SERVICE PROCEDURE
PCS Replacing Arbor & Motor Belts
Applicable Model(s)
Professional Cabinet Saw (PCS175 & PCS31230).
Tools Needed
19mm combo or socket wrench
•
•
5mm hex wrench
•
Soft blow hammer
•
Block of wood
Part(s) or Service Kit(s) Needed
•
Arbor Belt
•
PCS Motor Belt
Related Links
•
SawStop Service Video – PCS Belt Replacement
PROCEDURE SUMMARY
This procedure instructs how to replace the belts for the motor and arbor block. Replacement of the
belts might be indicated if the belts make a noise on startup or if the saw lacks power when cutting
material.
SawStop typically recommends replacing both belts after 2 to 4 years of use.
SAFETY
WARNING:
Disconnect the plug from the power source from the tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
WARNING:
Wear gloves when handling the saw blade.
WARNING:
When servicing your tool, use only replacement parts from SawStop.
WARNING:
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
SawStop.com/support
For questions, contact SawStop Technical Support
Phone: 503-582-9934 / Email:
service@sawstop.com
Rev Date 0872024
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SawStop PCS175
Summary of Contents for SawStop PCS175
- Page 1 This procedure instructs how to replace the belts for the motor and arbor block. Replacement of the belts might be indicated if the belts make a noise on startup or if the saw lacks power when cutting material. SawStop typically recommends replacing both belts after 2 to 4 years of use. SAFETY WARNING: Disconnect the plug from the power source from the tool before making any adjustments, changing accessories, or storing power tools.
- Page 2 7. Working through the motor door, use the 5mm hex wrench to remove the hex cap screw and washer that holds the shaft for the double pulley. (Image 2) Image 2 SawStop.com/support For questions, contact SawStop Technical Support Rev Date 0872024 Phone: 503-582-9934 / Email: service@sawstop.com...
- Page 3 16. Lower the assembly to create room for the wooden block to fit between the motor bracket and the upper torque tube, then raise the elevation so that the assembly puts tension on the belt. (Image 4) Image 4 SawStop.com/support For questions, contact SawStop Technical Support Rev Date 0872024 Phone: 503-582-9934 / Email: service@sawstop.com...
- Page 4 22. Pull out on the switchbox paddle to start the saw. 23. Listen for any squealing sound from the belts on startup. If any squealing occurs on startup with the replacement belt, contact SawStop Technical Service for further troubleshooting. SawStop.com/support...
