SERVICE PROCEDURE
Steps to Manually Reset Arbor in Retention Bracket
Applicable Model(s)
Jobsite Saw (JSS), Professional Cabinet Saw (PCS), Industrial Cabinet Saw (ICS/CB)
Tools Needed
Blade wrenches
•
•
Gloves or shop towel
Related Links
•
Resetting the arbor arm on JSS/PCS/ICS table saws
PROCEDURE SUMMARY
This procedure demonstrates how to manually reset the arbor in the retention bracket on the JSS, ICS,
CB, and PCS model saws. A manual reset might be required if the arbor does not lock in place, drops
during operation, or can be moved freely while the saw is off. This most often occurs after your saw had
a safety activation.
SAFETY
WARNING:
Disconnect the plug from the power source from the tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
WARNING:
When servicing your tool, use only replacement parts from SawStop.
WARNING:
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
WARNING:
Read and understand the instruction manual and all
safety warnings that came with your tool before attempting to maintain or operate the tool. Failure to
follow instructions or heed warnings may result in electric shock, fire, serious personal injury or property
damage. Save these instructions and refer to them whenever necessary.
SawStop.com/support
For questions, contact SawStop Technical Support
Phone: 503-582-9934 / Email:
service@sawstop.com
Rev Date 073024
