Summary of Contents for Amphenol Amphe-PRB
- Page 1 AI-21 Amphe-PRB Assembly Instructions Rev. Date Zone Description Owner 2023/10/8 Initial Release Bruce Lee...
-
Page 2: Table Of Contents
Contents Product Component ......................3-4 (1) Plug Connector: PRB06E24-BLS ................3 (2) Receptacle Connector: PRB07R24-BLP ..............4 Plug Connector Assembly ....................5-7 (1) Cable Processing ....................5 (2) Assembly Plug Connector ..................6-7 Receptacle Connector Assembly ..................8-10 (1) Cable Processing ....................8 (2) Assembly Receptacle Connector ................ -
Page 3: Product Component
Product Component (1) Plug Connector: PRB06E24-BLS Position Description Gasket Plug Shell RDS SKT Contact Washer, Waved Coupling Nut O-Ring Adapter Rubber Sleeve Screw Nut... -
Page 4: Receptacle Connector: Prb07R24-Blp
Product Component (2) Receptacle Connector: PRB07R24-BLP Position Description Hex Nut Panel Gasket Receptacle Shell Pin Contact... -
Page 5: Plug Connector Assembly
Plug Connector Assembly (1) Cable Processing Step 1) Slide the Screw Nut and adapter through the cable in sequence. Screw Nut Screw Nut Adapter Adapter Screw Nut Adapter Figure 1 13 mm Step 2) Strip the cable outer jacket to 57-60 mm. 57-60 mm 57-60 mm 57-60 mm... -
Page 6: Assembly Plug Connector
Plug Connector Assembly (2) Assembly Plug Connector Step 1) Install the contact to the plug shell hole. ew Nut Figure 5 Figure 6 Screw Nut Adapter... - Page 7 Plug Connector Assembly (2) Assembly Plug Connector Step 2) Tighten the adapter and screw nut separately, finish the assembly. Screw Nut Adapter Figure 7 Recommended Torque Value Component Torque Value (N · m) Adapter 6 ~ 7 Screw Nut 5 ~ 6...
-
Page 8: Receptacle Connector Assembly
Receptacle Connector Assembly (1) Cable Processing Step 1) Strip the wire outer jacket to 12~13 mm. 12~13 mm 12~13 mm Figure 8 Step 2) Contact Crimping. Figure 9... -
Page 9: Assembly Receptacle Connector
12~13 mm Receptacle Connector Assembly (2) Assembly Receptacle Connector Panel Step 1) Install the contact to the receptacle shell hole. Hex Nut Figure 10 Figure 11... - Page 10 Receptacle Connector Assembly Panel (2) Assembly Receptacle Connector Step 2) Let the receptacle connector through the panel hole and tighten the hex nut, finish the assembly. Recommended hex nut torque value is 5~5.5 Nm. Panel Hex Nut Figure 12 Figure 13...
