EPILOG LASER

16371 Table Mountain Parkway

Golden, Colorado 80403

Phone 303-215-9171 - FAX 303-277-9669

www.epiloglaser.com

Machine Type: 36EXT

Procedure: Checking Table Level

About the safety messages used in this document

Throughout this document, certain items are labeled Note, Safety Glasses, Caution, Warning or

Danger. These terms alert you to precautions that may result in damage to your engraving system

or a risk to your personal safety. Read and follow them carefully.

This SAFETY ALERT SYMBOL is used to draw your attention to issues which could involve

potential personal injury.

WARNING ELECTRICAL HAZARD: This symbol indicates a potentially hazardous

electrical situation which, if not avoided, could result in Death or Serious personal injury.

system.

CAUTION: PINCH POINT HAZARD: This symbol indicates a possible Pinch Point Hazard

which if not avoided may result in personal injury and possible damage to the engraving system.

Keep hands clear.

SAFETY GLASSES indicate a direct hazardous situation which, if Safety glasses are not

worn may result in eye injury or permanent loss of vision.

NOTE: A 'Note' is not necessarily safety related but indicates a recommendation or special point of

information that could assist in understanding the use or care of a feature item.

Need help?

Do you have a question about the Legend 36EXT and is the answer not in the manual?

Page 1 EPILOG LASER 16371 Table Mountain Parkway Golden, Colorado 80403 Phone 303-215-9171 - FAX 303-277-9669 www.epiloglaser.com Machine Type: 36EXT Procedure: Checking Table Level About the safety messages used in this document Throughout this document, certain items are labeled Note, Safety Glasses, Caution, Warning or Danger.
Page 2 Tools required: Manual Focus Gauge SAFETY GLASSES: Please wear the safety glasses which were provided with your machine and or your replacement/repair parts. 2. With your machine on, open up the main door so you can have full access to the table. 3.
Page 3 CAUTION: PINCH POINT HAZARD: Using the focus feature, raise the table until the focus gauge just comes in to contact with the engraving surface. This corner is our standard. All other corners will be raised or lowered accordingly to match this corners height.
Page 4 10. The table lift wings, which support the table assembly pass through these cut outs. At each of the tables attachment points there are 2 5/32 Allen Screws. These two 5/32 Allen wrench screws are used to fine tune the table level. There is about 3/8” adjustment max per screw.
