- Page 1 LPC-08 Series 8” Multi-functional Touch Panel PC Quick Reference Guide Ed – May 2010 Copyright Notice Copyright © 2010 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E201708A1A1R...
-
Page 2: Table Of Contents
LPC-08 Series Contents Getting Started......................3 Safety Precautions ....................3 Packing List ......................3 System Specifications ...................4 System Overview....................6 1.4.1 Rear View............................. 6 1.4.2 Right View ............................ 6 System Dimensions....................7 1.5.1 LPC-08 Series..........................7 Hardware Configuration.....................8 Jumper and Connector Setting, Driver and BIOS Installing........8 Installing Memory ....................9 Installing CF Card....................10 Installing Hard Disk....................11... -
Page 3: Getting Started
Quick Reference Guide 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. -
Page 4: System Specifications
LPC-08 Series 1.3 System Specifications Panel Specifications LPC-08A1 LPC-0803 LCD size 8" Display type SVGA TFT Resolution 800 x 600 Color 262K 0.2025mm(H) x 0.2025mm(V) Pixel pitch 400 cd/m² Luminance Contrast ratio Viewing angle 55(U), 65(D), 65(L), 65(R) Response time... - Page 5 202.5 mm X 159.5 mm X 42.3 mm Dimensions (w/HDD 202.5 x 159.5 x 55 mm) Weight 1.38 Kgs (w/HDD 1.68Kgs) Note: 1. LPC-08A1 supports +10V~28V wide range power input. 2. Either RS-232 or RS-422/485 for COM2 only. LPC-08 Series Quick Reference Guide...
-
Page 6: System Overview
2 x USB connector (LPC-0803) Ethernet connector RJ-45 Line-out audio jack LINE OUT Power Power switch USB 2.0 connector CRT connector DB-15 female connector Note: The optional WiFi module will occupy one USB port for LPC-08A1. 6 LPC-08 Series Quick Reference Guide... -
Page 7: System Dimensions
Quick Reference Guide 1.5 System Dimensions 1.5.1 LPC-08 Series LPC-08 Series Quick Reference Guide... -
Page 8: Hardware Configuration
LPC-08 Series 2. Hardware Configuration 2.1 Jumper and Connector Setting, Driver and BIOS Installing Please refer to ECM-LX800D, ECM-945GSE Quick Installation Guide or User’s Manual for further information. Note: If you need more information, please visit our website: http://www.avalue.com.tw 8 LPC-08 Series Quick Reference Guide... -
Page 9: Installing Memory
Quick Reference Guide 2.2 Installing Memory Note: Memory installation is not for LPC-08A1 due to 512MB memory onboard. Step 1. Unfasten 6 screws to remove the bottom chassis. Step 2. Unlock 4 coppers from the rear I/O of VGA & COM ports. -
Page 10: Installing Cf Card
LPC-08 Series 2.3 Installing CF Card Step 1. Unlock 2 screws from the rear side of the panel PC as above. Step 2. Put the CF card into the socket and fasten 2 screws back. 10 LPC-08 Series Quick Reference Guide... -
Page 11: Installing Hard Disk
Quick Reference Guide 2.4 Installing Hard Disk Note: To install the HDD of LPC-08 series requires specific bottom chassis. Step 1. Unfasten 6 screws to remove the bottom chassis. LPC-08 Series Quick Reference Guide 11... - Page 12 LPC-08 Series Step 2. Lock 4 screws with HDD bracket and assemble 4 cushions. Step 3. Lock 4 screws to install the HDD into the bottom chassis. Step 4. Assemble the bottom chassis back as step 3 to step 1. 12 LPC-08 Series Quick Reference Guide...
