Uplus Lighting IP-PIX1830 User Manual

Advertisement

Quick Links

User manual
IP-PIX1830
Please read the instructions carefully before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP-PIX1830 and is the answer not in the manual?

Questions and answers

Summary of Contents for Uplus Lighting IP-PIX1830

  • Page 1 User manual IP-PIX1830 Please read the instructions carefully before use...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………4-7 DMX Channel ……………………………………………………………………………………7-22 Dimension………………………………………………………………………………………23-24 Trouble Shooting…………………………………………………………………………………25 Fixture Cleaning………………………………………………………… ………………………25 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.
  • Page 4: Technical Specifications

    2.Technical Specifications Light source:18*30W RGBWAUV 6in1 Led,auxiliary light 160*0.5W RGB LED Led pixel control effect Four side of bar can be freely spliced Max consumption Power: 400W Beam angle:20°(6°/10°/12°/15°/25°/40°optional) DMX Channel:9/228/66/37/20/86CH Control: DMX512/Auto Run/Master-Slave/RDM Display:LCD display IP Rate: IP65 Strong aluminum housing and IP65 cooling fan Rich build-in color &...
  • Page 5 Main menu Function Note DMX__009/228/066/0 Channel Address Code range :001—512 37/020/086 Attention: When receiving the DMX A 001 signal, the "__" interval in the first line of display flashes DMX_CH 009CH Channel Mode xx:009/228/066/037/020/086 range :00-41 range :00-99 * become -:mean the item is selected Z-M 00:Do not execute Main light effects Z-M *00...
  • Page 6 S-M 00 [Execute lighting effects through S-S *99 color polling] Z_Red Static main light red range :000-255 R:255 Z_Green Static main light green range :000-255 G:255 Z_Blue Static main light blue range :000-255 B:255 LCD Background Display Function (The number in the display list is the default value for this item) (Press and hold the function key for 10 seconds to enter the DMX mode, and press the determine key to exit)...
  • Page 7 When restoring the factory settings, the current value and total power limit will not be restored. Temp D:55 Setting the temperature value of the lamp body, (40-70) Note that this function only works when the lamp body is connected to a temperature control resistor D-State OFF OFF DMX512 signal failure (after signal failure, the light enters...
  • Page 8: Dmx Channels

    4.DMX Channels 9 Channel Channel Function Description Value Main light R dimming 0-255 Control the main light R from dark to bright Main light G dimming 0-255 Control the main light G from dark to bright Main light B dimming 0-255 Control the main light B from dark to bright Main light W dimming...
  • Page 9 .... 0-255 ..Auxiliary light R40 dimming 0-255 Control the Auxiliary light R40 from dark to bright Auxiliary light G40 dimming 0-255 Control the Auxiliary light G40 from dark to bright Auxiliary light B40 dimming 0-255 Control the Auxiliary light B40 from dark to bright Lamp bead arrangement (both main and auxiliary light signals enter from board 1) Main light ……...
  • Page 10 Lamp bead arrangement (both main and auxiliary light signals enter from board 1) Main light …… Auxiliary light 37 Channel Channel Function Description Value Full control and point control 0-255 Must be turned on, otherwise the light beads will total dimming not light up Full control strobe empty...
  • Page 11 together) 0-5 empty 6-10 Pattern Summary 11-15 Pattern 1 16-20 Pattern 2 21-25 Pattern 3 26-30 Pattern 4 31-35 Pattern 5 36-40 Pattern 6 41-45 Pattern 7 46-50 Pattern 8 51-55 Pattern 9 56-60 Pattern 10 61-65 Pattern 11 66-70 Pattern 12 71-75 Pattern 13...
  • Page 12 206-210 Colorful patterns 6 211-221 Voice control mode 1 Macro function 222-232 Voice control mode 2 233-243 Voice control mode 3 244-255 Summary of voice control modes Macro speed 0-255 From slow to fast (when the speed is zero, macro functions will not be executed) LED1 dimming 0-255...
  • Page 13: Dmx Channel

    Lamp bead arrangement (both main and auxiliary light signals enter from board 1) Main light …… 20 Channel Channel Function Description Value Total dimming 0-255 Must be turned on, otherwise the light beads will not light up Total strobe empty 6-255 strobe, from slow to fast 0-5...
  • Page 14 166-170 Gradient 171-175 Pulse 176-180 Jump 181-185 Colorful patterns 1 186-190 Colorful patterns 2 Main light macro function 191-195 Colorful patterns 3 196-200 Colorful patterns 4 201-205 Colorful patterns 5 206-210 Colorful patterns 6 211-221 Voice control mode 1 222-232 Voice control mode 2 233-243 Voice control mode 3...
  • Page 15 6-255 strobe, from slow to fast Auxiliary light R dimming 0.255 Control the color of the auxiliary light R from dark to bright, and it can also be used as a color selection for the auxiliary light macro function Auxiliary light G dimming 0-255 Control the color of the auxiliary light G from dark to bright, and it can also be used as a color...
  • Page 16 102-104 Pattern 32 105-107 Pattern 33 108-110 Pattern 34 111-113 Pattern 35 114-116 Pattern 36 117-119 Pattern 37 120-122 Pattern 38 123-125 Pattern 39 126-128 Pattern 40 129-131 Pattern 41 132-134 Pattern 42 135-137 Pattern 43 138-140 Pattern 44 141-143 Pattern 45 144-146 Pattern 46...
  • Page 17 240-242 Colorful patterns 7 243-245 Colorful patterns 8 246-247 Voice control mode 1 Auxiliary light Macro 248-249 Voice control mode 2 Function 250-251 Voice control mode 3 252-255 Summary of voice control modes Auxiliary light macro function 0-255 From slow to fast (when the speed is zero, macro speed functions will not be executed) 1-36...
  • Page 18 71-75 Pattern 13 76-80 Pattern 14 81-85 Pattern 15 86-90 Pattern 16 91-95 Pattern 17 96-100 Pattern 18 101-105 Pattern 19 106-110 Pattern 20 111-115 Pattern 21 116-120 Pattern 22 121-125 Pattern 23 126-130 Pattern 24 131-135 Pattern 25 136-140 Pattern 26 Main light macro function 141-145...
  • Page 19 223-255 composite color (from dark to bright) Main light R dimming 0-255 Control the main light R from dark to bright, and it can also be used as a color selection for the main light macro function Main light G dimming 0-255 Control the main light G from dark to bright, and it can also be used as a color selection for the...
  • Page 20 45-47 Pattern 13 48-50 Pattern 14 51-53 Pattern 15 54-56 Pattern 16 57-59 Pattern 17 60-62 Pattern 18 63-65 Pattern 19 66-68 Pattern 20 69-71 Pattern 21 72-74 Pattern 22 75-77 Pattern 23 78-80 Pattern 24 81-83 Pattern 25 84-86 Pattern 26 87-89 Pattern 27...
  • Page 21 183-185 Pattern 59 186-188 Pattern 60 189-191 Pattern 61 192-194 Pattern 62 195-197 Pattern 63 198-200 Pattern 64 201-203 Pattern 65 204-206 Pattern 66 207-209 Pattern 67 210-212 Pattern 68 Auxiliary light Macro Function 213-215 Gradient 216-218 Pulse 219-221 Jump 222-224 Colorful patterns 1 225-227...
  • Page 22 Main light A1 dimming 0-255 Control the main light A1 from dark to bright Main light UV1 dimming 0-255 Control the main light UV1 from dark to bright Main light R2 dimming 0-255 Control the main light R2 from dark to bright Main light G2 dimming 0-255 Control the main light G2 from dark to bright...
  • Page 23: Dimension

    5.Dimension...
  • Page 25: Trouble Shooting

    6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
