SawStop ICS Series Service Procedure

SERVICE PROCEDURE
Replacing Switch Box for ICS, PCS and CNS
Applicable Model(s)
Industrial Cabinet Saw (ICS), Professional Cabinet Saw (PCS), Contractor Saw (CNS)
Tools Needed
• #2 Phillips screwdriver
5mm hex key
•
Part(s) or Service Kit(s) Needed
CB107 035 (Referenced by Part Number(s): CB107 035, PCS-019, CNS-07-026)
•
Related Links
Replace Switch Box for Cast Iron Saws
•
PROCEDURE SUMMARY
This procedure demonstrates how to replace the switch box on ICS, PCS, or CNS saw. Replacement might
be required in the event of an electrical or mechanical fault within the switch box.
SAFETY
WARNING: Disconnect the plug from the power source from the tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
WARNING: When servicing your tool, use only replacement parts from SawStop.
WARNING: Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
WARNING: Read and understand the instruction manual and all safety warnings that came with your
tool before attempting to maintain or operate the tool. Failure to follow instructions or heed warnings
may result in electric shock, fire, serious personal injury or property damage. Save these instructions and
refer to them whenever necessary.
DISASSEMBLY
1. Disconnect all electrical power to the saw.
2. Using the #2 Phillips screwdriver, remove seven screws from the left side of the switch box. (Set
aside the left switch box cover along with the seven screws.) (Image 1)
