Summary of Contents for Uplus Lighting 480BSWF
- Page 1 User manual 480BSWF Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 DMX Channels ……………………………………………………………………………………5-9 LUX Date ……………………………………………………………………………………………10 Dimension …………………………………………………………………………………………11 Trouble Shooting…………………………………………………………………………………12 Fixture Cleaning………………………………………………………… ………………………12 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications 480W LED BSWF 4-in-1 moving head Optics: Source:480W white LED Life:>30000H Zoom angle:4.5°-55° Input power:550W AC100-240V 50-60HZ Pan movement:540°/630° optional(16bit) Tilt movement:270°(16bit) Advanced motion system:auto repositioning,fast,quiet and smooth Color: CMY+CTO color mixing system 1 color plate: 7 fixed color plates + white light Gobo: 1 effect plate (fire plate) 1 rotating gobo wheel: 7 gobos+white 1 fixed pattern plate: 8 pattern pieces + white... -
Page 5: Dmx Channels
3.DMX Channels DMX channel´s functions and values (34/54DMX channels) Mode Value Function 34CH 54CH Pan Movement 8bit: 0-255 Pan Movement Pan Fine 16bit 0-255 Fine control of Pan movement Tilt Movement 8bit: 0-255 Tilt Movement Tilt Fine 16bit 0-255 Fine control of Tilt movement Speed Pan/Tilt movement: 0-255 max to min speed... - Page 6 Color Wheel: 0-15 Open 16-22 Open/Color1 23-29 Color1 30-36 Color1/Color2 37-43 Color2 44-50 Color2/Color3 51-57 Color3 58-64 Color3/Color4 65-71 Color4 72-78 Color4/Color5 79-85 Color5 86-92 Color5/Color6 93-99 Color6 100-106 Color6/Color7 107-113 Color7 114-120 Color7/Open 121-127 Open 128-189 Forwards rainbow effect from fast to slow 190-193 No rotation 194-255...
- Page 7 47-59 Rot.gobo4 60-72 Rot.gobo5 73-85 Rot.gobo6 86-98 Rot.gobo7 99-111 Gobo 1 shake slow to fast 112-124 Gobo 2 shake slow to fast 125-137 Gobo 3 shake slow to fast 138-150 Gobo 4 shake slow to fast 151-163 Gobo 5 shake slow to fast 164-176 Gobo 6 shake slow to fast 177-189...
- Page 8 163-193 Backwards rotation from slow to fast 194-255 Animation rotation from slow to fast Iris: 0-255 Max.diameter to Min.diameter Iris Fine: 0-255 Iris Fine Prism: 0-127 Open 128-255 Prism Rotating prism index,rotating prism rotation 0-127 Prism indexing 128-189 Forwards prism rotation from fast to slow 190-193 No rotation 194-255...
- Page 9 0-255 Open to Close Blade 4B: 0-255 Blade 4 Rotation Blade 4B Fine: 0-255 Blade 4 Rotation Fine All Blade Rotation: 0-255 All Blade Rotation All Blade Rotation Fine: 0-255 All Blade Rotation Fine Reset、LCD、Fans unused 10-19 Display Off 20-29 Display On 30-39 Display Invert Off...
-
Page 10: Lux Date
4.LUX Date... -
Page 11: Dimension
5.Dimension... -
Page 12: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
