- Page 1 Getting Started Guide Version 1.0 Zynq -7000 All Programmable ® SoC / AD9361 Software-Defined Radio Evaluation Kit...
-
Page 2: Revision History
REVISION HISTORY DATE VERSION REVISION 11/07/2013 Initial Release \ LL 2 Getting Started with the Zynq -7000 All Programmable SoC / AD9361 Software-Defined Radio Evaluation Version 1.0 ®... -
Page 3: License Agreement
Upon completion, be sure to retain your login and password information for future visits to Avnet’s DRC. Logging in once, gives you unlimited access to all technical support files and downloads. You will also have the chance to request e-mail notifications whenever there are updates to your design kit. - Page 4 (collectively “Marks”) are the properties of their respective owners. Avnet disclaims any proprietary interest in Marks other than its own. Avnet and AV design logos are registered trademarks and service marks of Avnet, Inc. Avnet’s Marks may be used only with the prior written permission of Avnet, Inc. www.em.avnet.com 10.
-
Page 5: What's Inside The Box
2400 – 2500 MHz region, the kit is ideal for the RF engineer seeking optimized system performance meeting datasheet specifications in a defined range of RF spectrum. This Getting Started Guide will proceed through the steps to setup the Zynq-7000 AP SoC / AD9361 Software- Defined Radio Evaluation Kit and run the out-of-box demonstration. - Page 6 GETTING STARTED WITH ZYNQ SOFTWARE-DEFINED RADIO The Zynq-7000 All Programmable SoC / AD9361 Software-Defined Radio Evaluation Kit comes with a ‘Getting Started’ demonstration design flashed onto the SD card, which enables a single-board computer on the Avnet ZedBoard running UBUNTU desktop Linux. The system includes programmable logic-based interfaces and ARM- based Linux drivers for the Analog Devices AD9361 integrated RF Agile Transceiver on the FMC module.
-
Page 7: Demo Requirements
Demo Preparations a. Insert the SD Card into the ZedBoard. The 8 GB SD card is factory-programmed with the Zynq firmware, Linux kernel image, user-space application software and filesystem for a stand-alone bootable system. Figure 2: Insert the SD Card b. -
Page 8: Assembling The Hardware
Assembling the Hardware 1. Assemble as shown below: a. ZedBoard b. Analog Devices AD-FMCOMMS2-EBZ c. Antennas d. USB dongle (male micro-B to female standard-A) e. HDMI cable to display f. 12 V power supply Figure 5: Assembling the hardware for ‘Getting Started Demo’ 2. - Page 9 Figure 7: UBUNTU Desktop with Analog Devices IIO Oscilloscope b. From FMComms2 tab, set the following parameters, leaving all others at their default values. – TX LO Frequency = 2400 MHz Check that TX and RX LO frequencies match • –...
- Page 10 c. From the Capture tab, click ‘capture’ (triangle icon) to start data acquisition. – There are actually 2 tones of same frequency, generated by TX1 and TX2. Figure 9: Spectrum of Incoming ADC data d. Stop data capture and select the FMComms2 tab. –...
- Page 11 e. Return to the Capture tab. Click the triangle icon to start data acquisition. – Observe the 2 tones at different frequencies. Figure 11: Tones at Different Frequencies We now prepare to generate pre-defined waveforms from data files stored in the filesystem within the SD card. f.
- Page 12 g. From the adjacent pull-down menu: – From the waveforms folder, select the file ‘qpskwithfilt_30.72M.txt’ – Click ‘Open’ – Save settings Figure 13: Selecting the Waveform Data File h. Return to the Capture tab. – Active channels: select ‘in_voltage0’ and ‘in_voltage1’ –...
- Page 13 Congratulations! You have now run the Getting Started demonstration with the Zynq-7000 AP SoC / AD9361 Software-Defined Radio Evaluation Kit. Using this fully functional framework with embedded LINUX, you may now develop your wireless communications applications. Restoring the SD Card image...
- Page 14 5. Discover the disk number of the SD card device by using the list disk DiskPart command. In this example, the SD card device is enumerated as the Disk 1 device. DISKPART> list disk Figure 17: Listing the Enumerated Disk Devices 6.
- Page 15 10. Extract the image contents of the archive obtained from Step 1 above using an xz compatible utility such as 7-Zip. Figure 19: Extracting the Archived Image 11. Launch a disk imaging utility such as Win32 Disk Imager. Click on the folder icon adjacent to the Image File entry box and set the Save as type filter option to *.* in order to make the all file extensions visible.
- Page 16 12. Select the source image file zed_fmcomms2_image_8gb as well as the target drive device. In this example, the image is located in the C:\ADI\ folder and the target SD card is assigned to the J:\ drive. Figure 21: Source Image File Selected 13.
- Page 17 15. Use Windows “safely remove” to eject the SD card. Figure 23: Windows “safely remove” to eject the SD card 16. Replace the re-imaged SD card into ZedBoard. The Zynq-7000 SoC / AD9361 Software-Defined Radio Evaluation Kit is ready for operation with the latest SD card image.
- Page 18 Additional Documentation and Support To access the most current collateral for the Zynq-7000 SoC / AD9361 Software-Defined Radio Evaluation Kit please visit the product website: http://www.zedboard.org/product/zynq-sdr-ii-eval http://www.em.avnet.com/adizynqsdr2 To access the Avnet Technical Community Forums, please visit the following web page: http://www.zedboard.org/support...
-
Page 19: Next Steps
Download Zynq embedded system source files for this Getting Started demonstration design as a starting point for your system customization. http://wiki.analog.com/resources/eval/user-guides/ad-fmcomms2-ebz/reference_hdl Consult the Zynq-7000 SoC / AD9361 Software-Defined Radio Evaluation Kit product website for notification of technical training. • http://www.zedboard.org/product/zynq-sdr-ii-eval •... - Page 20 AVNET and the AV logo are registered trademarks of Avnet, Inc. GS-AES-ZSDR2-ADI-G-14.4-01...
