- Page 1 GTL-100 Tube Labeling Printer User Manual User Manual :GTL-100 Version Issue Date :2019.08.16 :920-017821-00...
-
Page 2: Table Of Contents
Contents 1.Tube Labeling Printer ................................................1 1.1 Box content ................................................... 1 1.2 Overview ..................................................2 2 Loading the ribbon .................................................. 4 3. Tube Labeling Printer Instructions ............................................5 3.1 Use your computer to operate the printer ........................................5 4.Troubleshooting and Maintenance ............................................7 4-1Troubleshooting ─... - Page 3 FCC COMPLIANCE STATEMENT FOR AMERICAN USERS Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 Subpart B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Please read the following instructions carefully. Keep the equipment away from humidity. Before you connect the equipmentto the power outlet,please Check the voltage of the power source. Make sure the printer is off before plugging the power connector into the power jack. It is recommended that you connect the printer to a surge protector to prevent possible transient overvoltage damage. -
Page 5: Tube Labeling Printer
1.Tube Labeling Printer 1.1 Box content USB Cable Power Adapter Power Cord AC Adapter... -
Page 6: Overview
1.2 Overview Front view Part name Part name Media supply hub Spring-Loaded Plungers Top cover Rewinder Feed key Labeling system Power Indicator Tube tray Data transfer indicator... - Page 7 Real View Part Name Part Name Power switch Top cover Calibration button USB Host Power slot Ethernet port USB port RS-232 Serial port...
-
Page 8: Loading The Ribbon
2 Loading the ribbon 1. Place the media into the media supply hub (1) and Pass through above the shaft (2) 2. Press the fix hook and open the tph. 3. After passing the label paper through the label adjustment seat (4) and pass through the platen holder (5), the label is clamped to the rewinder (6) by the U-shaped clip. -
Page 9: Tube Labeling Printer Instructions
3. Tube Labeling Printer Instructions 3.1 Use your computer to operate the printer 1. After the Tube labeling printer is turned on, the labeling printer is automatically positioned. After the preparation is completed, the Data transfer indicator (1) will light up in yellow. 2. - Page 10 5. After pressing the print key, the data transfer indicator will start to flash (3). Please put the corresponding test tube(4) in the order shown to complete the labeling.
-
Page 11: Troubleshooting And Maintenance
4.Troubleshooting and Maintenance 4-1Troubleshooting ─ Paper jam 1. When you encounter a paper jam, open the top cover and the left side cover, pull up the labeling printer fixing clip (1), and lower the labeling system to the left. 2. After pulling forward, lift up to remove the labeling cover 3. -
Page 12: Maintenance
4-2 Maintenance 1. Wipe the print head (1) and the platen (2) with a dry cloth. 2. It is recommended to clean at least once every two weeks. -
Page 13: Appendix
Appendix Specifications Model GTL-100 Print method Direct thermal Resolution 203 dpi (8 dots/mm) Diameter 13-16mm, Length 75-100mm Tubes Can use Plastic or Glass tubes Throughput 3 sec per a labeling Label size 50(W) x 30(H)mm Label Roll Max. 4.33”(110mm) Media... - Page 14 Agency Approvals CE, FCC Class B, BSMI, CB, UL, cUL Bluetooth Options Carry Bag *Appearance and specifications are subject to change without prior notice for improvements.
