HPM-GNRDE
Dual Intel® Xeon® 6 Processor EATX Server Board
with IPMI2.0. Processor supports up to 350W TDP
User's Manual
Ed – 23 April 2025
st
1
Copyright Notice
Copyright © 2025 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No: E2047E5S000R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HPM-GNRDE and is the answer not in the manual?

Questions and answers

Related Manuals for Avalue Technology HPM-GNRDE

Summary of Contents for Avalue Technology HPM-GNRDE

  • Page 1 HPM-GNRDE Dual Intel® Xeon® 6 Processor EATX Server Board with IPMI2.0. Processor supports up to 350W TDP User’s Manual Ed – 23 April 2025 Copyright Notice Copyright © 2025 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No: E2047E5S000R...

  • Page 2: Document Amendment History

    HPM-GNRDE User’s Manual Document Amendment History Revision Date Comment April 2025 Avalue Initial Release 2 HPM-GNRDE User’s Manual...

  • Page 3: Declaration Of Conformity

    For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2025 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc.
  • Page 4 ㆍDescription of your software (operating system, version, application software, etc.) ㆍA complete description of the problem ㆍThe exact wording of any error messages To receive the latest version of the user’s manual; please visit our Web site at: www.avalue.com 4 HPM-GNRDE User’s Manual...
  • Page 5 On the other hand, if the new product defect is resulting from incorrect configuration or erroneous use by the user instead of any problem of the hardware itself, the customer will also be requested to pay for relevant handling fees. HPM-GNRDE User’s Manual...
  • Page 6 Lacking detailed statement of fault steps also makes the problem hard to be identified, sometimes resulting in second-time repairs. 6 HPM-GNRDE User’s Manual...
  • Page 7 • Product has been altered or its label of the serial number has been torn off. • Product functionality issues resulting from improper use by the user, unauthorized dismantle or alteration, unfit operation environment, improper maintenance, accident HPM-GNRDE User’s Manual...
  • Page 8 If the customer demands an additional maintenance analysis report, a service fee of various level will be charged depending on the warranty status. In case the analysis result shows that the defect attributes to Avalue’s faulty design or process, the analysis fee will be exempted. 8 HPM-GNRDE User’s Manual...
  • Page 9 CPU, memory, HDD, SSD, storage devices; also replacements motherboards of systems. Please contact Avalue sales for details to evaluate the possibility of system upgrade service and obtain information of lead time and price. HPM-GNRDE User’s Manual...

  • Page 10: Explanation Of Graphical Symbols

    A NOTE provides additional information intended to avoid Note inconveniences during operation. Direct current. Alternating current Stand-by, Power on FCC Certification CE Certification Follow the national requirements for disposal of equipment. Stacking layer limit This side up 10 HPM-GNRDE User’s Manual...
  • Page 11 User’s Manual Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. HPM-GNRDE User’s Manual 11...

  • Page 12: Disposing Of Your Old Product

    EXPLOSION ou une fuite de liquide ou de gaz inflammable. - UNE BATTERIE soumise à une pression d'air extrêmement basse pouvant entraî ner une EXPLOSION ou une fuite de liquide ou de gaz inflammable. 12 HPM-GNRDE User’s Manual...

  • Page 13: Table Of Contents

    2.3.23 USB3.1 Gen1 connector (JUSB2) ..................... 44 2.3.24 Front Panel connector (JFP1) ....................44 2.3.25 Inlet Thermal Sensor (JINLET_SER1) ..................45 2.3.26 Outlet Thermal Sensor (JOUTLET_SER1) ................45 2.3.27 HDD Backplane thermal Sensor (JHDD_SER1) ............... 46 HPM-GNRDE User’s Manual 13...
  • Page 14 IBL-IO Configuration ......................67 4.6.3.2 Miscellaneous Configuration ....................68 4.6.4 Socket Config ..........................69 4.6.4.1 Processor Configuration ......................69 4.6.4.2 Memory Configuration ......................70 4.6.4.2.1 Memory Topology ........................71 4.6.4.2.2 Memory RAS Configuration ....................71 4.6.4.3 IIO Configuration........................72 14 HPM-GNRDE User’s Manual...
  • Page 15 Port A ~ Port H ....................... 96 4.6.4.3.2.6 PCI Express 5 ........................97 4.6.4.3.2.6.1 Intel VMD technology ..................... 98 4.6.4.3.2.6.2 Port A ~ Port H ....................... 98 4.6.4.3.3 Global Configuration ......................99 4.6.4.3.4 Intel VMD technology ......................99 HPM-GNRDE User’s Manual 15...
  • Page 16 Save Changes ........................117 4.6.8.6 Discard Changes ......................... 117 4.6.8.7 Restore Defaults ........................117 4.6.8.8 Save as User Defaults ......................117 4.6.8.9 Restore User Defaults ......................117 5. Mechanical Drawing ....................118 6. Maintenance & Troubleshooting ................120 16 HPM-GNRDE User’s Manual...

  • Page 17: Getting Started

    électrostatique. Placez tous les composants électroniques sur une surface antistatique ou dans un sac antistatique quand ils ne sont pas dans le châssis. Risque d'explosion si la batterie est remplacée par un type incorrect. Jetez les piles usagées selon les instructions HPM-GNRDE User’s Manual 17...

  • Page 18: Packing List

    1.2 Packing List Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty HPM-GNRDE motherboard I/O Shield LGA4710 CPU carrier-E2B 18 HPM-GNRDE User’s Manual...

  • Page 19: Manual Objectives

    We strongly recommend that you study this manual carefully before attempting to set up HPM-GNRDE or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance.

  • Page 20: System Specifications

    2 x Mini-SAS HD 4i (for 4x SATA Only) 1 x 7pin SATA connector 4 x Slim SAS 8i (SFF-8654) connector (from 1st CPU) Other 3 x MCIO x8 connectors (SFF-TA-1016) (from 2nd CPU) Edge I/O 1 x DB-9 male connector 20 HPM-GNRDE User’s Manual...
  • Page 21 6 x 4 Pin Chassis Fan Header (4 Pin PWM, 2 for front fans and 4 for rear fans) Buzzer 1 x onboard buzzer 1 x front panel connector (2.54 mm Pitch) Function Function Front Panel HDD LED POWER LED RESET BUTTON POWER BUTTON 9-11 STATUS LED 10-12 LAN1 ACT LED HPM-GNRDE User’s Manual 21...
  • Page 22 2 x Intel I210AT 1GbE controller LAN Chipset 1 x Intel E610-XAT2 10GbE controller supports 2 x 10GbE Ethernet ports 2 x 1G Base-T Ethernet Controller LAN Spec. 1 x Dual 10G Base-T Ethernet controller 1G LAN: LED Indicator 10G LAN: 22 HPM-GNRDE User’s Manual...
  • Page 23 B. System Error. Power Condition Memo FAN status Indicator Power off System always Failed System boot failed/VGA is not ready BIOS ready to boot VGA is ready. (Informed by BIOS) Blinking BIOS initializing Blinking (BMC to implement) HPM-GNRDE User’s Manual 23...
  • Page 24 System condition : Non-Operation mode IEC 60068-2-64 Test:Fh Package Vibration Test: Reference IEC60068-2-64 Testing procedures Test PSD : 0.026G²/Hz , 2.16 Grms Non-operation mode Test frequency : 5~500 Hz Test axis : X,Y and Z axis 24 HPM-GNRDE User’s Manual...
  • Page 25 3 Package weight : 5Kg 4 Test drawing Windows 11 SAC and LTSC Windows Server 2025. OS Information Ubuntu 24.02 Red Hat Enterprise Linux (RHEL) 8.0 or above Note: Specifications are subject to change without notice. HPM-GNRDE User’s Manual 25...
  • Page 26 DIMM8 CPU1 CH-H DIMM0 DIMM9 CPU2 CH-A DIMM0 DIMM10 CPU2 CH-B DIMM0 DIMM11 CPU2 CH-C DIMM0 DIMM12 CPU2 CH-D DIMM0 DIMM13 CPU2 CH-E DIMM0 DIMM14 CPU2 CH-F DIMM0 DIMM15 CPU2 CH-G DIMM0 DIMM16 CPU2 CH-H DIMM0 26 HPM-GNRDE User’s Manual...

  • Page 27: Architecture Overview-Block Diagram

    User’s Manual 1.5 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of HPM-GNRDE. HPM-GNRDE User’s Manual 27...

  • Page 28: Hardware Configuration

    HPM-GNRDE User’s Manual 2. Hardware Configuration 28 HPM-GNRDE User’s Manual...

  • Page 29: Product Overview

    User’s Manual 2.1 Product Overview HPM-GNRDE User’s Manual 29...

  • Page 30: Jumper And Connector List

    CPU fan connector 1-2 4 x 1 wafer, pitch 2.54mm Serial port 1 connector VGA_COM1 VGA connector JCOM2 Serial port 2 connector 5 x 2 wafer, pitch 2.00mm JCOM5 BMC_UART5 debug connector 4 x 1 header, pitch 2.54mm 30 HPM-GNRDE User’s Manual...
  • Page 31 4 x 1 wafer, pitch 2.00mm JOUTLET_SER1 Outlet Thermal Sensor 4 x 1 wafer, pitch 2.00mm JHDD_SER1 HDD Backplane thermal Sensor 5 x 1 wafer, pitch 2.00mm JPEHPSMB1 CPU PCIE HP SMB connector 5 x 1 header, pitch 2.00mm HPM-GNRDE User’s Manual 31...
  • Page 32 2 x M.2 M-Key PCIe 5.0 x4 NVMe SSD JCPLD_JTAG1 CPLD JTAG header 5 x 2 header, pitch 2.54mm MCIO1-3 3 x MCIO x8 connectors (SFF-TA-1016) JPMFG1 MFG mode select 3 x 1 header, pitch 2.00mm 32 HPM-GNRDE User’s Manual...

  • Page 33: Setting Jumpers & Connectors

    User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 Force PWRON setting (JPALLPWRON1) Disable* Enable * Default 2.3.2 Clear CMOS (JPCMOSCLEAR1) Normal RTC Reset* Clear RTC REGISTERS * Default HPM-GNRDE User’s Manual 33...

  • Page 34: Boot Uart5 Setting (Jpboot_Uart5)

    HPM-GNRDE User’s Manual 2.3.3 Boot UART5 setting (JPBOOT_UART5) Disable* Enable BOOT FROM UART5 * Default 2.3.4 CPLD JTAG header (JCPLD_JTAG1) Signal PIN PIN Signal +3.3VSB JTAG_TDI_CONN JTAG_TMS_CONN +3.3VSB JTAG_TDO_CONN CPLD_JTAG_MUX_CTL JTAG_TCK_CONN 34 HPM-GNRDE User’s Manual...

  • Page 35: System Fan Connector 1 (Sys_Fan1)

    User’s Manual 2.3.5 System fan connector 1 (SYS_FAN1) Signal SYS_PWM1 FAN_R2_TACH1 +12V 2.3.6 System fan connector 2 (SYS_FAN2) Signal SYS_PWM2 FAN_R2_TACH2 +12V HPM-GNRDE User’s Manual 35...

  • Page 36: System Fan Connector 3 (Sys_Fan3)

    HPM-GNRDE User’s Manual 2.3.7 System fan connector 3 (SYS_FAN3) Signal SYS_PWM3 FAN_R2_TACH3 +12V 2.3.8 System fan connector 4 (SYS_FAN4) Signal SYS_PWM4 FAN_R2_TACH4 +12V 36 HPM-GNRDE User’s Manual...

  • Page 37: System Fan Connector 5 (Sys_Fan5)

    User’s Manual 2.3.9 System fan connector 5 (SYS_FAN5) Signal +12V FAN_R2_TACH5 SYS_PWM5 2.3.10 System fan connector 6 (SYS_FAN6) Signal +12V FAN_R2_TACH6 SYS_PWM6 HPM-GNRDE User’s Manual 37...

  • Page 38: Cpu Fan Connector 1 (Cpu_Fan1)

    HPM-GNRDE User’s Manual 2.3.11 CPU fan connector 1 (CPU_FAN1) Signal +12V FAN_R2_TACH0 CPU0_PWM 2.3.12 CPU fan connector 2 (CPU_FAN2) Signal +12V FAN_R2_TACH7 CPU1_PWM 38 HPM-GNRDE User’s Manual...

  • Page 39: Spi Connector (Jspi1)

    User’s Manual 2.3.13 SPI connector (JSPI1) Signal PIN PIN Signal SPI_DED_IO2 SPI_DED_IO3 SPI_DED_MOSI SPI_ DED_MISO SPI_DED_CLK SPI_ DED_CS0_N ON_BIOS_SPI_VCC 2.3.14 Serial port 2 connector (JCOM2) Signal PIN PIN Signal COM_RXD2 COM_DCD#2 COM_DTR#2 COM_TXD2 COM_DSR#2 COM_CTS#2 COM_RTS#2 COM_RI#2 HPM-GNRDE User’s Manual 39...

  • Page 40: Bmc_Uart5 Debug Connector (Jcom5)

    HPM-GNRDE User’s Manual 2.3.15 BMC_UART5 debug connector (JCOM5) Signal UART5_TX UART5_RX +3.3VSB 2.3.16 ATX 12V power connector 1 (ATX12V1) Signal Signal +12V +12V +12V +12V 40 HPM-GNRDE User’s Manual...

  • Page 41: Atx 12V Power Connector 2 (Atx12V2)

    User’s Manual 2.3.17 ATX 12V power connector 2 (ATX12V2) Signal Signal +12V +12V +12V +12V 2.3.18 ATX 12V power connector 3 (ATX12V3) Signal Signal +12V +12V +12V +12V HPM-GNRDE User’s Manual 41...

  • Page 42: Atx 12V Power Connector 4 (Atx12V4)

    HPM-GNRDE User’s Manual 2.3.19 ATX 12V power connector 4 (ATX12V4) Signal Signal +12V +12V +12V +12V 2.3.20 ATX power connector (ATXPWR1) Signal PIN PIN Signal +3.3V +3.3V -12V +3.3V FM_PS_EN_ PSU_N PWRGD_PS_ PWROK_R +V5SB +12V +12V +3.3V 42 HPM-GNRDE User’s Manual...

  • Page 43: Power Supply Pmbus Connector (Jpmbus1)

    User’s Manual 2.3.21 Power supply PMBus connector (JPMBUS1) Signal PSU_z_SCL PSU_z_SDA PSU_ALERT_z_N 2.3.22 USB3.1 Gen1 connector (JUSB1) Signal PIN PIN Signal +V5S_USB_FRONT1 +V5S_USB_FRONT1 USB3_z_RN6 USB3_z_RN7 USB3_z_RP6 USB3_z_RP7 USB3_z_TN6 USB3_z_TN7 USB3_z_TP6 USB3_z_TP7 USB_z_PN6 USB_z_PN7 USB_z_PP6 USB_z_PP7 FRONTUSB3_OC1_N HPM-GNRDE User’s Manual 43...

  • Page 44: Usb3.1 Gen1 Connector (Jusb2)

    USB3_z_TN8 USB3_z_TN9 USB3_z_TP8 USB3_z_TP9 USB_z_PN8 USB_z_PN9 USB_z_PP8 USB_z_PP9 FRONTUSB3_OC2_N 2.3.24 Front Panel connector (JFP1) Signal PIN PIN Signal +3.3VSB HDD_LED_P PWRLED_R_N LED_HDD_ACTIVITY_B_N FP_PWR_BTN_N_R FP_RST_BTN_N_R LAN1_FRONT_LED_ACT_P 10 STATUS_LED_P LAN1_LED_ACT_N STATUS_LED_N SBPWRLED_P FRONT_UID_LED_N FRONT_UID_LED_P LAN2_FRONT_LED_ACT_P 18 FP_UID_BTN_N_R LAN2_LED_ACT_N 44 HPM-GNRDE User’s Manual...

  • Page 45: Inlet Thermal Sensor (Jinlet_Ser1)

    User’s Manual 2.3.25 Inlet Thermal Sensor (JINLET_SER1) Signal +3.3VSB SMB_INLET_TEMPSENSOR_SDA SMB_INLET_TEMPSENSOR_SCL 2.3.26 Outlet Thermal Sensor (JOUTLET_SER1) Signal SMB_OUTLET_TEMPSENSOR_SCL SMB_OUTLET_TEMPSENSOR_SDA +3.3VSB HPM-GNRDE User’s Manual 45...

  • Page 46: Hdd Backplane Thermal Sensor (Jhdd_Ser1)

    HPM-GNRDE User’s Manual 2.3.27 HDD Backplane thermal Sensor (JHDD_SER1) Signal SSD_LED_N SMB_HDBP_TEMPSENSOR_SCL SMB_HDBP_TEMPSENSOR_SDA +3.3VSB 2.3.28 CASE OPEN connector (JCASE_OPEN1) Signal FP_CHASSIS_INTRUSION 46 HPM-GNRDE User’s Manual...

  • Page 47: Vroc Header (Jraid_Key1)

    User’s Manual 2.3.29 VROC Header (JRAID_KEY1) Signal PU_VROC_HW_KEY_CONN_PIN2_R PU_VROC_HW_KEY_R_LVC3 2.3.30 CPU PCIE HP SMB connector (JPEHPSMB1) Signal FM_SMB_CPU0_ALERT_N SMB_PEHPCPU0_LVC3_SDA SMB_PEHPCPU0_LVC3_SCL HPM-GNRDE User’s Manual 47...

  • Page 48: Espi Connector (Jespi1)

    HPM-GNRDE User’s Manual 2.3.31 ESPI connector (JESPI1) Signal PIN PIN Signal 11 ESPI_CONN_RESET_P1V8_N ESPI_CONN_ALERT_P1V8_N ESPI_CONN_CLK_P1V8 ESPI_CONN_D3_P1V8 ESPI_CPU0_CS_HDR_N ESPI_CONN_D2_P1V8 RST_PLTRST_LPC_HEADER_N ESPI_CONN_D1_P1V8 +3.3VSB ESPI_CONN_D0_P1V8 2.3.32 NMI button (JNMI_BTN1) Signal FP_NMI_BTN_N_R 48 HPM-GNRDE User’s Manual...

  • Page 49: Drivers Installation

    HID touch digitizer built-in driver in Windows 7 or later. (For reference only) Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. HPM-GNRDE User’s Manual 49...

  • Page 50: Install Chipset Driver

    Windows 11 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Install. Step1. Click Next. Step 4. Click Finish to complete setup. Step 2. Click Accept. 50 HPM-GNRDE User’s Manual...

  • Page 51: Install Vga Driver

    Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Setup completed. Step 2. Click Next. HPM-GNRDE User’s Manual 51...

  • Page 52: Install Ethernet Driver

    All drivers can be found on the Avalue Official Website: www.avalue.com. Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 1. Click OK to continue installation. Step 2. Setup completed. 52 HPM-GNRDE User’s Manual...

  • Page 53: Install Quickassist Technology Driver

    Windows 11 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Install. Step 2. Click Next. Step 5. Click Finish to complete setup. HPM-GNRDE User’s Manual 53...

  • Page 54: Install Vroc Driver

    Note: The installation procedures and screen shots in this section are based on Windows 11 operation system. Step 3. Click Accept. Step 1. Click Install to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Next. 54 HPM-GNRDE User’s Manual...
  • Page 55 User’s Manual Step 6. Click Install. Step 7. Click Continue. Step 8. Setup completed. HPM-GNRDE User’s Manual 55...

  • Page 56: Bios Setup

    HPM-GNRDE User’s Manual 4.BIOS Setup 56 HPM-GNRDE User’s Manual...

  • Page 57: Introduction

    If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. HPM-GNRDE User’s Manual 57...

  • Page 58: Using Setup

    Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “➢” pointer marks all sub menus. 58 HPM-GNRDE User’s Manual...

  • Page 59: Getting Help

    BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. HPM-GNRDE User’s Manual 59...

  • Page 60: Bios Setup

    Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com) to download the latest product and BIOS information. 60 HPM-GNRDE User’s Manual...

  • Page 61: Advanced Menu

    This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. Options Description DQV mode[Default] Expert mode Switch Expert mode or DQV mode. Expert mode 4.6.2.1 Trusted Computing HPM-GNRDE User’s Manual 61...

  • Page 62: Ast2600 Super Io Configuration

    TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated. 4.6.2.2 AST2600 Super IO Configuration Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). 62 HPM-GNRDE User’s Manual...

  • Page 63: Serial Port 1 Configuration

    User’s Manual 4.6.2.2.1 Serial Port 1 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 4.6.2.3 Serial Port Console Redirection Item Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled HPM-GNRDE User’s Manual 63...

  • Page 64: Option Rom Dispatch Policy

    Enable or Disable Option ROM execution for Slot#4 Empty Disabled selected Slot. Enabled[Default], Enable or Disable Option ROM execution for Slot#5 Empty Disabled selected Slot. Enabled[Default], Enable or Disable Option ROM execution for Slot#6 Empty Disabled selected Slot. 64 HPM-GNRDE User’s Manual...

  • Page 65: Usb Configuration

    Mass storage device emulation type. ‘AUTO’ Auto[Default] Floppy enumerates devices according to their media Mass Storage Devices Forced FDD format. Optical drives are emulated as ‘CDROM’, drives with no media will be Hard Disk CD-ROM emulated according to a drive type. HPM-GNRDE User’s Manual 65...

  • Page 66: Network Stack Configuration

    HPM-GNRDE User’s Manual 4.6.2.6 Network Stack Configuration Item Option Description Enabled Network stack Enable/Disable UEFI Network Stack. Disabled[Default] 4.6.2.7 NVMe Configuration 66 HPM-GNRDE User’s Manual...

  • Page 67: Platform Config

    Specify what state to go to when power is State After G3 S5 State[Default] re-applied after a power failure (G3 state). After Type 8 Global Reset Last Disabled[Default] Specify whether platform’s previous state State Enabled will be considered when deternining HPM-GNRDE User’s Manual 67...

  • Page 68: Miscellaneous Configuration

    Miscellaneous Configuration Item Option Description Auto[Default] Select active Video type. Onboard Device(BMC Early display always output to BMC-VGA. Active Video VGA) BIOS P.O.S.T display output to PCIe if system PCIE Device have discrete GPU with Option Auto/PCIe-Device. 68 HPM-GNRDE User’s Manual...

  • Page 69: Socket Config

    Processor Configuration Item Option Description All LPs[Default] Enables Logical processor (Software Method o Enable LP [Global] Single LP Enable/Disable Logical Processor threads). Two LPs Skip Flex Ratio Override Disabled[Default] Skip Flex Ratio override to use power-on default HPM-GNRDE User’s Manual 69...

  • Page 70: Memory Configuration

    Maximum Memory Frequency Selections in 3600 MT/s. If Enforce POR is disabled, user will 4000 Memory Frequency be able to run at higher frequencies than 4400 the memory suppot (limited by processor 4800 support). Do not select Reserved. 5200 5600 70 HPM-GNRDE User’s Manual...

  • Page 71: Memory Topology

    Disabled[Default] Mirror Mode enable the required size of memory to be mirrored. Full Mirror Mode If rank sparing is enabled partial mirroring will not take effect. Enabling any type of Mirror Mode will disable XPT Prefetch. HPM-GNRDE User’s Manual 71...

  • Page 72: Iio Configuration

    HPM-GNRDE User’s Manual Disabled[Default] Imitate behavior of UEFI based Address Range UEFI ARM Mirror Enabled Mirror with setup option. Disabled[Default] Mirror TAD0 Enable Mirror on entire memory for TAD0. Enabled 4.6.4.3 IIO Configuration 4.6.4.3.1 Socket0 Configuration 72 HPM-GNRDE User’s Manual...

  • Page 73: Pci Express 0

    Select PCIe port Bifurcation for selected slot(s) x2x2x2x2x_x8 Port Format: xGxExCxA The port can further be x2x2x2x2x4x4 Bifurcation x2x2 Disable-disable all PCIe Lanes and the x2x2x4x2x2x4 controller. x4x2x2x2x2x4 x2x2x2x2x2x2x4 x_x8x4x2x2 x4x4x4x2x2 x_x8x2x2x2x2 x2x2x4x4x2x2 x4x2x2x4x2x2 x4x4x2x2x2x2 x2x2x2x2x4x2x2 x2x2x4x2x2x2x2 x4x2x2x2x2x2x2 x2x2x2x2x2x2x2x2 HPM-GNRDE User’s Manual 73...

  • Page 74: Intel Vmd Technology

    HPM-GNRDE User’s Manual 4.6.4.3.1.1.1 Intel VMD technology Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled 4.6.4.3.1.1.2 Port A ~ Port H 74 HPM-GNRDE User’s Manual...
  • Page 75 . Advanced user may use ‘Force Enable’ option to enforce enabling 10-bit Tag in a hierarchy wherer Root Port is 10-bit Tag Completer capable, but not all nodes support 10-bit Tag Completer. The user HPM-GNRDE User’s Manual 75...

  • Page 76: Pci Express 1

    4.6.4.3.1.2 PCI Express 1 Item Option Description Auto[Default] Select PCIe port Bifurcation for selected slot(s) x4x4x4x4 Bifurcation Port Format: xGxExCxA The port can further be x4x4x_x8 x2x2 Disable-disable all PCIe Lanes and the x_x8x4x4 76 HPM-GNRDE User’s Manual...

  • Page 77: Intel Vmd Technology

    4.6.4.3.1.2.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled HPM-GNRDE User’s Manual 77...

  • Page 78: Port A ~ Port H

    Please refer to 4.6.4.3.1.1.2 for more information. 4.6.4.3.1.3 PCI Express 2 Item Option Description Select PCIe port Bifurcation for selected slot(s) Auto[Default] x4x4x4x4 Bifurcation Port Format: xGxExCxA The port can further be x4x4x_x8 x2x2 Disable-disable all PCIe Lanes and the 78 HPM-GNRDE User’s Manual...

  • Page 79: Intel Vmd Technology

    4.6.4.3.1.3.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled HPM-GNRDE User’s Manual 79...

  • Page 80: Port A ~ Port H

    Please refer to 4.6.4.3.1.1.2 for more information. 4.6.4.3.1.4 PCI Express 3 Item Option Description Select PCIe port Bifurcation for selected slot(s) Auto[Default] x4x4x4x4 Bifurcation Port Format: xGxExCxA The port can further be x4x4x_x8 x2x2 Disable-disable all PCIe Lanes and the 80 HPM-GNRDE User’s Manual...

  • Page 81: Intel Vmd Technology

    4.6.4.3.1.4.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled HPM-GNRDE User’s Manual 81...

  • Page 82: Port A ~ Port H

    Please refer to 4.6.4.3.1.1.2 for more information. 4.6.4.3.1.5 PCI Express 4 Item Option Description Select PCIe port Bifurcation for selected slot(s) Auto[Default] x4x4x4x4 Bifurcation Port Format: xGxExCxA The port can further be x4x4x_x8 x2x2 Disable-disable all PCIe Lanes and the 82 HPM-GNRDE User’s Manual...

  • Page 83: Intel Vmd Technology

    4.6.4.3.1.5.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled HPM-GNRDE User’s Manual 83...

  • Page 84: Port A ~ Port H

    Please refer to 4.6.4.3.1.1.2 for more information. 4.6.4.3.1.6 PCI Express 5 Item Option Description Select PCIe port Bifurcation for selected slot(s) Auto[Default] x4x4x4x4 Bifurcation Port Format: xGxExCxA The port can further be x4x4x_x8 x2x2 Disable-disable all PCIe Lanes and the 84 HPM-GNRDE User’s Manual...

  • Page 85: Intel Vmd Technology

    4.6.4.3.1.6.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled HPM-GNRDE User’s Manual 85...

  • Page 86: Port A ~ Port H

    HPM-GNRDE User’s Manual 4.6.4.3.1.6.2 Port A ~ Port H Please refer to 4.6.4.3.1.1.2 for more information. 4.6.4.3.2 Socket1 Configuration 86 HPM-GNRDE User’s Manual...

  • Page 87: Pci Express 0

    Select PCIe port Bifurcation for selected slot(s) x2x2x2x2x_x8 Port Format: xGxExCxA The port can further be x2x2x2x2x4x4 Bifurcation x2x2 Disable-disable all PCIe Lanes and the x2x2x4x2x2x4 controller. x4x2x2x2x2x4 x2x2x2x2x2x2x4 x_x8x4x2x2 x4x4x4x2x2 x_x8x2x2x2x2 x2x2x4x4x2x2 x4x2x2x4x2x2 x4x4x2x2x2x2 x2x2x2x2x4x2x2 x2x2x4x2x2x2x2 x4x2x2x2x2x2x2 x2x2x2x2x2x2x2x2 HPM-GNRDE User’s Manual 87...

  • Page 88: Intel Vmd Technology

    HPM-GNRDE User’s Manual 4.6.4.3.2.1.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled 4.6.4.3.2.1.2 Port A ~ Port H Please refer to 4.6.4.3.1.1.2 for more information. 88 HPM-GNRDE User’s Manual...

  • Page 89: Pci Express 1

    Select PCIe port Bifurcation for selected slot(s) x2x2x2x2x_x8 Port Format: xGxExCxA The port can further be x2x2x2x2x4x4 Bifurcation x2x2 Disable-disable all PCIe Lanes and the x2x2x4x2x2x4 controller. x4x2x2x2x2x4 x2x2x2x2x2x2x4 x_x8x4x2x2 x4x4x4x2x2 x_x8x2x2x2x2 x2x2x4x4x2x2 x4x2x2x4x2x2 x4x4x2x2x2x2 x2x2x2x2x4x2x2 x2x2x4x2x2x2x2 x4x2x2x2x2x2x2 x2x2x2x2x2x2x2x2 HPM-GNRDE User’s Manual 89...

  • Page 90: Intel Vmd Technology

    HPM-GNRDE User’s Manual 4.6.4.3.2.2.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled 4.6.4.3.2.2.2 Port A ~ Port H Please refer to 4.6.4.3.1.1.2 for more information. 90 HPM-GNRDE User’s Manual...

  • Page 91: Pci Express 2

    Select PCIe port Bifurcation for selected slot(s) x2x2x2x2x_x8 Port Format: xGxExCxA The port can further be x2x2x2x2x4x4 Bifurcation x2x2 Disable-disable all PCIe Lanes and the x2x2x4x2x2x4 controller. x4x2x2x2x2x4 x2x2x2x2x2x2x4 x_x8x4x2x2 x4x4x4x2x2 x_x8x2x2x2x2 x2x2x4x4x2x2 x4x2x2x4x2x2 x4x4x2x2x2x2 x2x2x2x2x4x2x2 x2x2x4x2x2x2x2 x4x2x2x2x2x2x2 x2x2x2x2x2x2x2x2 HPM-GNRDE User’s Manual 91...

  • Page 92: Intel Vmd Technology

    HPM-GNRDE User’s Manual 4.6.4.3.2.3.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled 4.6.4.3.2.3.2 Port A ~ Port H Please refer to 4.6.4.3.1.1.2 for more information. 92 HPM-GNRDE User’s Manual...

  • Page 93: Pci Express 3

    Select PCIe port Bifurcation for selected slot(s) x2x2x2x2x_x8 Port Format: xGxExCxA The port can further be x2x2x2x2x4x4 Bifurcation x2x2 Disable-disable all PCIe Lanes and the x2x2x4x2x2x4 controller. x4x2x2x2x2x4 x2x2x2x2x2x2x4 x_x8x4x2x2 x4x4x4x2x2 x_x8x2x2x2x2 x2x2x4x4x2x2 x4x2x2x4x2x2 x4x4x2x2x2x2 x2x2x2x2x4x2x2 x2x2x4x2x2x2x2 x4x2x2x2x2x2x2 x2x2x2x2x2x2x2x2 HPM-GNRDE User’s Manual 93...

  • Page 94: Intel Vmd Technology

    HPM-GNRDE User’s Manual 4.6.4.3.2.4.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled 4.6.4.3.2.4.2 Port A ~ Port H Please refer to 4.6.4.3.1.1.2 for more information. 94 HPM-GNRDE User’s Manual...

  • Page 95: Pci Express 4

    Select PCIe port Bifurcation for selected slot(s) x2x2x2x2x_x8 Port Format: xGxExCxA The port can further be x2x2x2x2x4x4 Bifurcation x2x2 Disable-disable all PCIe Lanes and the x2x2x4x2x2x4 controller. x4x2x2x2x2x4 x2x2x2x2x2x2x4 x_x8x4x2x2 x4x4x4x2x2 x_x8x2x2x2x2 x2x2x4x4x2x2 x4x2x2x4x2x2 x4x4x2x2x2x2 x2x2x2x2x4x2x2 x2x2x4x2x2x2x2 x4x2x2x2x2x2x2 x2x2x2x2x2x2x2x2 HPM-GNRDE User’s Manual 95...

  • Page 96: Intel Vmd Technology

    HPM-GNRDE User’s Manual 4.6.4.3.2.5.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled 4.6.4.3.2.5.2 Port A ~ Port H Please refer to 4.6.4.3.1.1.2 for more information. 96 HPM-GNRDE User’s Manual...

  • Page 97: Pci Express 5

    Select PCIe port Bifurcation for selected slot(s) x2x2x2x2x_x8 Port Format: xGxExCxA The port can further be x2x2x2x2x4x4 Bifurcation x2x2 Disable-disable all PCIe Lanes and the x2x2x4x2x2x4 controller. x4x2x2x2x2x4 x2x2x2x2x2x2x4 x_x8x4x2x2 x4x4x4x2x2 x_x8x2x2x2x2 x2x2x4x4x2x2 x4x2x2x4x2x2 x4x4x2x2x2x2 x2x2x2x2x4x2x2 x2x2x4x2x2x2x2 x4x2x2x2x2x2x2 x2x2x2x2x2x2x2x2 HPM-GNRDE User’s Manual 97...

  • Page 98: Intel Vmd Technology

    HPM-GNRDE User’s Manual 4.6.4.3.2.6.1 Intel VMD technology Please refer to 4.6.4.3.1.1.1 for more information. Item Option Description Disabled[Default] Intel VMD technology Intel VMD technology Enabled 4.6.4.3.2.6.2 Port A ~ Port H Please refer to 4.6.4.3.1.1.2 for more information. 98 HPM-GNRDE User’s Manual...

  • Page 99: Global Configuration

    User’s Manual 4.6.4.3.3 Global Configuration Item Options Description Enable Hot Plug Hot Plug. Disable[Default] This option can disable ASPM support for all PCIe root Disable ASPM Support (Global) Per-Port[Default] ports. 4.6.4.3.4 Intel VMD technology HPM-GNRDE User’s Manual 99...

  • Page 100: Intel Vmd For Volume Management Device On Socket 0

    Intel VMD for Volume Management Device on Socket 0 Item Option Description Disable[Default] Enable/Disable VMD Enable/Disable VMD in this Stack. Enable 4.6.4.3.4.2 Intel VMD for Volume Management Device on Socket 1 Item Option Description Disable[Default] Enable/Disable VMD Enable/Disable VMD in this Stack. Enable 100 HPM-GNRDE User’s Manual...

  • Page 101: Advanced Power Management Configuration

    SpeedStep (Pstates) Enable/Disable EIST (P-States). Enable[Default] HW_ALL[Default] EIST PSD Function Choose HW_ALL/SW_ALL in _PSD return. SW_ALL Max Performance[Default] Select the performance state that the BIOS Boot performance mode Max Efficient will set before OS hand off. HPM-GNRDE User’s Manual 101...

  • Page 102: Cpu C State Control

    Option Description Disable Monitor MWAIT Allows Monitor and MWAIT instructions. Enable[Default] Disable Allows CPU to automatically demote to C1. C1 to C1e Promotion Enable[Default] Takes effect after reboot. Disable ACPI C6x Enumeration ACPI C6x Enumeration. Auto[Default] 102 HPM-GNRDE User’s Manual...

  • Page 103: Server Mgmt

    User’s Manual 4.6.5 Server Mgmt HPM-GNRDE User’s Manual 103...
  • Page 104 Configure how the system should respond if AC Power Last Power State Power Control Policy is lost, Reset not required as selected Power policy will Power Restore Unspecified[Default] be set in BMC when policy is saved. 104 HPM-GNRDE User’s Manual...

  • Page 105: System Event Log

    Choose options for reactions to a full SEL. Delete Oldest Record Disabled Both Disable the logging of EFI Status Codes or log Log EFI Status Codes Error code[Default] only error code or only progress code or both. Progress code HPM-GNRDE User’s Manual 105...

  • Page 106: Bmc Self Test Log

    Bmc self test log Item Option Description Yes, On every reset[Default] Erase Log Erase Log Options. Clear Log[Default] When log is full Select the action to be taken when log is full. Do not log any more 106 HPM-GNRDE User’s Manual...

  • Page 107: Bmc Network Configuration

    BIOS phase. Select to configure LAN channel parameters Unspecified[Default] statically or dynamically(by BIOS or BMC). Configuration Address source Static Unspecified option will not modify any BMC DynamicBmcDhcp network parameters during BIOS phase. 4.6.5.4 BMC User Settings HPM-GNRDE User’s Manual 107...

  • Page 108: Bmc Add User Details

    HPM-GNRDE User’s Manual 4.6.5.4.1 BMC Add User Details Item Description User Name Enter BMC User Name. 4.6.5.4.2 BMC Delete User Details Item Description User Name Enter BMC User Name. 108 HPM-GNRDE User’s Manual...

  • Page 109: Bmc Change User Settings

    User’s Manual 4.6.5.4.3 BMC Change User Settings Item Description User Name Enter BMC User Name. 4.6.6 Security HPM-GNRDE User’s Manual 109...

  • Page 110: Secure Boot

    HPM-GNRDE User’s Manual ⚫ Administrator Password Set setup Administrator Password ⚫ User Password Set User Password 4.6.6.1 Secure Boot 110 HPM-GNRDE User’s Manual...
  • Page 111 The mode change requires platform reset. Secure Boot mode options: Standard or Custom. In Custom Standard[Default] Secure Boot Mode mode, Secure Boot Policy variables can be configured by a Custom physically present user without full authentication. HPM-GNRDE User’s Manual 111...

  • Page 112: Expert Key Management

    HPM-GNRDE User’s Manual 4.6.6.1.1 Expert Key Management 112 HPM-GNRDE User’s Manual...
  • Page 113 User’s Manual HPM-GNRDE User’s Manual 113...

  • Page 114: Boot

    HPM-GNRDE User’s Manual Item Option Description Install factory default Secure Boot keys after the Disabled[Default] Factory Key Provision platform reset and while the Sysstem is in Setup Enabled mode. 4.6.7 Boot 114 HPM-GNRDE User’s Manual...
  • Page 115 Set the system boot order. USB Device Network Hard Disk NVME CD/DVD[Default] Boot Option #3 Set the system boot order. USB Device Network Hard Disk NVME Boot Option #4 CD/DVD Set the system boot order. SD[Default] USB Device HPM-GNRDE User’s Manual 115...

  • Page 116: Save And Exit

    Optimized Boot will disable Csm support and Disabled[Default] disable connecting Network devices to decrease Optimized Boot Enabled boot time. While disabling Optimized Boot, make sure to restore Csm Support option to previous value before enabling Optimized Boot. 4.6.8 Save and exit 116 HPM-GNRDE User’s Manual...

  • Page 117: Save Changes And Exit

    This option saves a copy of the current BIOS settings as the User Defaults. This option is useful for preserving custom BIOS setup configurations. 4.6.8.9 Restore User Defaults This option restores all BIOS settings to the user defaults. This option is useful for restoring previously preserved custom BIOS setup configurations. HPM-GNRDE User’s Manual 117...

  • Page 118: Mechanical Drawing

    HPM-GNRDE User’s Manual 5. Mechanical Drawing 118 HPM-GNRDE User’s Manual...
  • Page 119 User’s Manual Unit: mm HPM-GNRDE User’s Manual 119...

  • Page 120: Maintenance & Troubleshooting

    System Maintenance Introduction If the components of the product fail they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts. Please follow the safety precautions outlined in the sections that follow 120 HPM-GNRDE User’s Manual...

  • Page 121: General Safety Precautions

    This equipment is not suitable for use in locations where children are likely to be present. DO NOT: ⚫ Drop the device. ⚫ In a site where the ambient temperature exceeds the rated temperature. HPM-GNRDE User’s Manual 121...

  • Page 122: Anti - Static Precautions

    This reduces the possibility of ESD damage. ⚫ Only handle the edges of the electrical component. When handling the electrical component, hold the electrical component by its edges. Please ensure the following safety precautions are adhered to at all times. 122 HPM-GNRDE User’s Manual...

  • Page 123: Maintenance And Cleaning

    Never drop any objects or liquids through the openings of the device. ⚫ Be cautious of any possible allergic reactions to solvents or chemicals used when cleaning the device. ⚫ Avoid eating, drinking and smoking within vicinity of the device. HPM-GNRDE User’s Manual 123...

  • Page 124: Basic Troubleshooting

    No Console Input Devices are found Flash update is failed Typically for development use. The beep code is generated when platform cannot be reset because reset protocol is not available. Platform PCI resource requirements cannot be met 124 HPM-GNRDE User’s Manual...

Table of Contents
