Summary of Contents for Uplus Lighting IP-S1000
- Page 1 User manual IP-S1000 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels ……………………………………………………………………………………6-9 Trouble Shooting…………………………………………………………………………………10 Fixture Cleaning………………………………………………………… ………………………10 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Menu Description Main menu Secondary Menu Third level menu Default value add 001 15CH/158CH/50CH 15CH Signal status clear/keep clear PassWord - - - - ↑↓↑↓ R current 020--255 G current 020--255 B current 020--255 root W current 020--255 temperature 40--80 power... -
Page 6: Dmx Channels
Controll Note: In the case of temperature control short circuit or open circuit, the fan is only controlled by the light, that is, the light fan starts, and the Fans mode fan stops after 20 seconds after turning off the Controll /longTurn light;... - Page 7 128-159 Slow strobe CH10 White strobe 160-191 Turn on 192-223 random strobe 224-255 Turn on No function Effect 1 10-13 Effect 2 14-17 Effect 3 CH11 RGBW Macro function selection 18-21 Effect 4 22-25 Effect 5 26-29 Effect 6 …… ……...
- Page 8 64-95 Ordinary strobe 96-127 Turn on CH43 RGB strobe 128-159 Slow strobe 160-191 Turn on 192-223 random strobe 224-255 Turn on Turn on 6-31 Turn off 32-63 Turn on CH44 White strobe 64-95 Ordinary strobe 96-127 Turn on 128-159 Slow strobe 160-191 Turn on 192-223...
- Page 9 CH152 RGB Dimmer fine 0-255 RGB Dimmer fine,from dark to light CH153 White total dimmer 0-255 White total dimmer,from dark to light CH154 White dimmer fine 0-255 White dimmer fine,from dark to light Turn on 6-31 Turn off 32-63 Turn on CH155 RGB strobe 64-95...
-
Page 10: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
