Summary of Contents for Uplus Lighting IP-ZP1815
- Page 1 User manual IP-ZP1815 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ………………………………………………………………………………………5 DMX Channels ……………………………………………………………………………………6 Trouble Shooting…………………………………………………………………………………7 Fixture Cleaning………………………………………………………… ………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
Installation: •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
3.Control Menu Operating instructions: Pressing function key A will cycle through 15 different function effects, the first two digits of the digital tube represent the current function (refer to the menu). The last two digits represent the function in which the. Address code. or speed, parameter. Press B or C to change the value of the parameter. -
Page 6: Dmx Channels
4.DMX Channels 11 Channel Model Display Function Dimmer R、G、B、W dimmer : from dark to bright R Dimmer Red Dimmer- Dark to Bright G Dimmer Green Dimmer- Dark to Bright B Dimmer Blue Dimmer- Dark to Bright W Dimmer White Dimmer- Dark to Bright Y Dimmer Yellow Dimmer- Dark to Bright Strobe... -
Page 7: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
