- Page 1 EL-41W 4 by 1 HDMI 1.3 Switcher Operation Manual EL-41W...
-
Page 2: Revision History
Revision History Version No. Date Summary of Change 20090514 Preliminary Release Precaution Failure to follow the precautions described below may cause damage to 4 by 1 HDMI 1.3 Switcher and void the warranty. DO NOT open the case. Doing so will void the warranty. If you find ... -
Page 3: Table Of Contents
Table of Contents Introduction…………………………………………………..………. Applications………………………………..………………....…. Package Contents………………………………………....… System Requirements…………………………………………..……. Features……………………………………………..……..……… Operation Controls and Functions……………………………………. Top Panel ................. Front Panel…………………………………………..….….… Remote Control.....……………………………..……..… Connection and Installation……………………………..……..… Specifications……………………………………………...……….. -
Page 4: Introduction
1. Introduction This is a high performance HDMI v1.3 Switcher with remote control. It allows various HDMI sources to share a HDTV display. Simply press the button to select your desire HDMI source for display on the HDTV. The device is compatible to HDMI v1.3 specifications, and can define to supports Deep Color transfer (10-bit and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high... -
Page 5: Features
5. Features HDMI 1.3, HDCP1.1 and DVI1.0 compliant. Deep color video up to 12bit, 1080p@60Hz. Four HDMI sources to connect up to a HDMI display simultaneously. Supports DVI source and DVI display by using HDMI to/from DVI adaptor ... -
Page 6: Operation Controls And Functions
④ ④ Sys. Reset: System reset function. Sys.Reset It is suggested having this function switch OFF always except when EL-41W doing system reset. By switching 4X1 HDMI V1.3 Switcher INPUT to ON, the system will reset HDMI output to HDMI input1gradually ⑤... -
Page 7: Remote Control
7. Remote Control ① Power button: Press to switch On the device, press it again to set the device in standby mode. ② 1~4: Press the desire input button to select the input source. 8. Connection and Installation LCD TV Blue Ray 30˚... -
Page 8: Specifications
9. Specifications Frequency Bandwidth 2.25Gbps (single link) Input Ports 4 x HDMI Female ports Output Port 1 x HDMI Female port (single link) HDMI Output Resolution 480i ~1080p 50/60, 1080p24, VGA~UXGA Power Supply 5VDC / 1A (US/EU standards, CE/FCC/UL certified) Dimensions (mm) 93(W) x 148 (D) x 31 (H) Weight (g)
