Operating Manual

Digital

precision measuring amplifier

DMP40, DMP40S2

B0396 4.0 en

Table of Contents

Need help?

Do you have a question about the DMP40 and is the answer not in the manual?

Questions and answers

Summary of Contents for HBM DMP40

Page 1 Operating Manual Digital precision measuring amplifier DMP40, DMP40S2 B0396 4.0 en...
Page 3 ..........DMP40, DMP40S2...
Page 4: Table Of Contents
Functions and symbols on the DMP Control elements on the DMP40 ......... .
Page 5 ......... . . E 46 DMP40, DMP40S2...
Page 6 ........... Index DMP40, DMP40S2...
Page 7 Introduction DMP40, DMP40S2...
Page 8 DMP40, DMP40S2...
Page 9: Safety Instructions
All existing regulations must be complied with. Attention must be drawn to residual dangers associated with measuring equipment. After setting up and password protected activities, ensure that any controllers that may be connected are in a safe status, until the switching behaviour of the measuring amplifier has been tested. DMP40, DMP40S2...
Page 10 Warns of a potentially dangerous situation in which failure to comply with safety requirements can lead to death or serious physical injury. CAUTION Symbol: Meaning: Possibly dangerous situation Warns of a possibly dangerous situation in which failure to comply with safety requirements could cause damage to property or result in some kind of minor physical injury. DMP40, DMP40S2...
Page 11 Any modification precludes liability on our part for any resulting damage. In particular, all repairs and soldering work on motherboards (replacement of components other than EPROMs) are prohibited. When replacing complete modules only original HBM parts may be used. Qualified personnel are persons who are entrusted with the installation, assembly, commissioning and operation of the product and who possess the appropriate professional, trade or craft qualifications.
Page 12 The amplifier complies with the safety requirements of DIN EN 61010, Part 1 (VDE 0411, Part 1); Protection Class I. To ensure sufficient electromagnetic immunity, it is essential to use Greenline shielding only (see HBM brochure "Greenline shielding design"; internet download http://www.hbm.com/Greenline).
Page 13: Notes On The Documentation
The page numbering consists of a capital letter (corresponding to the chapter heading) and a number. • Chapter D Functions and symbols on the DMP explains the display and the control keys • Chapter F Menu structure gives an overview of the selection and setup windows DMP40, DMP40S2...
Page 14 This section gives a clear explanation of how the DMP amplifier works. You can connect as many as eight sequentially selectable channels to the DMP40. Connected transducers (operat ing on the SG principle) are excited with a 225 Hz carrier frequency. Since all the transducers are connected to the excitation voltage at the same time and are therefore constantly "warmed up", as soon as you switch to the next...
Page 15 Desktop housing with 1 or 2 amplifiers (w x h x d): 458 mm x 171 mm x 367 mm Alternative version Number of amplifiers Max. number of channels Power supply DMP40 230 V/115 V DMP40S2 230 V/115 V DMP40, DMP40S2...
Page 16 RS−232/422/485 Synchronization port AP40 interface card Connection board for Pt100, AP 42 Pt500, Pt1000, DC voltage Control inputs sources and outputs DMP40S2 only Power Amplifier 2 Amplifier 1 pack Display With devices up to Ident No. 122820045 only. DMP40, DMP40S2...
Page 17 CP12 AP42 SY 02 Transducer ports Transducer ports Channels 1.1...1.8 Channels 2.1...2.8 Ident No. (DMP40S2 only) Mains Outputs IEEE488 interface Outputs Blanking plate connection Amplifier 1 Amplifier 2 Chassis ground With devices up to Ident No. 122820045 only. DMP40, DMP40S2...
Page 18: Conditions On Site
Protect the amplifier from humidity or atmospheric influences such as rain, snow and so on. • Please ensure that the ventilation openings in the side and the power pack fan vents in the back of the amplifier are not covered up. DMP40, DMP40S2...
Page 19: Maintenance And Cleaning
Clean the housing with a soft, damp (not wet) cloth. Never use solvents, since these can damage the display field as well as the makings and labeling on the front panel. • Make sure that no liquids find their way into the amplifier or its connection ports in the course of cleaning. DMP40, DMP40S2...
Page 20 Introduction ➝ Mechanical structure A 14 DMP40, DMP40S2...
Page 21 Connecting up DMP40, DMP40S2...
Page 22 DMP40, DMP40S2...
Page 23: Mains Connection
In factory set up ( ) the earthing switch connects zero operating voltage to the protection circuit. If external devices (transducers, computers) already make this link, giving rise to earth circuits (hum pickup), the earthing switch should be opened ( DMP40, DMP40S2...
Page 24: Connecting Transducers
You can connect SG transducers to the DMP amplifier in a full bridge network. In addition you can connect one Pt100, PT500, Pt1000 thermistor or one DC voltage source ("10 V) via the AP40 connection board. Type of connection Connect SG transducers in six wire mode. DMP40, DMP40S2...
Page 25: Terminal Plate
Wiring colours: wh= white; bk= black; bu= blue; rd= red; ye= yellow; gn= green; gy= grey The LEDs above the port jacks indicate the operating status of the channel: LED on (green) = channel active LED off = channel inactive DMP40, DMP40S2...
Page 26: Auxiliary Inputs
Excitation voltage Sensor circuit Pt100 Pt500 Pt1000 Cable shielding Hsg. Sensor circuit Excitation voltage The LED above the port jack indicates the operating status of the channel: LED on (green) = channel active LED off = channel inactive DMP40, DMP40S2...
Page 27 The synchronization jacks have the same features, so it is equally valid which of the two you use as input or output. Set the switch on one device to MASTER, and on all the others to SLAVE. Use synchronization cable Kab251−0,5 (accessories). Synchronization jack DMP40, DMP40S2...
Page 28 20 Limit value output 1 21 Limit value output 2 22 Limit value output 3 23 Limit value output 4 24 Warning OUTPUT 25 Analog ground The signals for control inputs are freely definable (factory set up is the specified default). DMP40, DMP40S2...
Page 29: Control Inputs
Input is switched to the measuring signal Input is switched to the zero signal Control outputs: Function Level 0 V Level 24 V Limit val. Limit switches OFF Limit switches ON Warning Device not ready or error (e.g. overload) No error DMP40, DMP40S2...
Page 30 0.5 A. Circuit diagram of the control inputs: Control inputs 1 ... 8 External AP42 2.5 k +24 V approx. 5.6 V 12mA 36 V − DMP40, DMP40S2...
Page 31 Commissioning DMP40, DMP40S2...
Page 32 DMP40, DMP40S2...
Page 33 • Unpack the DMP. • Check the DMP for damage. • Is the delivery complete? • Compare the contents of packages with the enclosed documenta tion list. Is the documentation complete? DMP40, DMP40S2...
Page 34 Connect the DMP to the mains supply with the mains cable provided. • The power pack for the DMP amplifier is designed for 230 V or DMP40 Initializing 115 V connection. Adaptation to the existing mains supply voltage is automatic. •...
Page 35 We recommend that you only set up the dialog language of you want to use a language other than English. Check Acal Channel Amplifier Display Print System F keys Password Language Save/Recall Time Version LANGUAGE Language: English ↓ Deutsch English DMP40, DMP40S2...
Page 36 Commissioning ➝ Switching on DMP40, DMP40S2...
Page 37: D Functions And Symbols On The Dmp
Functions and symbols on the DMP DMP40, DMP40S2...
Page 38 DMP40, DMP40S2...
Page 39: Control Elements On The Dmp40
Operation Ý Control elements Control elements on the DMP40 Clear key Cursor keys and Clears the whole of the entry in the confirmation key ( edit fields Alphanumeric Channel selection keys Measuring mode: Signal selection (absolute, gross, net) They select the active channel...
Page 40 Pressing this shift key takes you from one operating mode to the other, i.e. from measuring mode to set up mode and vice versa. Control keys for measuring mode Control keys for set up mode Green border Black border DMP40, DMP40S2...
Page 41: Display
The first display After switching on the mains supply (after about 10 seconds) the initial izing of the DMP40 is shown on the display by a horizontal bar. You are DMP40 Initalizing also given information on the current software version.
Page 42: Display In Measuring Mode
On changing the display format, the screen number is briefly shown in the status line. You can define up to ten display formats and allocate a "Screen number". Setting the display format options is covered in detail in Chapter 2.4, Page E 27. DMP40, DMP40S2...
Page 43 • Function key F1 − F5 trigger the assigned function (e.g. tare, calibrate, etc.). Function key F4 as set up in the factory switches between the unscaled value (Abs; mV/V) and the scaling in the physical unit. DMP40, DMP40S2...
Page 44: Status Line
Display of "2 values" screen type Measured value Unit Output signal Channel name Absolute (freely selectable) Gross Meas. value line 1 Number of chan nels selected Meas. value line 2 Status line Meas. Acal OFF Check F key assignment Activation message DMP40, DMP40S2...
Page 45 Example: User defined scaling Absolute Zero value=0.5 mV/V Gross Tare value=0.25 mV/V mV/V 0.75 (relative to zero value 0.25mV/V) For this example, the following values appear in the display: Absolute 1.5 mV/V Gross 1.0 mV/V 0.75 mV/V DMP40, DMP40S2...
Page 46 Example: On value of limit value switch 1 is exceeded Low pass filter is in the transient phase. In this state, the displayed value is not valid! In this field, activation or status messages (e.g. clr min/max(clear peak values), calibrate, ...) ap pear briefly DMP40, DMP40S2...
Page 47: Setup Mode
DMP40, DMP40S2...
Page 48 Pull up menu Amplifier Channel F keys Password Setup window Language Save/Recall Setup level 1 Time Password Version Channel Amplifier delete User: Password: modify Setup level 2 Access: Define User Set.. Amplifier Channel User: Password: Authority: Operator Cancel Setup window DMP40, DMP40S2...
Page 49: Setup Window
The current setup window can lead to other setup levels. Selection level 1 Channel Amplifier Display Print System Selection bar F keys Selection level 2 Password Pull up menu Highlight Language Save/Recall Time Version Setup level 1 English ↓ English Selection window English DMP40, DMP40S2...
Page 50: Quit Setup Window
Selection level 1 Selection level 2 Amplifier Channel F keys Password Setup level 1 Language Password Save/Recall Time nelete User: Version Channel Amplifier Password: modify Setup level 2 Access: Define User Set.. Amplifier Channel User: Password: Authority: Operator Cancel DMP40, DMP40S2...
Page 51 All settings, which you made before the security prompt are stored temporarily in the RAM as soon as you have made a change and confirmed with . Data is saved permanently, as soon as you confirm with "Yes" at the se curity prompt on quitting set up mode. Volatile memory (8hrs) Save EEPROM Permanent save DMP40, DMP40S2...
Page 52: Selection Menus
The field selected is displayed inversely. Confirm your selection with . Pull up menus can be scrolled, i.e. hav ing gone right through the menu, you return to the first selection again. The item last selected with the highlight is saved. DMP40, DMP40S2...
Page 53: Setup Window
The field selected is displayed inversely. After pressing the confirm key, the selection field opens up. Using the cursor keys select and confirm your setting with . In the documentation (not on the display), such fields are indicated by downward pointing arrows↓ . DMP40, DMP40S2...
Page 54 • Buttons Example: change... Cancel The field selected is displayed inversely. Confirm with . Three dots (change ...) follow the button designation which appear after confirming another setup window. DMP40, DMP40S2...
Page 55: E Setting Up The Dmp
Setting up the DMP DMP40, DMP40S2...
Page 56 DMP40, DMP40S2...
Page 57: Setting Up The Amplifier
’Limit values, Min/Max Store ’Remote control contacts, etc. ’Setting up display formats Range Range System settings Scal./Linear Scal./Linear Zero/Tare Zero/Tare Filter Filter Press shift key and return to measuring mode Min/Max Store Min/Max Store Limit Values Limit Values Copy Copy DMP40, DMP40S2...
Page 58 6. Press the confirmation key to open the "Range" setup window. 7. Press the confirmation key to open the "Range:" selection box. 8. Select 2.5mV/V from the selection box and confirm with 9. Use to change to the "Channel" pop up menu. DMP40, DMP40S2...
Page 59 0.000 measure 1st pt. 50.000... 2.000 measure 2nd pt. Save 12. Select with the cursor keys and confirm with enable the settings. 13. Use the shift key to change to measuring mode. 14. Confirm the security prompt with DMP40, DMP40S2...
Page 60: Measuring Range
The maximum accuracy specified in the Technical Data is only reached with the settings: Excitation voltage=10 V and Range=2.5 mV/V. RANGE CHANNEL 1.1 6 wire ↓ The excitation voltage is set to 2.5V Range: 5 mV/V ↓ 2.5 mV/V 4 wire 5 mV/V 6 wire 10 mV/V DMP40, DMP40S2...
Page 61: Scaling And Linearization
Num.precision 0.000000... 0.000000... measure 6th pt. Number of decimal places in the display. 0.000000... 0.000000... measure 7th pt. 0.000000... 0.000000... measure 8th pt. 0.000000... 0.000000... measure 9th pt. 10th pt. 0.000000... 0.000000... measure 11th pt. 0.000000... 0.000000... measure DMP40, DMP40S2...
Page 62 0.000000... 0.000000... measure 9th pt. 10th pt. 0.000000... 0.000000... measure mV/V 11th pt. 0.000000... 0.000000... measure Characteristic curve of the transducer Linearized characteristic curve Enter the points of the curve in ascending order (in the mathematically positive direction). DMP40, DMP40S2...
Page 63: Setting Zero/Taring
Limit Values Copy The concepts "zero value" and "tare value" are explained in chapter 2.2, page D 9 with an example. ZERO AND TARE VALUES CHANNEL 1.1 0.000000... mV/V Zero Zero value: 0.000000... mV/V Tare value: Tare DMP40, DMP40S2...
Page 64: Low Pass Filter
The Bessel characteristic exhibits a step response with very little (<1 %) or no overshoot. The amplitude response falls away less steeply. Each amplifier has two defaults (Lowpass 1, Lowpass 2), and only one filter is active. Bessel DMP40, DMP40S2...
Page 65 6. When you want to return to measuring mode, press shift key 0.02 ↓ Bessel ↓ Filter 1 3dB cut off frequency: Butterw ↓ and confirm the security prompt with Filter 2 3dB cu toff frequency: 10↓ Bessel Butterworth 0.03 0.05 0.22 0.45 0.90 11 0 DMP40, DMP40S2...
Page 66: Switching Filters
You can switch between the preset filters: − In measuring mode via the function key (factory set up , 2nd level). − Via the remote control contacts, when remote control is on. − With the command "AFS" (Computer control, Part 2). DMP40, DMP40S2...
Page 67: Min / Max Store
Min / Max storage Display Peak to peak (Envelope) In the case of rapid dynamic signals, you must take into account that peak values are defined in the time slot of the currently selected filter (1.2 Hz − 75 Hz). DMP40, DMP40S2...
Page 68: Deactivate / Delete Min/Max Store
1. Using a function key (factory set up ,/2nd level). 2. Using remote contacts CPV1/CPV2, if the device is set up for re mote control. Maximum Minimum 3. Using a computer with the command "CPV". Peak to peak DMP40, DMP40S2...
Page 69: Controlling Min / Max Storage
CPV: is used for deleting the min/max store HLD: freezes the current content of the store or releases it You can carry out other functions with these remote control elements, such as, for example, storing the instantaneous value. DMP40, DMP40S2...
Page 70: Peak Value" Operating Mode
Peak/instantaneous Run/Hold Function value Store1 =AP42, Pin 4 Store1=AP42, Pin 5 Function Hold Store2=AP42, Pin 18 Store2=AP42, Pin 19 Instantan Operating eous Min/Max Min/Max: mode value Memory running in 24 V selected direction with Freeze value 24 V DMP40, DMP40S2...
Page 71: Instantaneous Value" Operating Mode
Control circuit Control circuit Run/Hold Peak/instantaneous value Function Store1 =AP42, Pin 4 Store1 =AP42, Pin 5 Hold Function Store2=AP42, Pin18 Store2=AP42, Pin 19 Instantaneous Operating value mode Instantaneous value: memory running in either direction with Freeze value 24 V DMP40, DMP40S2...
Page 72: Envelope Operating Mode
In general terms, you get usable envelopes with a time con stant which is approximately 10 times the basic frequency period (t= 10 Time constant: OK Time constant: too large Time constant: too small DMP40, DMP40S2...
Page 73: Limit Values
The factory setting is a hysteresis of 1 % (limit values 1 and 2 below the On value, limit values 3 and 4 above the On value). DMP40, DMP40S2...
Page 74: Deactivate Limit Value Switches
Channel 1.1 shift key to change to measuring mode (confirm the security 1 . . Limit values No ↓ Enable limit switch prompt with Gross ↓ Source On value 2.550000 ... mV/V Off value 2.525000 ... mV/V gross DMP40, DMP40S2...
Page 75: Adjusting Limit Values
LIMIT VALUE SWITCH 1 Channel 1.1 Source 1 . . Limit switches Selects the signal source that you want to monitor (absolute/gross/ No ↓ Enable net/) Gross ↓ Source On value 2.550000 ... mV/V Off value 2.525000 ... mV/V gross DMP40, DMP40S2...
Page 76 Example: Limit value switches 1 and 2 enabled If the On value set for a limit value switch is exceeded, the switch num ber is highlighted in white on the display. Example: On value for limit value switch 1 is exceeded DMP40, DMP40S2...
Page 77: Copy
1...8 those channels (n), deren ) whose settings are to be overwrit COPY THE CHANNEL SETTINGS 1.1 ↓ ten. Confirm with Copy from channel to channels: 1. 1 2 3 4 5 6 7 8 > 6. Use to select the "OK" button and confirm with DMP40, DMP40S2...
Page 78: Amplifier Settings
The maximum accuracy specified in the Technical Data is only reached with the settings: excitation voltage=10 V and range=2.5 mV/V. EXCITATION VOLTAGE Attention: Amplifier input range may be effected! 2nd amplifier: 5.0 V↓ 1st amplifier: 5.0 V↓ 2.5 V 5.0 V 10.0 V DMP40, DMP40S2...
Page 79: Selecting A Channel
(max. 10 characters). In the factory set up, the first digit represents the amplifier and the second digit the channel (2.3 = amplifier 2, chan nel 3). DMP40, DMP40S2...
Page 80: Remote Control Contacts
DMP amplifier by means of 24 V control signals (see also Chap. 4, page B 8). The remote control contacts are only active if remote control is ON (REMT). Assignment of the remotes can be freely chosen. DMP40, DMP40S2...
Page 81: Display Format
Meas. Acal Off simply types, and can be selected in the setup window. Acal Check Appearance • 1 value (with/without status line; with/without header) Type 2 values • 2 values (with/without status line) Meas. Acal Off Check Acal DMP40, DMP40S2...
Page 82: Switching Filters
Acal 2. Press Display 3. Confirm with You are now in the "Display format" setup window. Display DISPLAY FORMAT one value 1 ... Screen No.: One value ↓ Type: Channels/Signals: all↓ selection... Header: ext.temperature↓ On ↓ Status line: DMP40, DMP40S2...
Page 83: Setup Window Components
DISPLAY FORMAT two values "2 values" 0 ... Screen No: two values ↓ Type: 1st value (base): all↓ selection... Channels/Signals: 2nd value: Channel signal base ↓ base ↓ channel: unit On ↓ Channel name: On ↓ Status line DMP40, DMP40S2...
Page 84 1st value (base). Input absolute to base: the value entered is identical to the channel number, e.g. "1.5" . The measured value and the signal type are dis played regardless of the base. DMP40, DMP40S2...
Page 85 In order to display the channels of the second amplifier, it only makes sense to input the numbers −2 ...−9 and +7 ...+14 in the "Display" edit field. The input was actually 7. Selected base Input in the "Channel:" edit field −9 −2 Amplifier 1 2nd amplifier (DMP40S2 only) Channel: DMP40, DMP40S2...
Page 86 SELECTION OF CHANNELS / SIGNALS Value 1 Channel 1. Channel 2. 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Value 2 gross gross gross Meas. Check DMP40, DMP40S2...
Page 87 "Udim" user defined scaling, you can accept the unit of measure of the base (Base) or invert it (Toggle). Toggling means changing between base units, e.g. if the base unit is mV/V then the unit "Scaled" is dis played for the second value and vice versa. DMP40, DMP40S2...
Page 88 Min/Max Store (Minimum/Maximum) • Range and excitation voltage • External voltage • External resistance • External temperature Status line Fades the status line in or out of the display. The details on the status line refer to the 1st value. DMP40, DMP40S2...
Page 89: Print
For printing, you can assign two function keys to the "Print" function (see "System, F keys"; page E 37). Example 1: Printout of "Display" DEFINE PRINT SCREEN 1.1 1.1−DMP40 15862 ppm Gross 23−Jul−96 11:06:12 F−key ’Print_S1’ prints: Act.screen↓ Measure Filt: 0.22 Hz Be AutoCal: On LV:1=0,2=0,3=0,4=0 F−key ’Print_S2’...
Page 90: Printout Parameters
Amplifier parameters Example 3: Printout the parameters 1 2 3 4 5 6 7 8 Channel parameters System Parameter: −−−−−−−−−−−−−−−−− Display parameters Print parameters System version : DMP40,P10 Dialog language: English Time : 11:00:59 Date : 23−07−96 User : HBM Password...
Page 91: Function Keys
F5 . . . (move to next level) F keys − Level 3 • F1 Auxiliary channels • F2 Printout parameters • F3 Print screen 1 Acal Off Meas. • Aux−Chan P−print Print−S1 Print−S2 F4 Print screen 2 • F5 . . . DMP40, DMP40S2...
Page 92 If you have defined the function for . . . all channels, this is shown by the symbol in the top right hand corner of the F key field. The "Taring" function being defined for all channels DMP40, DMP40S2...
Page 93 When the polarity is inversed, the effect will P print (print instrument settings) Print S1 (print defined screen) also be present at the serial and parallel interfaces. Print S2 (print defined screen) one channel all channels DMP40, DMP40S2...
Page 94: F Keys In Set Up Mode
F keys 2.6.2 F keys in set up mode In set up mode use the function keys to call the pop up menus on the F keys Password menu bar. Language Save/Recall Time Version Channel Amplifier Display System Print DMP40, DMP40S2...
Page 95: Password
Operator (only enabled settings can be changed) You can define a password and access authorisation for a maximum of 9 users. Important: password protection can only be switched on if at least one new user is defined with the "System" access authorisation. DMP40, DMP40S2...
Page 96: Defining New Users
"Access" selection field, select the required PASSWORD new... delete... User: access authorisation and press to confirm. modify.. Password: 8. Use to select the "OK" button and confirm with set... Access: Define user User: Password: Operator Access: Cancel Operator System DMP40, DMP40S2...
Page 97: Switch On Password Protection
Print Screens Parameters message. Select with and press again. Press System F keys twice. You are now in the "PASSWORD" setup window. Password Language Now define a user with system privileges as described in Chapter 2.7.1. Save/Recall Cancel DMP40, DMP40S2...
Page 98: Set Access Privileges For Operator
(jump to OK button) and confirm with Copy Amplifier Excitation voltage Channel select Remote contacts Display Display When you want to return to measuring mode, press shift key Print Screens Parameters confirm the security prompt with System F keys Password Language Save/Recall Cancel DMP40, DMP40S2...
Page 99: Delete User
"delete..." button behind the required user and press to confirm. PASSWORD 6. Press (jump to OK button) and confirm with new... delete... User: modify.. Password: set... Access: Delete user Miller delete User1: Meyer delete User2: delete User3: User9: delete Cancel DMP40, DMP40S2...
Page 100: Change Password
"modify..." button and press to confirm. Version 5. In the edit field and press to confirm. 6. Press (jump to OK button) and confirm with PASSWORD new... delete... User: modify.. Password: set... Access: Modify password New password: Cancel DMP40, DMP40S2...
Page 101: Language
E 47 Language Language You can use this function to select the language for the display, menus and help texts. DMP40, DMP40S2...
Page 102: Save/Recall
You are now in the setup menu "Save/recall settings". Load factory settings 4. Use to select the required button and press to confirm. 1st amplifier Display Channel 1. 1 2 3 4 5 6 7 8 > Cancel DMP40, DMP40S2...
Page 103 (n), deren Werkseinstellungen ) whose factory settings are to be recalled, or select the key symbol "All". Confirm with 6. Use to select the "OK" button and confirm with When you want to return to measuring mode, press shift key confirm the security prompt with DMP40, DMP40S2...
Page 104: Time
Use this function to set up the date, day and time. Check Acal Channel Amplifier Display Print System F keys Password Language Save/Recall Time Version SET DATE/TIME Day ... Month ↓ Year ... Date: Friday ↓ Day: Hour ... Min ... Sec ... Time DMP40, DMP40S2...
Page 105: Version
2.11 Version The header in the "Version" setup window shows the system version. Check Acal The lower line shows the type name and program version of the selec ted amplifier (e.g. HBM, RD40−DMP40, 0, P00). Channel Amplifier Display Print System...
Page 106 E 52 Version DMP40, DMP40S2...
Page 107: Menu Structure
Menu structure DMP40, DMP40S2...
Page 108 DMP40, DMP40S2...
Page 109 Selection bar The lines in the pull up menu are displayed in If the menu does not fit sequence. on one page, it is split. Circled letters guide you to the next page. Setup window ↓ Selection field DMP40, DMP40S2...
Page 110 Menu Symbols mV/V ↓ Selection field 0.000000... Edit field measure Button Activation fields Cursor keys Arrows show the direction in which the keys work DMP40, DMP40S2...
Page 111 4th pt. 0.000000... 0.000000... measure 5th pt. 0.000000... 0.000000... measure 6th pt. mbar 0.000000... 0.000000... measure 7th pt. 0.000000... 0.000000... measure 8th pt. 0.000000... 0.000000... measure 9th pt. µm 0.000000... 0.000000... measure 10th pt. 0.000000... 0.000000... measure 11th pt. DMP40, DMP40S2...
Page 112 2nd store envelope: FILTERS CHANNEL 1.1 0.02 ↓ Bessel ↓ Filter 1 −3dB cut off frequency: Maximum 0.45 ↓ Butterworth Filter 2 −3dB cut off frequency: Minimum ↓ Peak to peak Bessel Butterworth 0.03 0.05 0.22 0.45 0.90 11.0 DMP40, DMP40S2...
Page 113 Copy from channel No ↓ Enable limit switch gross ↓ to channels: Source 1. 1 2 3 4 5 6 7 8 > ✓ ✓ ✓ On value 2.550000 ... mV/V Off value 2.525000 ... mV/V gross PVM1 PVM2 DMP40, DMP40S2...
Page 114 Remote 4: FREQ−filter1/2 Remote 5: CPV1−instantaneous/peak 1 CHANNEL NAMES,CHANNEL SELECT Remote 6: HLD1−hold peak store 1 enabled ↓ Channel 1.1 1.1−DMP40 ... Remote 7: CPV2−instantaneous/peak 2 enabled ↓ Channel 1.2 1.2−DMP40 ... 2.5 V Remote 8: HLD2−hold peak store 2 5.0 V...
Page 115 Min/Max display Range/Excitation mV/V ext. voltage scaled ext. resistor base ext. temperature toggle SELECTION OF CHANNELS / SIGNALS Cancel All channels All signals Channel 1. 1 2 3 4 5 6 7 8 gross gross base base+1 base+2 DMP40, DMP40S2...
Page 116 Act.screen↓ 1 2 3 4 5 6 7 8 Channel parameters Display parameters Print parameters ✓ ✓ Act.screen Screen 1 Screen 2 Screen 3 Screen 4 Screen 5 Screen 6 Screen 7 Screen 8 Screen 9 Screen 10 DMP40, DMP40S2...
Page 117 −>T<− (taring) −>0<− (zero balance) Autocal (autocalibr. on/off) Check (zero/cal/measure signal) Start/Stop (start/stop meas.) aux chan (special channels) P print (print instrument settings) Print S1 (print defined screen) Print S2 (print defined screen) one channel all channels DMP40, DMP40S2...
Page 118 Amplifier Excitation voltage New password: Miller delete User1: Channel select Operator Authority: Remote contacts Cancel delete Meyer User2: Cancel Display Display delete Print Screens User3: Parameters Operator System System F keys Password User9: delete Language Save/Recall Cancel Cancel DMP40, DMP40S2...
Page 119 Recall Friday Day: External Hour ... Min ... Sec ... Time Load factory settings DMP40 Version 1st amplifier Display Channel 1. 1 2 3 4 5 6 7 8 > 1st amplifier: HBM, RD40 DMP40, 0, Pxx Cancel DMP40, DMP40S2...
Page 120 F 14 Menu DMP40, DMP40S2...
Page 121: Technical Data
Technical Data DMP40, DMP40S2...
Page 122 DMP40, DMP40S2...
Page 123: Amplifier Plug In Units
Permitted relative humidity at 31 °C (non condensing) with lin ear reduction to 50 % at 40 °C. With excitation voltage 10V; range 2.5mV/V; transducer resistance 350Ω; length of cable <10m With irradiation in accordance with EN 50082−1 DMP40, DMP40S2...
Page 124 Dimensions (W x H x D) 458 x 171 x 367 Connection for Transducers 8 x DB 15S 2 x 8 x DB 15S Limit value outputs, remote inputs DB 25S Computer interface RS232 DB 9S Computer interface RS422/485 DB 9S DMP40, DMP40S2...
Page 125: H Index
Index DMP40, DMP40S2...
Page 126 DMP40, DMP40S2...
Page 127 Connecting transducers, B 4 Activation fields, D 17 , F 4 Connecting up, B 1 Activation messages, D 10 Control elements on the DMP40, D 3 Adjusting limit values, E 21 Control inputs, B 9 Alternative version, A 9 Control keys for measuring mode, D 4 Amplifier settings, E 24 Control keys for set−up mode, D 4...
Page 128 Measuring range, E 6 Menu structure, F 1 Gross value, D 9 Min / Max store, E 13 Header, E 34 Net value, D 9 Housing, A 9 , A 12 , A 13 Num.precision, E 7 Hysteresis, E 19 Input DMP40, DMP40S2...
Page 129 E 29 SG full bridges, B 5 Signal, E 33 Signal type, D 9 Remote control contacts, E 26 Status line, D 10 , E 34 Remotes, B 8 Step, E 7 Residual dangers, Residual dangers, A 3 DMP40, DMP40S2...
Page 130 Synchronization cable, B 7 Unit, E 8 , E 33 Synchronizing several devices, B 7 Version, E 51 Tare value, E 9 Technical Data, G 1 The first display, D 5 Time, E 50 Zero value, E 9 DMP40, DMP40S2...
Page 132 They are not to be understood as express warranty and do not constitute any liability whatsoever. Postfach 10 01 51, D 64201 Darmstadt Im Tiefen See 45, D 64293 Darmstadt Tel.: +49/61 51/8 03 0; Fax: +49/61 51/ 8039100 B0396 4.0 en E−mail: support@hbm.com www.hbm.com...
Page 133 Operating Manual Digital precision measuring amplifier DMP40, DMP40S2 Operation with computer or terminal B0396 4.0 en...
Page 135 ........... . IEEE 488 interface function in HBM devices .
Page 136 E 14 4 .2 Address setting on the DMP40 ........
Page 137 ............G 12 Communication computer − DMP40 ....... . .
Page 138 Contents Appendix III: Glossary Appendix IV: Alphabetical summary of commands Appendix V: Summary of commands by function Appendix VI: Index to keywords Operation with computer or terminal...
Page 139: A Introduction
Introduction Operation with computer or terminal...
Page 140 Operation with computer or terminal...
Page 141: Summary Of Documentation
Introduction Ý Summary of documentation Summary of documentation The following publications comprise the complete product documentation of the DMP40/DMP40S2 precision mea suring amplifier: The Operating Manual explains to you how to operate the amplifier manually Operation with computer or terminal...
Page 142: How To Use This Manual
The contents list at the beginning of the manual gives you an initial overview. • The header tells you which chapter or sub section you are currently reading. Example: HBM Interpreter commands Data output structure The manual’s title (Operation with computer or terminal, User Manual, ...) appears in the footer. •...
Page 143: Operation With Computer Or Terminal
Introduction Ý Summary of documentation Operation with computer or terminal This manual explains how to operate your HBM amplifier with a terminal or computer. • With a terminal, dialogue with the DMP amplifier is possible. • You can effect all device settings by sending an appropriate command sequence from the computer. With a computer and the appropriate programs recurrent measurement sequences can be automated.
Page 144: Summary Of Chapters And Appendices
Introduction Ý Summary of documentation 1.2.1 Summary of chapters and appendices Chapter A Introduction General notes on using this manual. The documentation summary lists for you all the documents pertaining to the DMP system. Chapter B The RS 232C, RS 485 and IEEE 488 78 interfaces compared This tells you which interfaces are incorporated in the DMP amplifier and the essential differences between them.
Page 145 Chapter G HBM Interpreter commands Important conventions governing the syntax, structure and notation of commands are highlighted. The complete HBM Interpreter command set completes this chapter. Appendix I Program versions Alterations in the present CP12 program version P17 relative to older versions are listed here.
Page 146 Introduction Ý Summary of documentation Appendix IV Alphabetical summary of commands The alphabetical summary of commands helps you find your way about more quickly. Appendix V Summary of commands by functions You can also access a summary of commands arranged by functions. Appendix VI Keyword index Note:...
Page 147: B Interfaces Compared
Interfaces compared Operation with computer or terminal...
Page 148 Operation with computer or terminal...
Page 149 Interfaces compared The DMP40 incorporates three different interfaces: • an RS 232 C, • an RS 485 and • an IEEE 488 78. At any one time the device can be operated through one interface only; each has certain advantages but also disadvantages.
Page 150 Interfaces compared IEEE 488 78 interface (Chapter D) Parallel data transfer • Transmission rate relativly "high". • Several devices can operate in a link up. Data transfer is faster than when using a serial interface. The maximum transmission rate for measured values is no higher than when communication is serial (at least 9600 baud).
Page 151: Crs 232/Rs 422/485 Serial Interfaces
RS 232/RS 422/485 serial interfaces Operation with computer or terminal...
Page 152 Operation with computer or terminal...
Page 153: Rs 232C And Rs 42/485 Interfaces
RS 232C/RS 485/422 serial interfaces RS 232C and RS 42/485 interfaces Both interfaces are designated serial interfaces since data is transferred in sequence, bit by bit. They differ in the voltage level used and in construction; the RS 232C interface is suitable for point to point connections, the RS 422/485 for bus operation.
Page 154 RS 232C/RS 485/422 serial interfaces Data transfer is controlled by means of the software handshake X ON (DC1) and X OFF (DC3). If the computer is ready to receive data, it sends the control character X ON (DC1) down the data line. If it cannot accept data, e.g.
Page 155: Rs 422/485 Bus
The bus shown here is an extension of the RS 422 interface permitting − unlike the latter − more than one trans mitter. Each DMP40 has a receiver and a transmitter; the transmitter can be switched on or off with the SELECT commands.
Page 156 RS 232C/RS 485/422 serial interfaces Operation with computer or terminal...
Page 157: Dieee 488 78 Parallel Interface
IEEE 488 78 parallel interface Operation with computer or terminal...
Page 158 Operation with computer or terminal...
Page 159: Ieee 488 78 Bus
24 pin Amphenol connector conforming to the US Standard and the 25 pin subminiature D connector conforming to the international IEC 625 Standard. Electrically the two connectors are equivalent; on the PI12 connection board HBM use the 24 pin Amphenol connector.
Page 160: Addressing
IEEE 488 78 parallel interface→ Addressing Addressing Each of the devices functioning together in a link up must have its own address so that they can be correctly distin guished by the controller. These addresses are generally set with a switch and numbered consecutively from 0 to 30. Each device can be addressed at its individual address.
Page 161: Service Request (Srq)
IEEE 488 78 parallel interface Ý Service Request Service Request (SRQ) Each of the devices functioning together in a link up must have its own address so that they can be correctly distin guished by the controller. In a link up of several measuring amplifiers a measurement run can occupy a considerable time span. The control ler waits for this task to finish.
Page 162: Serial Poll (Spoll)
IEEE 488 78 parallel interface Ý Service Request Serial poll (SPOLL) If a Service Request occurs during a measurement, by initiating a serial poll the computer can identify the device which has caused the interrupt. The computer must address all devices and query the status value. By this means the computer can also determine the cause of the interrupt.
Page 163: Parallel Poll (Ppoll)
In a parallel poll the controller receives no indication as to the reason for the SRQ. If the controller transmits the identification command (EOI + ATN = IDY = True), the devices must set the data line assigned to them. HBM de vices are activated with the interface command PPM.
Page 164: Interface Commands
IEEE 488 78 parallel interface Ý Interface commands Interface commands These commands are not among the device commands described later. They apply to the IEEE interface only. The table below lists the most important of these commands. The commands are to be output via the interface as ASCII code. If this does not happen automatically in the com puter an appropriate translation routine is required.
Page 165: Ieee 488 Interface Function In Hbm Devices
IEEE 488 78 parallel interfaceÝ IEEE interface function IEEE 488 interface function in HBM devices Your device’s HBM Interpreter is equipped with the following interface functions: Interface function Abbreviation Meaning Source Handshake All functions are included. Acceptor Handshake All functions are included.
Page 166 D 10 IEEE 488 78 parallel interfaceÝ IEEE interface function Operation with computer or terminal...
Page 167: E Communicating With The Dmp
Communicating with the DMP Operation with computer or terminal...
Page 168 Communicating with the DMP ➝ HBM Interpreter Operation with computer or terminal...
Page 169: Hbm Interpreter
Communicating with the DMP ➝ HBM Interpreter HBM Interpreter The HBM Interpreter "translates" the command received from an interface and the associated character strings into a code understood by the DMP40. You can call the Interpreter via the RS 232C, RS 422/485 and IEEE 488 78 interfaces.
Page 170: Activation Of The Rs 232C Interface
Computer operation without echo means: The generated data but no command characters are returned to the computer by the DMP40. With the RS 232C interface each information item generated is output as soon as it is complete in the output buffer.
Page 171: Serial Poll (Spoll)
(enabled low, internal 10kOhm to +5V) Shield Container connection via bolt secured plug. No function in the DMP40 amplifier Note: This assignment differs from that of a PC. For this reason we recommend that you use the connection cable supplied.
Page 172: Setting The Interface
Communicating with the DMP ➝ Activation of the RS 232C interface 2 .2 Setting the interface With the eightfold DIP switch on the CP12’s connection board you can set the CP 12 baud rate and RS 232C parity. Baud rate Baud rate Bu21 RS 485...
Page 173: Activation Of The Rs 485 Interface
The HBM devices have been factory set to address "1". If several devi ces are being operated on this bus, they must be set to different addresses.
Page 174: Serial Poll (Spoll)
Container connection through bolted in plug. Bu22 Through the RS 485 interface (Bu22) you can connect the DMP40 to a computer and so address up to 32 devices. Use a cable with a 9 pin connector and unattached ends to do this. The unterminated cables are connected to the screw terminals of the SC232/422 serial converter.
Page 175 25 pin RS 232 serial converter RS 422 − RA RB TA TB Eop Supply voltage (9V DC) for the serial converter. A plug in power supply unit is supplied with the converter. Screw terminal DMP40 Operation with computer or terminal...
Page 176: Setting The Interface
Communicating with the DMP ➝ Activation of the RS 485 interface E 10 3 .2 Setting the interface An eightfold DIP switch on the connection board enables you to CP 12 set the device address, RS 232C baud rate and parity.
Page 177 Communicating with the DMP ➝ Activation of the RS 485 interface E 11 CP12 connection board TxD P RxD P Pin 4 SC232/422 RxD N Pin 9 TxD N Computer RS 232 DMP 0 RS 485 RxD P TxD P Pin 3 serial RxD N...
Page 178: Activation Of The Ieee 488 78 Interface
IEEE 488 78 interface is initialised) activates the HBM Interpreter together with the first command. The DMP40 is thus in remote control mode and, except for the screen’s display functions, cannot now be operated through the control panel on the front panel.
Page 179 The computer must respond to the message Data present with an INPUT or ENTER and accept the data. Only when all data items pertaining to a command have been output can the HBM device inter pret the next command. Errors are recorded in the Standard Event Status Register and can be queried with the HBM command *ESR?.
Page 180: Interface Assignment
Communicating with the DMP ➝ Activation of the IEEE 78 interface E 14 4 .1 Interface assignment IEEE 488 interface assignment PI 12 Remotes Assignment IEEE 488 78 DIO1 DIO2 DIO3 DIO4 NRFD NDAC Shield DIO5 DIO6 DIO7 DIO8 Ground 6 Ground 7 Ground 8 Ground 9...
Page 181: Address Setting On The Dmp40
Communicating with the DMP ➝ Activation of the IEEE 488 78 interface E 15 4 .2 Address setting on the DMP40 An eightfold DIP switch on the PI12’s connection board enables you to PI 12 set the device address and interface configuration.
Page 182 Communicating with the DMP ➝ Activation of the IEEE 78 interface E 16 Setting Talker/Listener: Switch only only Addressable allowed Listener Talker Factory setting Operation with computer or terminal...
Page 183: Connect The Computer To The Dmp
Connect the DMP40 and computer to the mains supply Leave DMP40 and computer switched off for the present RS 232C interface: • connect the DMP40 (Bu21, CP12) to the computer with the Kab 255−3 cable (supplied with the unit) • Set baud rate (9600*) •...
Page 184: Ieee 488 Interface
Communicating with the DMP ➝ Connection to the computer E 18 IEEE 488 interface: 24 pin 24 pin • connect the DMP40 (Bu1, PI12) to the computer with the Kab 0488−2 cable (not supplied with the unit) Kab 0488 2 • Set address: DMP40 PI12 plug 1.DMP40:...
Page 185: Program Creation
Program creation Operation with computer or terminal...
Page 186 Operation with computer or terminal...
Page 187: Ibm Pcs And Compatibles
Program creation ➝ IBM PCs and compatibles IBM PCs and compatibles To make embarking on program creation a little easier for you, you will find here the routines for programming the interfaces of IBM PCs and compatibles. Caution: • First attach all cable connections. •...
Page 188: Communicating Via The Rs 232C Interface
Program creation ➝ IBM PCs and compatibles Communicating via the RS 232C interface Connect the PC and the DMP40 using the Kab 255−3 cable and set the DIP switches as shown in the adjacent diagram. The interface has now been set to 9600 baud and no parity.
Page 189 47. SUB dmpcmd (wrt$) 48. PRINT "Command: "; wrt$, ’Display command on screen 49. PRINT #1, wrt$; ";" ’Transmit command to DMP40 50. LINE INPUT #1, rd$ ’Read response from DMP40 51. dummy$ = INPUT$(1, #1) ’Read end marker LF 52.
Page 190 Program creation ➝ IBM PCs and compatibles NOTES: 12. The control character CTRL R switches on the command interpreter in the measuring amplifier. At the end of the print command a termina ting sequence comprising the control characters CR (Carriage Return) and LF (Line Feed) is transmitted automatically.
Page 191 Program creation ➝ IBM PCs and compatibles 42.−46. With critical commands, e.g. after the command interpreter has been switched on, a delay routine can be used in order to wait until the measuring amplifier is ready again. 47.−53. In this sub program the command is transmitted to the measu ring amplifier, the response read in and both displayed on the screen.
Page 192: Communicating Via The Rs 485 Interface
Program creation ➝ IBM PCs and compatibles Communicating via the RS 485 interface Connect the PC to the DMP40. Device 1 Set the DIP switches on the CP12 connection board as shown in the adjacent diagram. The interface has now been set to 9600 baud and even parity.
Page 193: Communicating Via The Ieee Interface
Program creation ➝ IBM PCs and compatibles Communicating via the IEEE interface Setting of the GPIB board (IF488/PC2A) with National Instruments GPIB PC software to: GPIB0 Primary GPIB address 0 (other addresses also possible) Secondary GPIB address none T 10 µs Timeout setting EOS byte 00H (different byte also possible)
Page 194 Program creation ➝ IBM PCs and compatibles F 10 For the HBM device the following settings should be made: DEV4 Primary GPIB address: 04H Secondary GPIB address: none Timeout setting: T10s EOS byte: Terminate read on EOS no Set EOI with EOS on write...
Page 195 Connect the PC and DMP40 amplifiers using an IEEE connecting cable Device 1 (HBM cable: Kab 0488 2), and set the DIP switches LO, TO on the PI12 connection boards as shown in the diagram on the right. The interface has now been set to "addressable".
Page 196 Program creation ➝ IBM PCs and compatibles F 12 Operation with computer or terminal...
Page 197: Ghbm Interpreter Instruction Set
HBM Interpreter instruction set Operation with computer or terminal...
Page 198 Operation with computer or terminal...
Page 199: Important Conventions
HBM Interpreter instruction set ➝ Important conventions Important conventions These conventions and general notes make working with the HBM In terpreter commands easier for you. Notation • All commands can be input in lower or upper case. Short commands •...
Page 200 HBM Interpreter instruction set ➝ Important conventions Responses • The device’s responses shown in the examples are printed in italics. The responses are shown for one channel only. Character strings • For input purposes character strings must be enclosed in quotation marks.
Page 201 HBM Interpreter instruction set ➝ Important conventions I/O with numbers • Handling of numbers: under the IEEE488.2 Standard all numeric parameters can be input in floating point format even if they are integers or fixed point num bers. The numbers input are converted to the numeric format of the parame ter concerned and −...
Page 202 HBM Interpreter instruction set ➝ Important conventions Acknowledgement • You can choose whether or not the DMP40’s response to set up commands is output. Output commands, identified by a ? − always give rise to output data (see SRB command).
Page 203: Command Syntax
BDR4800(x) 0(y) The interface has been set to 4800 baud. • Query commands: Measured values or device settings are read from the DMP40 and ap pear on the screen. Example: BDR?(x) 4800,2,1,1(y) The RS 232 interface has been set to 4800 baud, even parity and 1 stop bit.
Page 204: Command Structure
HBM Interpreter instruction set ➝ Important conventions Command structure Short command Parameters End marker *TTT? p1, p2, ...pn Example: *PRE?(x) only in IEEE Standard commands Short command in alphabetical characters (a ... z) only in query commands p1, p2...pn Parameter value, consisting of opera ting sign (+/−) and digits (0...9) or...
Page 205 HBM Interpreter instruction set ➝ Important conventions ASCII character Carriage Return = decimal 13 ASCII character Line Feed = decimal 10 ASCII character semicolon = decimal 59 If an additional parameter − e.g. parameter 2 − is omitted, at least the separator must be input.
Page 206: Data Output Structure
*IDN?(x) HBM,CP12,0,P17(y) Example 2: CHS?0(x) 3(y) The responses sent by the DMP40 are printed in italics in this docu mentation (second line in the examples). Values output: q1,q2...qn Numerical values with sign, character strings (always in " ") or ’?’ as error si...
Page 207: The Commands Individually
Effect e.g. Explanation of how to set the DMP40. Response The DMP40 responds to your input. If you are operating through a terminal you will see this response on the screen (always with output commands, with input commands if required).
Page 208: Communication
(ASCII code 18 decimal) CTRL B: Start of communication via computer (ASCII code 2 decimal) After entering one of these control characters, the DMP40 can (with a few exceptions) no longer be operated via the front panel (’Remote’ display). CTRL A:...
Page 209 Instruction set for the HBM Interpreter ➝ Communication G 13 Device Clear Terminate communication Syntax: DCL (x) or with RS 232C / RS 485 control character CTRL A (ASCII code 01 decimal). Parameters: none Effect: Remote control operation is terminated.
Page 210 Effect: Depending on the interface selected, the relevant DMP40 address is output. The address is set with switches (A1 A5) on the CP12 connection board for the RS 485 interface and on the PI12 connection board for the IEEE interface. Both address settings are necessary for bus control.
Page 211 Instruction set for the HBM Interpreter ➝ Communication G 15 Example 1: Input of commands via RS 232C/RS 485 interface. ADR?(x) 1(y) Address 1 is set on the CP12 connection board (factory set up) for the RS 485 interface. Example 2:...
Page 212 With the Select command these addresses are mapped again on to addresses 32...63 and 64...95, i.e. the commands S00, S32, S64 actuate the DMP40 amplifiers with the address 00, but have a different effect on them Addresses 96...99 are provided for special functions.
Page 213 Instruction set for the HBM Interpreter ➝ Communication G 17 Explanation: S00...S31(x) Only the instrument with the specified address receives commands, executes them and responds. S32...S63(x) All instruments receive all commands and execute them. Only the in strument with the specified address (S32 = device 0) responds on behalf of all instruments.
Page 214 Instruction set for the HBM Interpreter ➝ Communication G 18 Response: none Example: S03(x) Device with the address 03 executes all commands and responds. S35(x) All devices at the bus receive all commands and execute them. Instrument with the address 03 (35 32) responds on behalf of all instruments.
Page 215 Instruction set for the HBM Interpreter ➝ Communication G 19 Channel Select Select amplifier channels The DMP40S2 has two amplifier channels, the DMP40 has one. Syntax: CHS p1(x) Parameters: Channel coding value 1 − 3 Channel combinations are set up using the total of the relevant channel coding values.
Page 216 Instruction set for the HBM Interpreter ➝ Communication G 20 Effect: The amplifier channels are selected according to the binary value of parameter p1. It is established in this way which amplifier channels are addressed by the following command. Response:...
Page 217 Instruction set for the HBM Interpreter ➝ Communication G 21 Channel Select Query CHS? Output of amplifier channels Syntax: CHS? p1(x) Parameters: present / selected channel numbers The channels present The channels selected Effect: The channels present and selected come from the total of the channel coding values.
Page 218 Instruction set for the HBM Interpreter ➝ Communication G 22 Example 1: Query: what channels are present in the device? CHS?0(x) 3(y) DMP40S2 is equipped with Channels 1 and 2. Example 2: Query: Which channels are selected? CHS?1(x) 1(y) Channel 1 is selected.
Page 219 Instruction set for the HBM Interpreter ➝ Communication G 23 Channel Multiplexer Select input Syntax: CHM p1(x) Parameters: Channel number 1 − 8 1 − 8 Note: All measurement parameters can change, as a new channel is selected with the command (filter setting, calibration, etc.)
Page 220 Instruction set for the HBM Interpreter ➝ Communication G 24 Reset Carry out warmstart Syntax: RES (x) Parameters: none Effect: The device carries out a warmstart. Communication is ended. Response: none Example: RES(x) Note: The RES command is an HBM command.
Page 221: Communication Computer − Dmp40
Instruction set for the HBM Interpreter ➝ Communication G 25 Communication computer − DMP40 Baud Rate Set baud rate of serial interface Syntax: BDR p1,p2,p3,p4(x) Parameters: É É É É p1 Baud rate Parity É É É É 1200 Even É...
Page 222 Acknowledgment Meaning Command has been executed Error Example 1: The DMP40 is operated via the RS 232C interface: BDR19200,2,1,1(x) 0(y) The RS 232C interface is set to 19200 Baud, Even Parity, 1 stop bit. Example 2: The DMP40 is operated via the RS 485 interface:...
Page 223 Response: q1,q2,q3,q4(y) Baud rate * Parity Stop bits Interface ID Example 1: The DMP40 is operated via the RS 232C interface: BDR?(x) 4800,0,2,1(y) The RS 232C interface is set to 4800 Baud, No Parity, 2 stop bits. Example 2: BDR?2(x)
Page 224 Instruction set for the HBM Interpreter ➝ Communication G 28 Internal Byte Query IBY? Baud rates/address switch query Syntax: IBY? p1(x) Parameters: DIP switch settings step width Carry out RAM test in CP12 Effect: On the CP12 or PI12 connection boards, there is an 8 way DIP switch for setting the address and interface configuration.
Page 225 Instruction set for the HBM Interpreter ➝ Communication G 29 Example 1: The positions of the DIP switches on the CP12 connection board correspond with the factory set up Baud rate EVEN PARITY ON The positions of the DIP switches on the PI12 connection board corre...
Page 226 Instruction set for the HBM Interpreter ➝ Communication G 30 Select Response Behavior Selection of behavior on acknowledgment of interface Syntax: SRB p1(x) Parameters: Switch acknowledgment output on/off Switch acknowledgment output off Switch acknowledgment output on Effect: There are two command types: Output commands (e.g.
Page 227 Instruction set for the HBM Interpreter ➝ Communication G 31 After switching the DMP40 on, the following default settings apply: Interface Note IEEE RS 232C RS 485 The IEEE interface gives no acknowledgments to set up commands. If there should be a response, this must be switched on with this command (SRB).
Page 228 The output behavior (acknowledgment on or off) of the interface is output (see SRB command). Response: q1(y) Switch acknowledgment output on/off Acknowledgment Off Acknowledgment On Example: The DMP40 is driven from the IEEE interface. SRB?(x) 0(y) Set up commands do not output a response. Operation with computer or terminal...
Page 229: Error Correction, Status Register
Instruction set for the HBM Interpreter ➝ Communication G 33 Error correction, status register Standard Event Status Register *ESR? Output of the event status register Syntax: *ESR? (x) Parameters: none Effect: Output of contents of standard Event Status Register (ESR) as decimal equivalent.
Page 230 Instruction set for the HBM Interpreter ➝ Communication G 34 Bits: 7 6 5 Standard Event Status Register *ESR? & & & & & & & & 7 6 5 Standard Event Status Enable Register *ESE,*ESE? Output buffer Bits: ESB MAV Status Byte Register *STB? &...
Page 231 Instruction set for the HBM Interpreter ➝ Communication G 35 Request Status: Request status: Service request has been made. Event Summary Bit: Summary of all the bits of the Standard Event Status Register enabled in the Standard Event Status Enable Register.
Page 232 Instruction set for the HBM Interpreter ➝ Communication G 36 Standard Event Status Enable Register *ESE Input of ESR enable bit mask Syntax: *ESE p1(x) Parameters: Decimal equivalents of 8 Bit ESE register 0 − 255 Effect: This command sets the ESE masks. It makes it possible to suppress error messages.
Page 233 Instruction set for the HBM Interpreter ➝ Communication G 37 Standard Event Status Enable Query *ESE? Output of ESR enable bit mask Syntax: *ESE?(x) Parameters: none Effect: Current contents of Standard Event Status Enable (ESE) register output. Response: q1(y) Contents of ESE register 0 −...
Page 234 Instruction set for the HBM Interpreter ➝ Communication G 38 Parallel Poll Mode Inputting the parallel poll response (IEEE 488 only) Syntax: PPM p1(x) Parameters: No parallel poll response ( Sense = 1) 1 − 8 Parallel poll response (Sense = 1) 9 −...
Page 235 Instruction set for the HBM Interpreter ➝ Communication G 39 Example 1: PPM1(x) 0(y) The device answers with with 1 on data line 1, if one bit of the status byte registers and the associated bit of the parallel poll enable register are set (see also command *IST?, *PRE).
Page 236 Instruction set for the HBM Interpreter ➝ Communication G 40 Parallel Poll Mode Query PPM? Output of parallel poll response (IEEE 488 only) Syntax: PPM?(x) Parameters: none Effect: The parallel poll response setting is output. Response : q1(y) No parallel poll response ( Sense = 1) 1 −...
Page 237 Instruction set for the HBM Interpreter ➝ Communication G 41 Status byte register query *STB? Output of STB register Syntax: *STB?(x) Parameters: none Effect: Output of status byte register. The status byte register receives information on whether there is a message in the output buffer, an error has occurred or a service request has been made (see also *ESR? command).
Page 238: Service Request Enable Register
Instruction set for the HBM Interpreter ➝ Communication G 42 Service Request Enable Register *SRE Input of TB enable bit mask Syntax: *SRE p1(x) Parameters: Decimal equivalents of 8 Bit SRE register 0 − 63, 128 − 191 Effect: This command sets the SRE register bits. It makes it possible to allow or suppress service requests to the IEEE interface.
Page 239 Instruction set for the HBM Interpreter ➝ Communication G 43 Example: *SRE32(x) 0(y) 5 from the SRE register is set, i.e. so that the MSS bit is set and a service request made if the ESB bit has been set in the STB register.
Page 240 Instruction set for the HBM Interpreter ➝ Communication G 44 Service request enable query *SRE? Output of STB enable bit mask Syntax: *SRE?(x) Parameters: none Effect: Current contents of service request enable (SRE) registers is output. Response: q1(x) Contents of SRE register 0 −...
Page 241 Instruction set for the HBM Interpreter ➝ Communication G 45 Clear status *CLS Delete all queues and event registers Syntax: *CLS(x) Parameters: none Effect: All event status registers, which are represented by a summary bit in the status byte register, as well as the output buffer, are deleted.
Page 242 Response: q1(y) The DMP40 gives no response in the event of a parallel poll query In the event of a parallel poll query, the DMP40 answers Example: *IST?(x) 1(y) The DMP40 answers on a parallel poll query. Bits:...
Page 243 *PRE0(x) 0(y) No response in event of parallel poll query Example 2: *PRE64(x) 0(y) The DMP40 should answer in the event of a parallel poll query, if the MSS bit (master summary status) is set. Operation with computer or terminal...
Page 244 *PRE?(x) 64(y) Bit 6 from PRE register is set. The DMP40 answers in the event of a parallel poll query, if the MSS bit (master summary status) has been set in the status byte register. Operation with computer or terminal...
Page 245 Instruction set for the HBM Interpreter ➝ Communication G 49 Extended Status Query XST? Syntax: XST?(x) Parameters: none Effect: The DMP40 answers with one decimal number, which is bit−coded. Decimal 0001 0002 0004 0008 0010 0020 0040 0080 0100 0200...
Page 246 Instruction set for the HBM Interpreter ➝ Communication G 50 Bit0: not used Bit1: Calibration error Bit2: Sensor−Current limit Bit3: Sensor short cut to GND Bit4: Input signal clipped = overflow, open Bit5: no transducer, sensor lines open Bit6: not used...
Page 247: Identification
Instruction set for the HBM Interpreter ➝ Communication G 51 Identification Amplifier identification query AID? Output of amplifier identification Syntax: AID?(x) Parameters: none Effect: Output of amplifier identification. Response: Character string (20 characters per active amplifier)(y) Example: AID?(x) HBM,RD001 MC30,0,P13(y) Company, device designation, serial number, version number.
Page 248: Amplifier Set Ups
G 52 HBM Interpreter commands➝ Amplifier set ups Amplifier set ups Amplifier input Amplifier Sensor Adaptation Entering excitation voltage and transducer type Syntax: ASA p1,p2,p3(x) Parameters: Code number of required bridge excitation voltage Bridge excitation voltage 2.5 V 10 V...
Page 249 HBM Interpreter commands ➝ Amplifier set ups G 53 Parameters: Shunt status Shunt Effect: Amplifier sets itself to the selected transducer configuration. Response: Acknowledgment Meaning Command has been executed Error Example: ASA3,1,0(x) 0(y) The amplifier is set to 10 V excitation voltage, 2.5 mV/V sensitivity and shunt ’OFF’.
Page 250 G 54 HBM Interpreter commands➝ Amplifier set ups Amplifier sensor adaptation query ASA? Output excitation voltage and transducer type Syntax: ASA? p1(x) Parameters: Output excitation voltage and input sensitivity set up Output table of available set ups for excitation voltage and input sensitivity...
Page 251 HBM Interpreter commands ➝ Amplifier set ups G 55 Response: ASA?1(x) q1,q2,q3(y) Table of available settings Available excitation voltage Available sensitivity Shunt status Excitation voltage Excitation voltage (V) 02.5 05.0 10.0 10.0 The index corresponds to the excitation voltage to be set up (each element in the table is 4 characters long).
Page 252 G 56 HBM Interpreter commands➝ Amplifier set ups Amplifier Signal Select Select amplifier input signal Syntax: ASS p1(x) Parameters: Input source ZERO Internal zero signal Internal calibration signal MEAS Measuring signal Effect: Definition of amplifier input signal. Response: Acknowledgment Meaning...
Page 253 HBM Interpreter commands ➝ Amplifier set ups G 57 Amplifier Signal Select Query ASS? Output of source type Syntax: ASS?(x) Parameters: none Effect: The type of amplifier input signal is output. Response: q1(y) Amplifier’s input signal source Amplifier input is switched to ZERO.
Page 254 G 58 HBM Interpreter commands➝ Amplifier set ups Select Feedback Select type of transducer connection Syntax: SFB p1(x) Parameters: Circuit type 6 wire circuit 4 wire circuit Note: Accurate measurement results can only be obtained with 6 wire circuit (factory set up)! In special cases you can switch to 4 wires.
Page 255: Filter Set Up
HBM Interpreter commands ➝ Amplifier set ups G 59 Filter set up Amplifier Filtering Select Filter switching (fc 1/2) Syntax: AFS p1(x) Parameters: Filter code number Effect: Switching between two filters (see also ASF). Response: Acknowledgment Meaning Command has been executed...
Page 256 G 60 HBM Interpreter commands➝ Amplifier set ups Amplifier Filtering Select Query AFS? Output of filter setting Syntax: AFS?(x) Parameters: none Effect: Output of filter set up Response: q1(y) Filter code number Example: AFS?(x) 1(y) Filter fc1 is switched on...
Page 257 HBM Interpreter commands ➝ Amplifier set ups G 61 Amplifier Signal Filtering Input of cutoff frequency and filter characteristics Syntax: ASF p1,p2,p3(x) Parameters: Filter code number Filter frequency 1 − n Code number for frequency value (corresponds to the index from the frequency table, which can be output with the command ASF?0).
Page 258 G 62 HBM Interpreter commands➝ Amplifier set ups Response: Acknowledgment Meaning Command has been executed Error Example: Input of cutoff frequency and filter characteristics for filter fc2 e.g. for MC30. ASF 2,10,0 (x) 0(y) Filter fc2 is set to a cutoff frequency of 0.22Hz and Bessel characteristic.
Page 259 HBM Interpreter commands ➝ Amplifier set ups G 63 Amplifier Signal Filtering Query ASF? Output of cutoff frequency and filter characteristics Syntax: ASF? p1(x) Parameters: Filter code number Frequency table (Bessel und Butterworth) Filter fc1 Filter fc2 Effect: Output of cutoff frequency and filter characteristics set in low pass filter.
Page 260 G 64 HBM Interpreter commands➝ Amplifier set ups In the following tables you will find the available cutoff frequencies with Bessel or Butterworth characteristics with the maximum possible mea suring rate (speed) (see also ISR command). The index corresponds to the frequency to be set up (each element in the table is 5 characters long).
Page 261: Measuring Range
HBM Interpreter commands ➝ Amplifier set ups G 65 Measuring range Calibration Dead Weight Start zeroing/enter zero value (balance) Syntax: CDW(x) or CDW p1(x) Parameters: Zero value in ADU units 7 680 000 ADU units correspond to the final value of the measuring range currently set at 2.5mV/V, 5mV/V or 10mV/V.
Page 262 G 66 HBM Interpreter commands➝ Amplifier set ups Note: There also exists the possibility of setting the basic unbalance to zero, with the zero value to be calculated according to the following equation: 7 680 000 x basic unbalance (mV/V)
Page 263 HBM Interpreter commands ➝ Amplifier set ups G 67 Calibration Dead Weight Query CDW? Output of zero value Syntax: CDW? p1(x) Parameters: Code number of zero value Zero value Zero value plus current gross measured value Effect: With this command, the zero value is output from the memory or the...
Page 264 G 68 HBM Interpreter commands➝ Amplifier set ups Change Measuring Range Switch measuring range (Range 1/2) Syntax: CMR p1(x) Parameters: Measuring range code number Measuring range (Range) 1 Measuring range 2 Effect: Whichever of the two measuring ranges you require is switched on.
Page 265 HBM Interpreter commands ➝ Amplifier set ups G 69 Change Measuring Range Query CMR? Output of measuring range Syntax: CMR?(x) Parameters: none Effect: The measuring range selected is output. Response: q1(y) Measuring range code number Measuring range (Range) 1 Measuring range 2...
Page 266 0(y) Measuring range 2 is set to 2.5 mV/V Note: This command is implemented into the existing software in the DMP40 for reasons of compatibility only; permitted input value is only that with the ASA selected measuring range. Operation with computer or terminal...
Page 267 HBM Interpreter commands ➝ Amplifier set ups G 71 Input Measuring Range Query IMR? Output of final value of the measuring range Syntax: IMR? p1(x) Parameters: Measuring range code number The signal S1 in ADU units without zero and tare...
Page 268 G 72 HBM Interpreter commands➝ Amplifier set ups Example 1: IMR?2(x) 2,2.5(y) Measuring range 2 is set to 2.5 mV/V. Note: If no measuring range code number (p1) is input, the device sends the code number for the measuring range that is currently set and the final value of the measuring range.
Page 269: Tare
HBM Interpreter commands ➝ Amplifier set ups G 73 Tare Tare instruction Start taring /Enter tare value Syntax: TAR p1(x) Parameters: p1 (optional) Tare value in ADU units Effect: The signal S2 is tared (set to zero). If p1 is not sent, the current measured value is tared by S2.
Page 270 G 74 HBM Interpreter commands➝ Amplifier set ups Tare Value Query TAR? Output tare value Syntax: TAR?(x) Parameters: none Effect: The tare value is output in ADU units. Response: q1(y) Tare value in ADU units Example: TAR?(x) 3840000(y) Note: Using the following equation, you can convert the tare value into the...
Page 271: Analog Outputs
HBM Interpreter commands ➝ Amplifier set ups G 75 Analog outputs Output Path Select Assign analog outputs Syntax: OPS p1,p2(x) Parameters: Output Signal No link S1 (Gross) S2 (Net) S3 (min / max storage 1) S4 (min / max storage 2)
Page 272 G 76 HBM Interpreter commands➝ Amplifier set ups Output Path Select Query OPS? Query allocation of analog outputs Syntax: OPS? p1(x) Parameters: Code number of required output (see OPS command). Effect: With this the allocation between the analogue output p1 to one of the signals S1 −...
Page 273: Peak Store
HBM Interpreter commands ➝ Amplifier set ups G 77 Peak store Peak Value Select Input of peak value store settings Syntax: PVS p1,p2,p3,p4(x) Parameters: Min / Max storage Peak value determination (always applies to both Min / Max storage) Signal −1...
Page 274 G 78 HBM Interpreter commands➝ Amplifier set ups Envelopes Envelope function is off 1..60000 Timing constant in ms Effect: This command is used to set the function of the peak value store p1. Response: Acknowledgment Meaning Command has been executed...
Page 275 HBM Interpreter commands ➝ Amplifier set ups G 79 Peak Value Select Query PVS? Output of peak value store settings Syntax: PVS?p1(x) Parameters: Code number of Min / Max storage (see PVS command). Effect: This command causes the setting of peak value store p1 to be output.
Page 276 G 80 HBM Interpreter commands➝ Amplifier set ups Clear Peak Value Clear peak value store Syntax: CPV(x) Parameters: none Effect: This command clears the peak value stores Response: Acknowledgment Meaning Command has been executed Error Example: CPV(x) 0(y) Min / Max storage 1 and 2 (S3,S4) are deleted.
Page 277: Limit Value Monitoring
HBM Interpreter commands ➝ Amplifier set ups G 81 Limit value monitoring Limit Value Input of limit value switching thresholds Syntax: LIV p1,p2,p3,p4,p5(x) Parameters: Limit monitors Limit value monitoring Operation with computer or terminal...
Page 278 G 82 HBM Interpreter commands➝ Amplifier set ups Source p4, p5 Switching points Input in ADU units, 7680000 at final value of the measuring range. Effect: With the aid of this command, limit value switch p1 is set to limit value monitoring, to source p3, to switching point p4 (closer) and switching point p5 (opener).
Page 279 HBM Interpreter commands ➝ Amplifier set ups G 83 Example 1: LIV1,1,2,3840000,−3840000(x) 0(y) Limit value switch 1 is set to limit value monitoring, source S2 and swit ching points +50 % (closer) or 50 % (opener). Note: With the following equations, you can convert the switching points into...
Page 280 G 84 HBM Interpreter commands➝ Amplifier set ups Limit Value Query LIV? Output of limit value switching thresholds Syntax: LIV? p1,p2(x) Parameters: Limit monitors Query signal value of p2 (output in ADU units) Signal code number, if p1=0 Effect: This command causes the setting of limit value switch p1 to be output.
Page 281 HBM Interpreter commands ➝ Amplifier set ups G 85 Response: q1,q2,q3,q4,q5(y) or q6(y) Limit monitors Limit value monitoring On/Off source of the limit monitor Switching point 1 (closer) in ADU units Switching point 2 (opener) in ADU units Level of signal p2 in ADU units...
Page 282: Transferring Amplifier Settings And Comments
G 86 HBM Interpreter commands➝ Amplifier set ups Transferring amplifier settings and comments Memory Device Data Input of amplifier set up data Syntax: MDD p1(x) Parameters: Amplifier set up data, retrieved from the amplifier with the command MDD? (as hexadecimal string "___", 123 Bytes = 246 characters.
Page 283 HBM Interpreter commands ➝ Amplifier set ups G 87 Memory Device Data Query MDD? Output of amplifier set up data Syntax: MDD? p1(x) Parameters: Channel number of amplifier (1 2) Effect: Set up parameters of amplifier are output Response: "____hexadecimal string____"(y) (123 Bytes= 246 characters)
Page 284 G 88 HBM Interpreter commands➝ Amplifier set ups Transmit Device Data Save amplifier set ups and comments Syntax: TDD p1(x) Parameters: Amplifier set ups RAM (Setup Factory Data) EEPROM RAM (Recall Data) EEPROM (Save Data) External EEPROM RAM (Recall Data)
Page 285 HBM Interpreter commands ➝ Amplifier set ups G 89 Example: TDD2(x) 0(y) Store amplifier set ups in internal EEPROM. Saving to an external EEPROM takes about 3 secs. Operation with computer or terminal...
Page 286 G 90 HBM Interpreter commands➝ Amplifier set ups Transmit Device Data Query TDD? Query, where amplifier set up originates from Syntax: TDD? p1(x) Parameters: Source of amplifier set up Queries whether external EEPROM is connected Effect: Queries the source of the currently active amplifier setting.
Page 287 HBM Interpreter commands ➝ Amplifier set ups G 91 Example 1: TDD?0(x) 1(y) Amplifier set up comes from internal EEPROM. Example 2: TDD?3(x) 1(y) External EEPROM not present. Operation with computer or terminal...
Page 288 G 92 HBM Interpreter commands➝ Amplifier set ups User Channel Comment Input comment Syntax: UCC p1(x) Parameters: any string "_ _ _ _ _", (45 characters) Effect: With this command any comments can be stored in the amplifier. Response: Acknowledg...
Page 289 HBM Interpreter commands ➝ Amplifier set ups G 93 User Channel Comment Query UCC? Output comments Syntax: UCC?(x) Parameters: none Effect: With this command, a comment stored in the amplifier can be read off. Response: "_ _ (String)_ _"(y) Example: UCC?(x) "Pressure transducer at load machine"(y)
Page 290: Remote Control
G 94 HBM Interpreter commands➝ Amplifier set ups Remote control Local/Remote Local/Remote switching Syntax: LOR p1(x) Parameters: Status local remote Effect: Switch to remote control of certain amplifier functions (see RFP com mand) via remote control inputs of the AP42 connection board (Pin 2 −...
Page 291 HBM Interpreter commands ➝ Amplifier set ups G 95 Local/Remote Query LOR? Query Local/Remote status Syntax: LOR?(x) Parameters: none Effect: Local/Remote control status is output Response: q1(y) Status local remote Example: LOR?(x) 1(y) Local control is switched on, i.e. all set up functions for amplifier pa rameters via the remote control lines (Bu2, Pin2 −...
Page 292 G 96 HBM Interpreter commands➝ Amplifier set ups Remote Function Programming Assignment of remote functions Syntax: RFP " .."(x) Pin9 Bu2 of connection boards Pin2 Parameters: Code Function number Autocalibration Off/On ACAL...
Page 293 HBM Interpreter commands ➝ Amplifier set ups G 97 The function code numbers 0 − 7 correspond to the default assignment of Pins 2 − 9 after a device "SET UP". Effect: A string (8 characters) is sent for the assignment of Pins 2 − 9 of the AP42 socket on the amplifier connection boards.
Page 294 G 98 HBM Interpreter commands➝ Amplifier set ups Remote Function Programming Query RFP? Query re: assignment of the remote functions Syntax: RFP? p1(x) Parameters: Output assignment of remote functions Output table of available functions Effect: Output of assignment of remote functions of Pins 2 − 9 of the AP42 on the amplifier connection boards.
Page 295: Amplifier Functions
HBM Interpreter commands ➝ Amplifier functions G 99 Amplifier functions Calibration AutoCal Switching autocalibration on and off Syntax: ACL p1(x) Parameters: Automatic calibration Switch off Switch on Effect: Switching autocalibration status on and off (see also CAL). Response: Acknowledgment Meaning...
Page 296 HBM Interpreter commands ➝ Amplifier functions G 100 AutoCal Query ACL? Output of autocalibration status Syntax: ACL?(x) Parameters: none Effect: Status of autocalibration is output. Response: q1(y) Status Autocalibration is off Autocalibration is on Example: ACL?(x) 1(y) Autocalibration has been switched on.
Page 297 HBM Interpreter commands ➝ Amplifier functions G 101 Calibrate Calibration Syntax: CAL(x) Parameters: none Effect: A single calibration is triggered. Response: Acknowledgment Meaning Command has been executed Error Example: CAL(x) 0(y) Calibration is performed. Note: see also ACL command Operation with computer or terminal...
Page 298: Output Format, Measurement Output
HBM Interpreter commands ➝ Amplifier functions G 102 Output format, measurement output Change Output Format Change format of measurement output Syntax: COF p1(x) Parameters: Measurement output format Measured value, channel, status (ASCII format) Measured value (ASCII format) Binary measurement output 4 bytes (MSB XX XX LSB)
Page 299 HBM Interpreter commands ➝ Amplifier functions G 103 Bit: Status byte Limit value1 On Limit value 2 on Limit value 3 On Limit value 4 on S1 Overflow S2 Overflow Calibration error 128 Alteration of setting (e.g. via remote control signals),...
Page 300 HBM Interpreter commands ➝ Amplifier functions G 104 Effect: With the following MSV commands, measured values are output in the preferred form. Response: Acknowledgment Meaning Command has been executed Error Example: COF0(x) 0(y) Output measured values with channel no. and status in ASCII format.
Page 301 HBM Interpreter commands ➝ Amplifier functions G 105 Change Output Format Query COF? Query format of measurement output Syntax: COF?(x) Parameters: none Effect: Output the output format code number of measured values. Response: q1(y) Output format code number (see COF command).
Page 302 HBM Interpreter commands ➝ Amplifier functions G 106 Input Sampling Rate Define value transfer rate Syntax: ISR p1(x) Parameters: Divider value for measurement output data transfer rate via an interface. Effect: In the case of binary measurement output, this command takes care of an output in a fixed time raster for the commands MSV?13;...
Page 303 HBM Interpreter commands ➝ Amplifier functions G 107 The following commands start an output in the 15 measured values / seconds time raster: Command Function ISR5(x) Value transfer rate 15 per second COF2(x) Output format 4 bytes binary MSV?13,0(x) Continuous measurement output...
Page 304: Measured Value Output
HBM Interpreter commands ➝ Amplifier functions G 108 Measuring Signal Value Query MSV? Measured value output Syntax: MSV? p1,p2,p3(x) Parameter: Selection of amplifier signal Signal Gross Peak value1 Peak value2 LVS1 Closer LVS1 Opener LVS2 Closer LVS2 Opener LVS3 Closer...
Page 305 HBM Interpreter commands ➝ Amplifier functions G 109 Selection of amplifier signal Signal Peak value1 net mV/V Peak value2 absolute mV/V Peak value2 gross mV/V Peak value2 net mV/V Absolute Unit2 Gross Unit2 Net Unit2 Peak value1 absolute Unit2 Peak value1 gross Unit2...
Page 306 HBM Interpreter commands ➝ Amplifier functions G 110 Parameter: Sequence in seconds 0.1 s to 60.0 s. Output time in seconds between measured values (only for binary measurement output). Effect: The measured value from the required signal p1 is output. The output format depends on the last COF and TEX command.
Page 307 HBM Interpreter commands ➝ Amplifier functions G 111 Example 1: Output in full ASCII format TEX44,59(x) Separators ’,’ and ’;’ 0(y) COF0(x) Full ASCII format (value, channel, status) 0(y) Retrieve one measured value from S1. MSV?1(x) 9.998,3,0(y) Status byte Channel Measured value (e.g.
Page 308 HBM Interpreter commands ➝ Amplifier functions G 112 Example 2: Output in stripped ASCII format Stripped ASCII format (value only). One measured value from S1. COF1(x) 0(y) MSV?1(x) 9.998(y) Operation with computer or terminal...
Page 309 HBM Interpreter commands ➝ Amplifier functions G 113 Example 3: Output in 4 byte binary format Binary 4 byte format One value from S1 COF2(x) 0(y) MSV?1(x) #14ffeedd00(y) 1 byte status Binary format 3 bytes measured value ASCII format z: Identification character for binary output...
Page 310 HBM Interpreter commands ➝ Amplifier functions G 114 Measuring Extended Values Query Output of additional measured values Syntax: MEV? p1 (x) Parameter: Selection of amplifier signal Signal External voltage in volts (xx.xxx) External resistance in W (xxxx.x) External temperature in °C (−xxx.xx) Transducer current in mA (xxx.x)
Page 311 HBM Interpreter commands ➝ Amplifier functions G 115 The maximum transducer current is about 250 mA. If the final stage of transducer excitation is limited, 999.9 mA is displayed. The transducer resistance is the quotient of the current excitation voltage and the transducer current. If the final stage is limited, 0 is output.
Page 312 HBM Interpreter commands ➝ Amplifier functions G 116 Stop End of measurement output Syntax: STP(x) Parameters: none Effect: The measurement output initiated with MSV? is stopped. Response: none Example: STP(x) Operation with computer or terminal...
Page 313 HBM Interpreter commands ➝ Amplifier functions G 117 Define Terminator Define value separators Syntax: TEX p1,p2(x) Parameters: Parameter separators 1 126 Default: 44, ASCII "," Block separators 1 126 Default: 13, ASCII "CR" Effect: ASCII characters input with p1 and p2 are effective as separators for ASCII value output (MSV? command).
Page 314 HBM Interpreter commands ➝ Amplifier functions G 118 Define Terminator Query TEX? Output value separator Syntax: TEX?(x) Parameters: none Effect: Output value separator (see TEX). Response: q1,q2(y) Parameter and block separators Example: TEX?(x) 44,13(y) 44 ➝ ASCII "," 13 ➝ ASCII "CR"...
Page 315: Display Functions
HBM Interpreter commands ➝ Amplifier functions G 119 Display functions Note: The commands in this Chapter, "Display functions" have an effect on the display of measured values on the Act.screen. Engineering Unit Input of the unit of measurement Syntax: ENU p1,p2(x)
Page 316 HBM Interpreter commands ➝ Amplifier functions G 120 Engineering Unit Query ENU? Output of the unit of measurement Syntax: ENU? p1(x) Parameters: Unit of measurement of measuring range currently set Unit − Measuring range 1 Unit − Measuring range 1...
Page 317 HBM Interpreter commands ➝ Amplifier functions G 121 These mean: MV/V mV/V µm INCH inch TONS tons FTLB ftlb INLB inlb µm/m uM/M mBAR mbar M/SS p/oo HPAS HPAS KPAS KPAS Operation with computer or terminal...
Page 318 HBM Interpreter commands ➝ Amplifier functions G 122 Example 1: ENU?(x) 1,"MV/V"(y) Unit of measurement of current measuring range set Example 2: ENU?3(x) "MV/VV_ _ _G_ _ _KG_ _T_ _ _KT_ _TONSLBS_N_ _ _KN_ _BAR_mBARPA_ PAS_HPASKPASPSI_UM_ _MM_ _CM_ _M_ _ _INCHNM_ _FTLBINLB UM/MM/S_M/SSp/o_p/ PPM_"(y)
Page 319 HBM Interpreter commands ➝ Amplifier functions G 123 Indication Adaptation Input, end value, decimal point, step Syntax: IAD p1,p2,p3,p4(x) Parameters: Range 1 or 2 End value without decimal point Decimal point (number of decimal places) Step (= minimum step) (digit)
Page 320 HBM Interpreter commands ➝ Amplifier functions G 124 Response: Acknowledgment Meaning Command has been executed Error Example: IAD2,10000,3,4(x) 0(y) Set display adaptation for Measuring range 2 End value 10,000 with step width 0.010 Note: In Measuring range 1, only the range currently selected with ASA can be input;...
Page 321 HBM Interpreter commands ➝ Amplifier functions G 125 Indication Adaptation Query IAD? Output end value, decimal point, step Syntax: IAD? p1(x) Parameters: Status of Measuring range 1 of Measuring range 1 Effect: Output of end value, decimal point, step. Response:...
Page 322 HBM Interpreter commands ➝ Amplifier functions G 126 Linearization Table Linearization of transducer characteristic curve Syntax: LTB n,x 1 ..Parameter: n=2 ...11 x=Figures in mV/V (Measuring range 1) y=Figures with current unit of measurement for Measuring range 2 (Set decimal places using the command "IAD")
Page 323 HBM Interpreter commands ➝ Amplifier functions G 127 Linearization Table Query LTB? Output current linearization curve Syntax: LTB?(x) Parameters: none Effect: The current characteristic curve points are output. Note: After inputting the characteristic curve points, the display adaptation ("IAD" command) of Measuring range 2 is automatically adjusted. As the linearization table is input in mV/V, no correction is necessary after a change of measuring range.
Page 324 HBM Interpreter commands ➝ Amplifier functions G 128 Sign Reversal Syntax: SGN p1(x) Parameters: Display normal display of values reversed display of values toggle normal / reversed Sign Reversal Query SGN? Syntax: SGN?(x) Parameters: Response: q1(y) normal display of values...
Page 325: Appendix I Program Versions
Appendix I ➝ Program versions Appendix I Program versions Some commands are executed in the amplifiers, others in the CP12. Should individual components (CP12 or amplifier) of your DMP ampli fier be fitted with older firmware versions, the table below will tell you which commands are affected by this.
Page 326 Appendix I ➝ Program versions Command Executed in the CP12 Executed in the amplifier *CLS *ESR? *ESE IBY? *IDN? Operation with computer or terminal...
Page 327 Appendix I ➝ Program versions Command Executed in the CP12 Executed in the ampli fier *IST? *PRE *RST *STB? *SRE Operation with computer or terminal...
Page 328 Appendix I ➝ Program versions Operation with computer or terminal...
Page 329: Appendix Ii Cp12 Measured Value Transmission Rates
Appendix II ➝ CP12 measured value transmission rates Appendix II CP12 measured value transmission rates The quickest transmission of measured values (IEEE interface or serial at 9600 baud) is obtained with binary output; with one or two (DMP40S2) amplifiers all values occurring at 75Hz can be transmitted (measuring rates: see command ASF).
Page 330 Appendix II ➝ CP12 measured value transmission rates Operation with computer or terminal...
Page 331: Appendix Iii Glossary
Appendix III ➝ Glossary Appendix III Glossary This glossary contains words which are use in the manual "Operation with computer or terminal", as well as general terms used in the field of computer technology. ASCII ASCII is a standardized code (American Standard Code for Information Interchange), in which specific codes are assigned to each printable character and each control character on your computer, e.g.
Page 332 Appendix III ➝ Glossary Byte Byte is the amount of memory space needed to save one character. One byte consists of 8 bits, e.g. 01010001. DIP switch A DIP switch is a mini switch, usually with 8 individual switches. Firmware Software, which is stored in the EEPROM or PROM and defines equip ment functions.
Page 333 Appendix III ➝ Glossary Register Standard Event Status Register The standard event status register (ESR) is set if errors occur in com munication. Different causes of error set different bits, so that errors can be specified precisely. Standard Event Status Enable Register An error bit is set in the standard event status register.
Page 334 Appendix III ➝ Glossary Interface Any connection point through which data can be transfered or other devices connected. Serial A standardized transfer mode, enabling data to be transfered between transmitting and receiving devices bit by bit. Syntax A fixed sequence of characters, which must be used for inputting com mands, parameters and switches, e.g.
Page 335: Appendix Iv Alphabetical Summary Of Commands
Appendix IV ➝ Alphabetical summary of commands Appendix IV Alphabetical summary of commands Operation with computer or terminal...
Page 336 Appendix IV ➝ Alphabetical summary of commands This summary relates to Chapter G "HBM Interpreter commands". Abbreviation Command Page Abbreviation Command Page Baud Rate AutoCal Set baud rate for the Switching on/off of serial interfaces ..... .
Page 337 Appendix IV ➝ Alphabetical summary of commands Abbreviation Command Page Abbreviation Command Page COF? Change Output Format Query IMR? Input Measuring Range Query Query format of measurement output G 105 Output of measuring−range upper and lower . limits ....... G 71 Clear Peak Value Clear peak−value store...
Page 338 Appendix IV ➝ Alphabetical summary of commands Abbreviation Command Page Abbreviation Command Page MSV? Measuring Signal Value Query *RST Reset Output of measured value ... . G 108 Execute warm start .
Page 339 Appendix IV ➝ Alphabetical summary of commands Abbreviation Command Page Tare Instruction Initiate taring/ input tare value ..... . G 73 TAR? Tare Value Query Output tare value...
Page 340 Appendix IV ➝ Alphabetical summary of commands Operation with computer or terminal...
Page 341: Appendix V Summary Of Commands By Function
Appendix V ➝ Summary of commands by function Appendix V Summary of commands by function Operation with computer or terminal...
Page 342 Appendix V ➝ Summary of commands by function This summary relates to Chapter G "HBM Interpreter instruction set". Abbreviation Page Abbreviation Page • Communications behaviour ..G 12 Error−handling, status register ...
Page 343 Appendix V ➝ Summary of commands by function Abbreviation Page Abbreviation Page • Change range Identification ......G 51 (range1/2) .
Page 344 Appendix V ➝ Summary of commands by function Abbreviation Page Abbreviation Page • • Transmission of amplifier Output format, measurement output ..G 102 settings and comment(s) ....G 86 Change measurement output Input of amplifier set−up data...
Page 345: Appendix Vi Index To Keywords
Appendix VI − Index to keywords Appendix VI Index to keywords Operation with computer or terminal...
Page 346 Appendix VI − Index to keywords Interface commands, D 8 Interfaces, A 5 , B 3 , B 4 , C 3 Activation, RS−232−C, E 4 Interpreter, E 3 , E 12 Activation of the interface, E 7 Address, D 4 , D 5 , E 7 , E 10 , E 15 Assignment, E 5 Parallel poll, D 5 , D 7 , D 9 Parity, C 4 , E 6 , E 10...
Page 348 They are not to be understood as express warranty and do not constitute any liability whatsoever. Postfach 10 01 51, D 64201 Darmstadt Im Tiefen See 45, D 64293 Darmstadt Tel.: +49/61 51/8 03 0; Fax: +49/61 51/ 8039100 B0396 4.0 en E−mail: support@hbm.com www.hbm.com...

This manual is also suitable for:

Dmp40s2

HBM DMP40 Operating Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HBM DMP40

Summary of Contents for HBM DMP40

This manual is also suitable for:

Table of Contents
