Page 1: Battery Installation
LPC-15WD510 Battery Installation Quick Reference Guide Ed – 3 December 2010 Copyright Notice Copyright © 2007-2010 Avalue Technology Inc., ALL RIGHTS RESERVED. -
Page 2: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. 2 LPC-15WD510 Battery... - Page 3 Step 1. Remove the battery along with its cover from the accessory box. Step 2. Position the LPC-15WD510 unit with its back facing up. Please unfasten and remove the screws located on the back cover, as pictured below. The back cover can now be removed.
- Page 4 LPC-15WD510 Step 3. Unfasten and remove the 4 highlighted screws from the LPC-15WD510 unit. This will remove the silver siding inside the unit and allow for easier installation of the battery. Step 4. Unfasten the two highlighted screws to uncover the location of the battery...
- Page 5 Quick Reference Guide Step 5. Place the battery Step 6. Make sure the battery socket is properly inserted into board slot Step 7. Place the battery cover and fasten the two screws (removed in step 4.) LPC 10”/12” Series Quick Reference Guide...
- Page 6 LPC-15WD510 Step 8. Re-place back cover to finish 6 LPC-15WD510 Battery...
