AETEK H42-042-91-150 Quick Installation Manual

PACKAGE CONTENTS
* 1x PoE switch
* 1x T25 L-wrench
IMPORTANT:
1. Install the PoE switch in a ventilated and dry place that is free of electromagnetic source, vibration, moisture, and dust.
2. Make sure the ventilation openings on the switch are not blocked.
3. Use CAT5 or 5e UTP/STP cables.
4. AC input (100~240V/AC, 50~60Hz).
5. IP67 rated housing
6. Although housing is IP67 rating , this is not suitable for water jets.
CONNECTION
Industrial 2xGbE PoE+2xGbE 24V/56V PoE+2xGbE SFP Switch
48-56VDC
INPUT
PWR2
POWER
Port 1~2
GbE RJ45
PoE Port
AC on/off
Port 1-2:
switch
Power Pin
Assignment
H42-042-91-150
Quick Installation Guide
* 1x Quick Installation Guide
Port 3 Port 4
Port 3~4
GbE RJ45
24V/56VDC PoE Port
Port 3-4:
100~240VAC
Power Pin
power input
Assignment
Outdoor PoE Switch
12V 24V
PWR1 PWR2
Port 5-6
GbE SFP ports
P/N: 5019050500
Port 3,4 DIP Switch Setting
2-pair 56VDC 4-pair 56VDC
2-pair 24VDC 4-pair 24VDC
No Passive PoE Output
No Power Output
12VDC / 24VDC Port Dip Switch
12VDC ON 24VDC ON
12V
12VDC OFF 24VDC OFF
24V
LED Status
24V 56V 2P 4P 24V 56V 2P 4P 12V 24V
