- Page 1 User manual IP-BSW500 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 . Technical Specifications…………………………………………………………………………4 . Control Menu ………………………………………………………………………………………5 . DMX Channels ……………………………………………………………………………………6-10 . Dimension ……………………………………………………………………………………………11 . Trouble Shooting…………………………………………………………………………………12 . Fixture Cleaning………………………………………………………… ………………………12 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Menu Operation On the base of the control panel offers a number of features, such as setting DMX fixture address, switch the lamp, run the test program, the mode selection. Stepper info Display information status of all motors and signals in fixture. Hall No display, indicating that the motor has no Hall, 0 indicating that the motor leaves the correction position point, 1 indicating that the motor is in... -
Page 6: Dmx Channels
4.DMX Channels DMX channel´s functions and values (22DMX channels) Channel Function DMX Value Function Illustration 0-255 Pan fine 0-255 Pan fine Tilt 0-255 Tilt Tilt fine 0-255 Tilt fine Dimmer 0-255 0-100% linear dimming No function 4-103 Pulse strobe slow to fast 104-107 open 108-155... - Page 7 20-24 Gobo5 25-29 Gobo6 30-34 Gobo7 CH12 Static GOBO 35-39 Gobo8 40-44 Gobo9 45-49 Gobo10 50-54 Gobo11 55-59 Gobo12 60-64 White 65-69 Shake slow to fast Gobo2 70-74 Shake slow to fast Gobo3 75-79 Shake slow to fast Gobo4 80-84 Shake slow to fast Gobo5 85-89 Shake slow to fast Gobo6...
- Page 8 0-127 None CH15 Prism 1 128-255 Inert prism1 0-127 0-360(degree) CH16 Prism 1 Rot 128-187 Rotate forward (fast to slow) 188-195 Stop 196-255 Rotate reverse (slow to fast) 0-127 None CH17 Prism 2 128-255 Inert prism2 0-127 0-360(degree) CH18 Prism 2 Rot 128-187 Rotate forward (fast to slow) 188-195...
- Page 9 80-89 Color8 90-99 White+Color1 Color wheel 100-109 Color1+color2 110-119 Color2+color3 120-129 Color3+color4 130-139 Color4+color5 140-149 Color5+color6 150-159 Color6+color7 160-169 Color7+color8 170-179 Color8+color9 180-215 Rotate forward (fast to slow) 216-220 Stop 221-255 Rotate reverse (slow to fast) Cyan 0-255 CH10 Magenta 0-255 CH11 Yellow...
- Page 10 10-19 Gobo1 20-29 Gobo2 30-39 Gobo3 40-49 Gobo4 CH14 Rot GOBO 50-59 Gobo5 60-69 Gobo6 70-79 Gobo7 80-89 Shake slow to fast Gobo1 90-99 Shake slow to fast Gobo2 100-109 Shake slow to fast Gobo3 110-119 Shake slow to fast Gobo4 120-129 Shake slow to fast Gobo5 130-139...
-
Page 11: Dimension
5.Dimension... -
Page 12: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
