- Page 1 User manual IP-LB20 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions…………………………………………………………………………3-4 Technical Specifications……………………………………………………………………4-5 Control Menu …………………………………………………………………………………5-8 DMX Channels ………………………………………………………………… ……………8-11 ………………………………………………………………… ………………12 6.Trouble Shooting………………………………………………………………………………13 7.Fixture Cleaning………………………………………………………… ……………………13 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
Installation: •The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
Product features: 1. Uniform light output, 2. Bright and saturated colors, 3. Aluminum alloy shell, sturdy body, compact structure, and excellent heat dissipation, 4. Standard diffusion film, magnetic suction design, simple and convenient 5. Multi sided splicing design, which can be infinitely spliced to form various shapes 6. - Page 6 2. Menu Function Description Display mode Function Description Address 001—512 Address code settings 2 Channel Mode Channel 6 Channel Mode 8 Channel Mode 11CH 10 Channel Mode DMX Fail Blackout Console data black field Hold Console data retention 600HZ 600 Refresh frequency 1200HZ 1200 Refresh frequency Frequency...
- Page 7 5200K 10000K 5600K WIFI LED_XXX WIFI mode and link address MASTER/SLAVE MASTER/SLAVE Master/Slave Wireless DMX ON Long GZ MODE Frequency band ID1-ID7 ON/OFF press to Group ID:1-7 Red/Green/Yellow/Blue/Purple/Blue/White confirm in Clear StateKey, Select RD MODE Pairing GZ/RD MODE Run Time 2/4/6/8 hour Lamp usage time setting Back Light...
-
Page 8: Dmx Channels
text starting with an LED will appear. For example, "LED-XXX", click on the link Step 4. The phone returns to the Home screen, finds the APP installed on the phone, opens it, and controls it after the link is successful. D.In the menu Wireless mode, the 7 frequency bands of wireless 2.4G can be adjusted, and the corresponding light colors of the 7 frequency bands are as follows (01 red/02 green/03 yellow/04 blue/05 light blue/06 purple/07 white) - Page 9 151-160Color temperature 6800K 161-170Color temperature 7200K 171-180Color temperature 7600K 181-190Color temperature 8000K 191-200Color temperature 8400K 201-210Color temperature 8800K 211-220Color temperature 9200K 221-230Color temperature 9600K 231-240Colortemperature 10000K 241-255NO FUNCTION 1-255 1-255 1-255 Blue linear Green linear dimming dimming linear dimming 1-255 1-255 1-255 White linear...
- Page 10 131-140Color temperature 6000K 141-150Color temperature 6400K 151-160Color temperature 6800K 161-170Color temperature 7200K 171-180Color temperature 7600K 181-190Color temperature 8000K 191-200Color temperature 8400K 201-210Color temperature 8800K 211-220Color temperature 9200K 221-230Color temperature 9600K 231-240Colortemperature10000K 241-255 NO FUNCTION 0-9 Closed light 10-50Staticcolormixing 51-100Jump mode 101-150Gradientmode 151-200mutationpattern 201-215...
- Page 11 Infrared remote control function: 1、Dimming up button 2、Dimming down key 3、OFF light off pause 4、ON operation 5、R、G、B、W、A、UV keys are 6 monochromes. 6、The 0 key is in the A001 console reception mode, and the up and down keys adjust the address 7、1-9 number keys for 9 mixed colors.
- Page 12 5.Dimension...
-
Page 13: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
