SawStop PCS175 Service Procedure

SERVICE PROCEDURE
Servicing Lower Limit PCS
Applicable Model(s)
Professional Cabinet Saw (PCS175 & PCS31230)
Tools Needed
• Wire brush
Air compressor or Canned Air
•
5mm hex key
•
Related Links
PCS Tilt and Elevation Maintenance
•
• PCS31230 Owner's Manual
• PCS175 Owner's Manual
PROCEDURE SUMMARY
Saw dust accumulation in or around the lower limit stop bolts and shaft may prevent the arbor from being able to
lower properly. This in turn could cause the blade to protrude above the tabletop.
SAFETY
WARNING: Disconnect the plug from the power source from the tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
WARNING: Wear gloves when handling the saw blade.
WARNING: When servicing the tool, use only replacement parts from SawStop.
WARNING: Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
WARNING: Read and understand the instruction manual and all safety warnings that came with the tool
before attempting to maintain or operate the tool. Failure to follow instructions or heed warnings may
result in electric shock, fire, serious personal injury or property damage. Save these instructions and
refer to them whenever necessary.
SawStop.com/support For questions, contact SawStop Technical Support
Phone: 503-582-9934 / Email: service@sawstop.com
110124
