XJ REAR WINDOW

MOLLE PANEL INSTALLATION

TOOLS NEEDED

• T-50 Torx

• Phillips Head Screwdriver

• 3/16" Allen

• 8mm socket

• Drill (96 and down)

Please read the mounting instructions below

carefully before attempting to install.

HARDWARE

• 2 1/2" Sheet Metal Screw qty. 1

• 5/16-18 1" Button Head qty. 4

• 5/16"-18 Flange Nut qty. 4

Thank you for purchasing your MOLLE panel from JcrOffroad!

Checkout our website, www.jcroffroad.com for other great off-

road products. Be sure to rate and review our product online. If

you have any questions or are missing parts, please don't hesitate

to call us at 269-353-1184!

Need help?

Do you have a question about the XJ and is the answer not in the manual?

Page 1 • 8mm socket • Drill (96 and down) Please read the mounting instructions below Thank you for purchasing your MOLLE panel from JcrOffroad! Checkout our website, www.jcroffroad.com for other great off- carefully before attempting to install. road products. Be sure to rate and review our product online. If you have any questions or are missing parts, please don’t hesitate...
Page 2 Loosen the seat back bracket and remove the rear two bolts. Place the front MOLLE panel bracket behind the seat back bracket and reinstall. Leave it loose until the panel is fully installed. Remove the upper seatbelt bolt using a T-50 Torx. Place the upper MOLLE panel bracket over the seatbelt bracket as shown.
Page 3 Put the MOLLE panel in place, behind the seatbelt and in front of the mounting brackets. Loosely bolt it in place. 97+: Remove the interior panel screw as shown and reinstall through the rear MOLLE panel bracket using the supplied screw. The bend will go towards the MOLLE panel. 96 -: You will not have this interior screw.
Page 4 Align the panel in the window opening, tighten all of the hardware down, and that’s it! Enjoy your new MOLLE panel!
