming from dark to bright A Dimmer 0-255... -
Page 9: Dimension
10 CH Mode Channel Function DMX Value Description Total dimmer 0-255 dimmer from dark to bright R Dimmer 0-255 Red dimming from dark to bright G Dimmer 0-255 Green dimming from dark to bright B Dimmer 0-255 Blue dimming from dark to bright W Dimmer 0-255 White dimming from dark to bright... -
Page 10: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
