- Page 1 ECM-US15WP 3.5" Intel® Atom™ processor Z510P / Z530P Micro Module User’s Manual Ed – 13 October 2009 Part No. 2047381800R...
- Page 2 CORRECT THE INTERFERENCE AT HIS OWN EXPENSE. Copyright Notice Copyright © 2009 Avalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
- Page 3 User’s Manual Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
-
Page 4: Technical Support
Avalue Technology Inc. Room 805, Building 9,No.99 Tianzhou Rd., an Avalue Company 7 Marconi, Irvine, CA92618 Caohejing Development Area, Tel: +1-949-470-1888 Xuhui District, Shanghai Fax: +1-949-470-0971 Tel: +86-21-5169-3609 Information: BCMSales@bcmcom.com Fax:+86-21-5445-3266 Web: www.bcmcom.com Information: sales.china@avalue.com.cn Service: service@avalue.com.tw 4 ECM-US15WP User’s Manual... - Page 5 In addition, free technical support is available from Avalue’s engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. Please do not hesitate to call or e-mail ECM-US15WP User’s Manual...
-
Page 6: Table Of Contents
Keyboard & mouse connector (JKB/MS) ................... 31 2.4.20 LVDS connector (JLVDS1) ......................32 2.4.21 USB connector 5&6 (JUSB1) ....................32 2.4.22 LCD backlight brightness adjustment (JVR1) ................33 2.4.23 Power connector (PWRCON1) ....................33 2.4.24 SDIO connector (SDIO_J1) ....................... 34 6 ECM-US15WP User’s Manual... - Page 7 Small Logo (EPA) Show ......................48 3.5.3 Advanced Chipset Features......................49 3.5.3.1 System BIOS Cacheable....................... 49 3.5.3.2 Video BIOS Cacheable......................50 3.5.3.12 VGA Setting ........................... 50 3.5.4 Integrated Peripherals ........................50 3.5.4.1 OnChip IDE Device ....................... 51 ECM-US15WP User’s Manual...
- Page 8 DISPLAY TYPE HAS CHANGED SINCE LAST BOOT ..............75 EISA Configuration Checksum Error PLEASE RUN EISA CONFIGURATION UTILITY....75 EISA Configuration Is Not Complete PLEASE RUN EISA CONFIGURATION UTILITY ....75 ERROR ENCOUNTERED INITIALIZING HARD DRIVE..............75 8 ECM-US15WP User’s Manual...
- Page 9 BIOS ROM checksum error - System halted................. 78 Memory test fail..........................78 POST Codes ..........................78 40.1 Normal POST Code ........................79 40.2 Quick POST Codes........................85 40.3 S4 POST Codes ........................87 40.4 BootBlock POST Codes......................88 ECM-US15WP User’s Manual...
-
Page 10: Getting Started
Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x Intel® US15WP Micro Module 1 x Quick Installation Guide for ECM-US15WP 1 x SDVO to VGA daughter board 1 x DVD-ROM contains the followings: —... -
Page 11: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment Oct. 2009 Initial Release ECM-US15WP User’s Manual 11... -
Page 12: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with ECM-US15WP series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 13: System Specifications
With 9-pin 2 mm box header (can be selected to support 4/5/8-wire touch Touch Screen Interface screen) Audio Realtek ALC883 supports 5.1 CH Audio AC97 Codec Mic in, Line in, CD Audio in, Line out Audio Interface ECM-US15WP User’s Manual 13... - Page 14 Single Power AT / ATX Power Type 0~60°C (32~140°F) Operation Temperature 0%~90% relative humidity, non-condensing Operating Humidity 5.7" x 4.2" (146 mm x 101 mm) Size ( L x W ) 0.44 lbs (0.2 Kg) Weight 14 ECM-US15WP User’s Manual...
-
Page 15: Architecture Overview - Block Diagram
User’s Manual 1.6 Architecture Overview – Block Diagram The following block diagram shows the architecture and main components of ECM-US15WP. ECM-US15WP User’s Manual 15... -
Page 16: Hardware Configuration
ECM-US15WP 2. Hardware Configuration 16 ECM-US15WP User’s Manual... -
Page 17: Product Overview
User’s Manual 2.1 Product Overview ECM-US15WP User’s Manual 17... -
Page 18: Installation Procedure
Window must be entered and configured correctly to match the particular system configuration. 7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before connecting the display cable and turning on the power. 18 ECM-US15WP User’s Manual... -
Page 19: Jumper And Connector List
3 x 1 header, pitch 2.0mm PWR_SEL1 Serial port 1 – Ring, +5V, +12V power 3 x 1 header, pitch 2.0mm select Serial port 2 – Ring, +5V, +12V power 3 x 1 header, pitch 2.0mm select ECM-US15WP User’s Manual 19... - Page 20 SATA 1 connector SATA1 SATA 2 connector SATA2 SDIO connector 5 x 1 header, pitch 2.54mm SDIO_J1 SDIO connector 6 x 1 header, pitch 2.54mm SDIO_J2 USB connector 2&3 Double deck USB1 USB connector 0&1 Double deck USB2 20 ECM-US15WP User’s Manual...
-
Page 21: Setting Jumpers & Connectors
User’s Manual 2.4 Setting Jumpers & Connectors 2.4.1 Clear CMOS (JABT1) Protect* Clear CMOS * Default 2.4.2 CF Card mode select (JCF1) Master * Slave * Default ECM-US15WP User’s Manual 21... -
Page 22: Touch Panel Mode Select (Jtouch1)
ECM-US15WP 2.4.3 Touch Panel mode select (JTOUCH1) 4/8-Wire* 5-Wire * Default 2.4.4 AT/ATX power mode select (PWR_SEL1) AT * * Default 22 ECM-US15WP User’s Manual... -
Page 23: Serial Port 1 - Ring, +5V, +12V Power Select (Ri1)
User’s Manual 2.4.5 Serial port 1 – Ring, +5V, +12V power select (RI1) Ring* +12V * Default 2.4.6 Serial port 2 – Ring, +5V, +12V power select (RI2) Ring* +12V * Default ECM-US15WP User’s Manual 23... -
Page 24: Atx Power Connector (Atxpw1)
ECM-US15WP 2.4.7 ATX power connector (ATXPW1) Signal PSON- PS5VSB 2.4.8 Battery connector (BBAT1) Signal 24 ECM-US15WP User’s Manual... -
Page 25: Serial Port 1 Connector (Com1)
User’s Manual 2.4.9 Serial Port 1 connector (COM1) Signal PIN PIN Signal 2.4.10 Serial Port 2 connector (COM2) Signal PIN PIN Signal ECM-US15WP User’s Manual 25... -
Page 26: Digital Input/ Output Connector (Dio1)
ECM-US15WP 2.4.11 Digital Input/ Output connector (DIO1) Signal PIN PIN Signal GPI0 GPO0 GPI1 GPO1 GPI2 GPO2 GPI3 GPO3 GPI4 GPO4 GPI5 GPO5 GPI6 GPO6 GPO7 SMB_CLK SMB_DATA 26 ECM-US15WP User’s Manual... -
Page 27: Primary Ide Connector (Ide1)
Primary IDE connector (IDE1) Signal PIN PIN Signal RESET# PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15 PDREQ PDIOW# PDIOR# PIORDY PDACK# IRQ15 PDA1 PDA0 PDA2 PDCS1# PDCS3# HD_LED1 ECM-US15WP User’s Manual 27... -
Page 28: Irda Connector (Ir1)
ECM-US15WP 2.4.13 IrDA connector (IR1) Signal IRRX IRTX 2.4.14 Audio connector (JAUDIO1) Signal PIN PIN Signal SPDIFI SPDIFO LINEIN_DETECT LINEIN_R LINEIN_L 28 ECM-US15WP User’s Manual... -
Page 29: Lcd Inverter Power Connector (J1)
User’s Manual 2.4.15 LCD inverter power connector (J1) Signal +12V 2.4.16 Serial port 2 in RS-422/485 mode (J422/485) Signal PIN PIN Signal Note: J422/485 is available after modifying the mode of COM2 in BIOS setting. ECM-US15WP User’s Manual 29... -
Page 30: Lcd Inverter Connector (Jbkl1)
VR signal controlled by JVR1. Please see the JVR1 section for detailed circuitry information. 2.4.17.1 Signal Description – LCD Inverter Connector (JBKL1) Signal Signal Description Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) BLK_ON LCD backlight ON/OFF control signal 30 ECM-US15WP User’s Manual... -
Page 31: Cd-Rom Audio Input Connector (Jcd1)
User’s Manual 2.4.18 CD-ROM audio input Connector (JCD1) Signal CD_R CD_L 2.4.19 Keyboard & mouse connector (JKB/MS) Signal Signal MSCK MSDT KBCK KBDT ECM-US15WP User’s Manual 31... -
Page 32: Lvds Connector (Jlvds1)
LVDS connector (JLVDS1) Signal PIN PIN Signal LCDS_0- LCDS_0+ LCDS_1- LCDS_1+ LCDS_2- LCDS_2+ LCDS_3- LCDS_3+ LCDS_CLK- 12 11 LCDS_CLK+ I_SCL I_SDA +3.3V +3.3V Note: Mating Connector: HIROSE DF13-20DS-1.25C 2.4.21 USB connector 5&6 (JUSB1) Signal PIN PIN Signal 32 ECM-US15WP User’s Manual... -
Page 33: Lcd Backlight Brightness Adjustment (Jvr1)
User’s Manual 2.4.22 LCD backlight brightness adjustment (JVR1) Signal 2.4.23 Power connector (PWRCON1) Signal PIN PIN Signal ECM-US15WP User’s Manual 33... -
Page 34: Sdio Connector (Sdio_J1)
ECM-US15WP 2.4.24 SDIO connector (SDIO_J1) Signal +3.3V DATA1 DATA0 2.4.25 SDIO connector (SDIO_J2) Signal DATA3 DATA2 34 ECM-US15WP User’s Manual... -
Page 35: Touch Panel Connector (Touch1)
BOTTOM EXCITE TOP EXCITE 2.4.27 SDVO port connector (JSDVO1) Signal PIN PIN Signal +12V SDVO_CLK SDVO_CLK# +3.3V SDVO_BLUE DVO_SEL1 SDVO_BLUE# DVO_SEL2 SDVO_GREEN SDVO_GREEN# SDVO_RED SDVO_REST SDVO_RED# SDVO_INIT SDVO_TVCLKIN SDVO_INIT# 20 SDVO_TVCLKIN# SDVO_STALL SDVO_CTRCLK SDVO_STALL# 23 24 SDVO_CTRDATA ECM-US15WP User’s Manual 35... -
Page 36: Sdvo To Dvi/ Lvds/ Crt
YA3P TLCN TDC2N YA2M YA3M TLCP TDC2P YA4P YA5P SDVO to CRT (V_VGA1) YA4M YA5M YA6P YA7P YA6M YA7M CLK1P CLK2P CLK1M CLK2M Signal PIN PIN Signal +12V +12V HS_VGA VS_VGA SDT_DDC SCK_DDC CRT_B_VGA CRT_G_VGA CRT_R_VGA 36 ECM-US15WP User’s Manual... -
Page 37: Bios Setup
User’s Manual 3. BIOS Setup ECM-US15WP User’s Manual 37... -
Page 38: Starting Setup
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 38 ECM-US15WP User’s Manual... -
Page 39: Using Setup
Save all the CMOS changes, only for Main Menu • Navigating Through The Menu Bar Use the left and right arrow keys to choose the menu you want to be in. Note: Some of the navigation keys differ from one screen to another. ECM-US15WP User’s Manual 39... -
Page 40: Getting Help
Award and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 40 ECM-US15WP User’s Manual... -
Page 41: Main Menu
Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. ECM-US15WP User’s Manual 41... -
Page 42: Standard Cmos Features
CGA 40 Video Select the default video device CGA 80 MONO All Errors Select the situation in which you want the BIOS Halt On No Errors to stop the POST process and notify you All, but Keyboard 42 ECM-US15WP User’s Manual... -
Page 43: Ide Adapter Setup
**** Warning: Setting a value of 65535 Precomp Max = 65535 means no hard disk Min = 0 Landing zone **** Max = 65535 Min = 0 Sector Number of sectors per track Max = 255 ECM-US15WP User’s Manual 43... -
Page 44: Advanced Bios Features
Disable MaxVal" feature. Enabling this feature Limit CPUID MaxVal Enable will make the main board BIOS respond "suitable", "virtual" CPUID to OS kernel. So WinNT or the legacy OS can use the masked CPUID to work 44 ECM-US15WP User’s Manual... -
Page 45: Hard Disk Boot Priority
Allows you to choose the VIRUS Warning feature for IDE Hard Disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and alarm beep. ECM-US15WP User’s Manual 45... -
Page 46: Cpu L1 & L2 & L3 Cache
Disabled any boot device 3.5.2.8 Boot Up NumLock Status Select power on state for NumLock. Item Description Enable NumLock Disable NumLock 3.5.2.9 Gate A20 Option Select if chipset or keyboard controller should control Gate A20. Item Description 46 ECM-US15WP User’s Manual... -
Page 47: Typematic Rate Setting
Setup freely. 3.5.2.14 APIC Mode The BIOS supports versions 1.4 of the Intel multiprocessor specification. When enabled, The MPS Version 1.4 Control for OS can be activated. The choice: Enabled/Disabled. ECM-US15WP User’s Manual 47... -
Page 48: Mps Version Control For Os
Generate error message 3.5.2.18 Small Logo (EPA) Show This item allows you enabled/disabled the small EPA logo show on screen at the POST step. Item Description Enabled EPA Logo show is enabled Disabled EPA Logo show is disabled 48 ECM-US15WP User’s Manual... -
Page 49: Advanced Chipset Features
BIOS ROM at F0000h-FFFFFh via the L2 cache. This greatly speeds up accesses to the system BIOS. However, this does not translate into better system performance because the OS does not need to access the system BIOS much. The choices: Disabled, Enabled. ECM-US15WP User’s Manual 49... -
Page 50: Video Bios Cacheable
This feature allows you to control LVDS back 37.5%, 50%, 62.5%, LVDS Back Light Control light. 75.0%,87.5%,100% VBIOS Default, This feature allows you to control BIA. BIA Control Level1~6 3.5.4 Integrated Peripherals Use this menu to specify your settings for integrated peripherals. 50 ECM-US15WP User’s Manual... -
Page 51: Onchip Ide Device
User’s Manual 3.5.4.1 OnChip IDE Device The chipset contains a PCI IDE interface with support for one IDE channel and two SATA channels. Select Enabled to activate the primary IDE interface. Select Disabled to deactivate this interface. ECM-US15WP User’s Manual 51... -
Page 52: Onboard Device
3.5.4.1 Onboard Device Item Options Description Auto, This item allows you to select the Intel HD Intel HD Audio Controller Disabled Audio Controller. Enabled This item allows you to enabled the SDIO/MMC SDIO/MMC Controller Disabled Controller. 52 ECM-US15WP User’s Manual... -
Page 53: Watch Dog Timer
USB keyboard should be provided by the Enabled operating system or the BIOS. This BIOS feature determines if support for the Disabled USB Storage Function USB Storage should be provided by the Enabled operating system or the BIOS. ECM-US15WP User’s Manual 53... -
Page 54: Power Management Setup
The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. 3.5.5.1 PCI Express PM Function This item allows you to enable/disable the PCI Express PME Function. The choices: Enabled, Disabled. 54 ECM-US15WP User’s Manual... -
Page 55: Acpi Function
Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off state when the system has “hung”.(Only could working on ATX Power supply) The choices: Delay 4 Sec, Instant-Off. 3.5.5.5 HEPT Feature The choices: Enabled, Disabled. ECM-US15WP User’s Manual 55... -
Page 56: Pnp / Pci Configuration
Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings. 56 ECM-US15WP User’s Manual... -
Page 57: Reset Configuration Data
The choices: Auto(ESCD), Manual. 3.5.6.3 PCI / VGA Palette Snoop Leave this field at Disabled. The choices: Enabled, Disabled. 3.5.6.4 Maximum Payload Size This setting defines the maximum payload size. The choices: 128, 256, 512, 1024, 2048, 4096. ECM-US15WP User’s Manual 57... -
Page 58: Pc Health Status
Load Fail-Safe Defaults Use this menu to load the BIOS default values for the minimal/stable performance for your system to operate. Press <Y> to load the BIOS default values for the most stable, minimal-performance system operations. 58 ECM-US15WP User’s Manual... -
Page 59: Load Optimized Defaults
While Award has designed the custom BIOS to maximize performance, the factory has the right to change these defaults to meet their needs. Press <Y> to load the default values setting for optimal performance system operations. ECM-US15WP User’s Manual 59... -
Page 60: Set Supervisor / User Password
You can set either supervisor or user password, or both of them. Supervisor Password: able to enter/change the options of setup menus. User Password: able to enter but no right to change the options of setup menus. 60 ECM-US15WP User’s Manual... - Page 61 Features Setup Menu and its Security option (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup. ECM-US15WP User’s Manual 61...
-
Page 62: Save & Exit Setup
Enter <Y> to store the selection made in the menus in CMOS, a special section in memory that stays on after turning the system off. The BIOS configures the system according to the Setup selection stored in CMOS when boot the computer next time. The system is restarted after saving the values. 62 ECM-US15WP User’s Manual... -
Page 63: Exit Without Save
User’s Manual 3.5.13 Exit Without Save Abandon all CMOS value changes and exit setup, and the system is restarted after exiting. ECM-US15WP User’s Manual 63... -
Page 64: Drivers Installation
ECM-US15WP 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 64 ECM-US15WP User’s Manual... -
Page 65: Install Chipset Driver (For Intel Us15Wp)
Windows XP operation system. If the warning message appears while the installation Step 3. Click Next. process, click Continue to go on. Step1. Locate 「\Driver_Chipset\Intel\ US15WP\ \infinst_autol.exe」. Step 4. Click Finish to complete setup. Step 2. Click Next. ECM-US15WP User’s Manual 65... -
Page 66: Install Display Driver (For Intel 945Gse)
Note: The installation procedures and screen shots in this section are based on Windows XP operation system. Step 3. Click Next. Step 1. Locate「Driver_Video\Intel\ Step 4. Click Yes. 945GSE\winxp_14324(Graphics).exe」. Step 2. Click Next. Step 5. Click Finish to complete setup. 66 ECM-US15WP User’s Manual... -
Page 67: Install Ethernet Driver (For Intel® 82574L Gigabit Lan)
Step 1. Click Start of the task bar, then the Step 4. Click Update Driver. System of Performance and Maintenance in Control Panel. Step 2. Click Device Manager of Step 5. Select the Advanced item and click Hardware. Next. ECM-US15WP User’s Manual 67... - Page 68 Step 6. Select the specific location to Step 9. Repeat the Step 1 ~ Step 3 to confirm the Generic Marvell is ready. Next. Step 7. The wizard runs the setup automatically. Step 8. Click Finish to complete the installation. 68 ECM-US15WP User’s Manual...
-
Page 69: Install Audio Driver (For Realtek Alc883)
Step 3. Select Yes to the next step. based on Windows 2000 operation system. Step 1. Locate 「\Driver_Audio\Intel\ Step 4. Click Finish to complete the setup. 6300ESB ALC655\setup.exe」. Step 2. The program executes the Setup automatically. ECM-US15WP User’s Manual 69... -
Page 70: Mechanical Drawing
ECM-US15WP 5. Mechanical Drawing 70 ECM-US15WP User’s Manual... - Page 71 User’s Manual Unit: mm ECM-US15WP User’s Manual 71...
- Page 72 ECM-US15WP Unit: mm Unit: mm 72 ECM-US15WP User’s Manual...
-
Page 73: Appendix A: Award Bios Post Messages
User’s Manual Appendix A: AWARD BIOS POST Messages ECM-US15WP User’s Manual 73... -
Page 74: Overview
Then reboot the system. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP Type of diskette drive installed in the system is different from the CMOS definition. Run Setup to reconfigure the drive type correctly. 74 ECM-US15WP User’s Manual... -
Page 75: Display Switch Is Set Incorrectly
Cannot find or initialize the floppy drive controller. Make sure the controller is installed correctly and firmly. If there are no floppy drives installed, be sure the Diskette Drive selection in Setup is set to NONE. ECM-US15WP User’s Manual 75... -
Page 76: Invalid Eisa Configuration Please Run Eisa Configuration Utility
ERROR messages when the segment that has caused the problem has been isolated. 20. PRESS A KEY TO REBOOT This will be displayed at the bottom screen when an error occurs that requires you to reboot. Press any key and the system will reboot. 76 ECM-US15WP User’s Manual... -
Page 77: Press F1 To Disable Nmi, F2 To Reboot
The board ID does not match the ID stored in the EISA non-volatile memory. Note: When either of these errors appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility. ECM-US15WP User’s Manual 77... -
Page 78: Floppy Disk(S) Fail (80) → Unable To Reset Floppy Subsystem
The checksum of ROM address F0000H-FFFFFH is bad. 39. Memory test fail. BIOS reports the memory test fail if the onboard memory is tested error. 40. POST Codes Please take reference to Phoenix-Award website for the latest post codes. http://www.phoenix.com/en/OEM-ODM/Customer+Services/BIOS/AwardBIOS/Award+Erro r+Codes.htm 78 ECM-US15WP User’s Manual... -
Page 79: Normal Post Code
If unmasked NMI occurs, display Press F1 to disable NMI, F2 reboot. Program Chip Set To program chipset from defaults values E1-EF Setup Pages E1- Page 1, E2 - Page 2, etc. Force load Default to Chipset defaults program chipset Reserved ECM-US15WP User’s Manual 79... - Page 80 Re-init KB Reserved HPM init If support HPM, HPM get initialized here Reserved Test CMOS Interface Verifies CMOS is working correctly, detects bad battery. If failed, and battery Status load CMOS defaults and load into chipset Reserved 80 ECM-US15WP User’s Manual...
- Page 81 Verify 8259 Channel 1 masked interrupts by alternately turning off and on the interrupt lines. Reserved Test 8259-2 Mask Bits Verify 8259 Channel 2 masked interrupts by alternately turning off and on the interrupt lines. Reserved Reserved ECM-US15WP User’s Manual 81...
- Page 82 PnP Init Display PnP logo and PnP early init Reserved Setup Virus Protect Setup virus protect according to Setup Reserved Awdflash Load If required, will auto load Awdflash.exe in POST Reserved Onboard I/O Init Initializing onboard superIO 82 ECM-US15WP User’s Manual...
- Page 83 IDE device detection and install Reserved Detect & Initialize Initialize any serial and parallel ports (also game port). Serial/Parallel Port Reserved Reserved Detect & Initialize Math Initialize math coprocessor. Coprocessor Reserved HDD Check for Write HDD check out protection ECM-US15WP User’s Manual 83...
- Page 84 Read and store boot partition head and cylinders values in RAM Final Init Final init for last micro details before boot Special KBC patch Set system speed for boot. Setup NumLock status according to Setup Boot Attempt Set low stack Boot via INT 19h. Boot 84 ECM-US15WP User’s Manual...
-
Page 85: Quick Post Codes
Reserved Reserved Setup Init Display setup message and enable setup functions Detect if mouse is present, initialize mouse, install interrupt vectors. Special treatment to PS2 Mouse port ACPI sub-system initializing Setup Cache Controller Initialize cache controller. ECM-US15WP User’s Manual 85... - Page 86 Read and store boot partition head and cylinders values in RAM Final Init Final init for last micro details before boot Special KBC patch Set system speed for boot. Setup NumLock status according to Setup. Boot Attempt Set low stack Boot via INT 19h. Boot 86 ECM-US15WP User’s Manual...
-
Page 87: S4 Post Codes
BIOS data area Parameters Initialize hard drive controller and any drives. IDE device detection and install Cache Init Cache init and USB init PM init PM initialization PM final Init and issue Final init Before resume Full on ECM-US15WP User’s Manual 87... -
Page 88: Bootblock Post Codes
KB init Initialized KBC Install interrupt vectors Install int. vector (0-77), and initialized 00-1fh to their proper place Init Video Video initializing Init FDD Scan floppy and media capacity for onboard superIO Boot Load boot sector 88 ECM-US15WP User’s Manual...
