  • Page 1 User manual TRI360 Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………2-3 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-9 DMX Channels …………………………………………………………………………………10-12 Dimension …………………………………………………………………………………………13 Trouble Shooting…………………………………………………………………………………14 Fixture Cleaning………………………………………………………… ………………………14 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that the also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...
  • Page 4 Installation: Equipped with removable ring, can be lifted using removable triangle folding bracket, can be placed on the ground This product is suitable for indoor and outdoor performances and parties, its protection level is IP65, the lamps should be kept clean, avoid use in wet or excessive dust environment, should be maintained every three months.

  • Page 5: Technical Specifications

    2.Technical Specifications LED:96PCS 5050 RGB 3in 1 LED Power:28W Input voltage:24V Light source life:20,000 hours Strobe flash: 0 ~ 30Hz Effect: Built-in 30 dynamic effects Maximum working:10 Hours Charging interval: 5 Hours Battery capacity: 10000mah Video display: OLED Channel:7CH /36CH /48CH Signal connection: 2 .4G Wireless connection, Mobile Phone APP, Wireless DMX, Artnet.

  • Page 6: Control Menu

    3.Control Menu Display Function Explain Functional description Act on MODE menu selection Enter the menu selection Menu operation falling-rising tone To the previous option Change the parameter increase DOWN Under To the latter option Change parameter reduction ENTER affirm Confirm selected features Save the last parameter Display Menu Main Menu...
  • Page 7 Program8 Program 9 Program 10 Program 1 1 Program 12 Program 13 Program 14 Program 15 Program 16 Program Program 17 Program 18 Program 19 Program 20 Program 21 Program 22 Program 23 Build-in Program From 1 To 30 Program 24 Program 25 Program26 Program 27...

  • Page 8: Power Supply Connection

    Power supply connection This product is a convenient, high- performance battery lamp, with the following two charging solutions: Scheme 1 uses the charging device in the special air box for charging, and the eight desk lamps can be charged at the same time Scheme 2: Charge with a 24V power adapte Signal connection WIFI control...

  • Page 9: Wireless Dmx Control

    ArtNet protocol wireless control ARTENT Control of the steps Step 1: Step 1: the computer is connected to the controller with the network cable, and the control box will automatically recognize the IP of the computer by default. If it cannot be automatically identified, manually set the control box->...

  • Page 10: Dmx Address Code Setting

    DMX address code setting address first address second address third address fourth address 7C H 01-07 36CH 01-36 48CH 01-48 Above: Number of lamps added from the fourth set; address code according to channel and so on. 4.DMX Channels 7 Channel mode 7 CH Function Value...

  • Page 11: Channel Mode

    Program 17 144– 151 Program 18 152– 159 Program 19 160– 167 Program 20 168– 175 Program 21 176– 183 Program 22 184– 191 Program 23 192– 199 Program 24 200–207 Program 25 208–215 Program 26 216–223 Program 27 224–231 Program 28 232–239 Program 29...
  • Page 12 LED21-LED24 Green 000 – 255 LED21-LED24 Blue 000 – 255 LED25-LED28 000 – 255 LED25-LED28 Green 000 – 255 LED25-LED28 Blue 000 – 255 LED29-LED32 000 – 255 LED29-LED32 Green 000 – 255 LED29-LED32 Blue 000 – 255 LED33-LED36 000 – 255 LED33-LED36 Green 000 –...
  • Page 13 LED3- LED15 Green 000 – 255 LED13-LED15 Blue 000 – 255 LED16-LED18 000 – 255 LED16-LED18 Green 000 – 255 LED16-LED18 Blue 000 – 255 LED19-LED21 000 – 255 LED19-LED21 Green 000 – 255 LED19-LED21 Blue 000 – 255 LED22-LED24 000 –...

  • Page 14: Dimension

    5.Dimension...

  • Page 15: Trouble Shooting

    6. Trouble Shooting Simple troubleshooting method question Check the cause resolvent Screen-free display Battery battery (cause is not on when Charge the battery (Power displays the current charging) charge) The DMX wireless Check the lamp Mode mode with 7 CH / 36 Select Mode Mode to set to Channel Mode signal cannot receive / CH / 48 CH and press the confirmation key...
