ECM-5510
5.25" AMD Geode GX466 333 MHz Mini Module with 128 MB
DDR SDRAM Onboard, VGA, LVDS, Audio, LAN, CF,
PC/104, PCI, 4 COM, 4 USB 1.1 & GPIO
User's Manual
nd
2
Ed – 19 January 2007
Part No. E2047551001R

Advertisement

Table of Contents
loading

Related Manuals for Avalue Technology AMD Geode E2047551001R

Summary of Contents for Avalue Technology AMD Geode E2047551001R

  • Page 1 ECM-5510 5.25" AMD Geode GX466 333 MHz Mini Module with 128 MB DDR SDRAM Onboard, VGA, LVDS, Audio, LAN, CF, PC/104, PCI, 4 COM, 4 USB 1.1 & GPIO User’s Manual Ed – 19 January 2007 Part No. E2047551001R...
  • Page 2 ECM-5510 FCC Statement THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS "A"...
  • Page 3 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the use of the described product(s), conveys no license or title under any patent, copyright, or masks work rights to these products, and makes no representations or warranties that these products are free from patent, copyright, or mask work right infringement, unless...
  • Page 4 ECM-5510 Technical Support We want you to get the maximum performance from your products. So if you run into technical difficulties, we are here to help. For the most frequently asked questions, you can easily find answers in your product documentation. These answers are normally a lot more detailed than the ones we can give over the phone.
  • Page 5 Product Warranty Avalue warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Avalue, or which have been subject to misuse, abuse, accident or improper installation.

  • Page 6: Table Of Contents

    ECM-5510 Contents Getting Started...10 Safety Precautions ...10 Packing List...10 Document Amendment History ...11 Manual Objectives...12 System Specifications ...13 Architecture Overview ...15 1.6.1 Block Diagram ... 15 1.6.2 AMD Geode GX2 & CS5535... 16 1.6.3 VIA VT1612A Audio Codec... 18 1.6.4 Ethernet...
  • Page 7 2.4.16 Serial Port 2 Connector in RS-232 Mode (CN6, 2.4.17 Serial Port 2 Connector in RS-422 Mode (CN6, 2.4.18 Serial Port 2 Connector in RS-485 Mode (CN6, 2.4.19 PC/104 Connector (CN7 + CN8) ... 43 2.4.20 IrDA Connector (CN10)... 49 2.4.21 Keyboard &...
  • Page 8 ECM-5510 Drivers Installation ...87 Install Audio Driver (For AMD GX2) ...88 Install Display Driver (For AMD GX2)...90 Install Ethernet Driver (For Realtek RTL810x, RTL813x Family) ...92 Measurement Drawing ...93 Appendix A: BIOS Revisions ...95 Appendix B: AWARD BIOS POST Messages ...96 Overview...97 Post Beep ...97 Error Messages ...97...
  • Page 9 Hard Disk(s) fail (80) → HDD reset failed... 101 Hard Disk(s) fail (40) → HDD controller diagnostics failed... 101 Hard Disk(s) fail (20) → HDD initialization error... 101 Hard Disk(s) fail (10) → Unable to recalibrate fixed disk... 101 Hard Disk(s) fail (08) → Sector Verify failed... 101 Keyboard is locked out - Unlock the key.

  • Page 10: Getting Started

    ECM-5510 1. Getting Started 1.1 Safety Precautions Warning! Caution! 1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x ECM-5510 onboard AMD Geode GX466 333 MHz mini module 1 x Quick Installation Guide for ECM-5510 1 x CD-ROM or DVD-ROM contains the followings: —...

  • Page 11: Document Amendment History

    User’s Manual 1.3 Document Amendment History Revision Date Comment May, 2006 Vicky Lin Initial Release ECM-5510 User’s Manual 11...

  • Page 12: Manual Objectives

    ECM-5510 1.4 Manual Objectives This manual describes in detail the Avalue Technology ECM-5510 Single Board. We have tried to include as much information as possible but we have not duplicated information that is provided in the standard IBM Technical References, unless it proved to be necessary to aid in the understanding of this board.

  • Page 13: System Specifications

    1.5 System Specifications System BIOS System Chipset I/O Chip System Memory Watchdog Timer Expansion IrDA Display Chipset Display Memory Resolution VGA/LCD Interface LVDS Audio Chipset AC97 Codec Audio Interface Ethernet LAN 1 Ethernet Interface Onboard AMD Geode GX466 333 MHz Note: Available in different CPU speeds by request Award 512 KB Flash BIOS AMD Geode GX466/CS5535...
  • Page 14 ECM-5510 Mechanical & Environmental Power Requirement Power Type Operation Temperature Operating Humidity Size ( L x W ) Weight 14 ECM-5510 User’s Manual +5V @ 1.71 A, 5 Vsb @ 0.17 A (with AMD Geode GX466 333 MHz & 256 MB DDR SDRAM) AT/ATX 0~60...

  • Page 15: Architecture Overview

    User’s Manual 1.6 Architecture Overview 1.6.1 Block Diagram The following block diagram shows the architecture and main components of ECM-5510. The following sections provide detail information about the functions provided onboard. ECM-5510 User’s Manual 15...

  • Page 16: Amd Geode Gx2 & Cs5535

    ECM-5510 1.6.2 AMD Geode GX2 & CS5535 The AMD Geode ™ GX2 processor is designed from the ground-up for information appliances, the GX2 processor delivers optimal performance for full-featured multimedia applications across broadband connections. The GX2 processor includes a powerful 32-bit-x86 core integrated FPU, a display controller with up to 1600 x 1200 resolution, a graphic processor, a SDRAM controller (SDR or DDR supported), a TFT interface and integrated DACs for CRT support (pinout options).
  • Page 17 Shared with serial port 1 • 16550A and 16450 software compatible • Consumer-IR (TV-remote) mode • HP-SIR • Selectable internal or external modulation/demodulation (SHARP-IR) • Consumer remote control supports RC-5, RC-6, NEC, RCA, • RECS 80 AMD Geode™ Solutions CS5535 companion device –...

  • Page 18: Via Vt1612A Audio Codec

    ECM-5510 1.6.3 VIA VT1612A Audio Codec VIA Technologies’ VT1612ATM 18-bit audio codec conforms to the AC’97 2.2. The VT1612A integrates Sample Rate Converters and can be adjusted in 1Hz increments. The analog mixer circuitry integrates a stereo enhancement to provide a pleasing 3D surround sound effect for stereo media.

  • Page 19: Winbond W83627Hf-Aw Lpc Super I/O

    1.6.5 Winbond W83627HF-AW LPC Super I/O The Winbond W83627F/HF is made to fully comply with Microsoft PC98 and PC99 Hardware Design Guide. Moreover, W83627F/HF is made to meet the specification of PC98/PC99’s requirement in the power management: ACPI and DPM (Device Power Management).

  • Page 20: Ns Ds90C385 Lvds Transmitter

    ECM-5510 1.6.7 NS DS90C385 LVDS Transmitter The DS90C385 transmitter converts 28 bits of LVCMOS/LVTTL data into four LVDS (Low Voltage Differential Signaling) data streams. A phase-locked transmit clock is transmitted in parallel with the data streams over a fifth LVDS link. Every cycle of the transmit clock 28 bits of input data are sampled and transmitted.

  • Page 21: Hardware Configuration

    User’s Manual 2. Hardware Configuration ECM-5510 User’s Manual 21...

  • Page 22: Product Overview

    ECM-5510 2.1 Product Overview 22 ECM-5510 User’s Manual...

  • Page 23: Installation Procedure

    2.2 Installation Procedure This chapter explains you the instructions of how to setup your system. 1. Turn off the power supply. 2. Insert the DIMM module (be careful with the orientation). 3. Insert all external cables for hard disk, floppy, keyboard, mouse, USB etc. except for flat panel.

  • Page 24: Main Memory

    ECM-5510 2.2.1 Main Memory ECM-5510 provides one 184-pin SODIMM sockets to support DDR SDRAM. The total maximum memory size is 512 MB. Make sure to unplug the power supply before adding or removing DIMMs or other system components. Failure to do so may cause severe damage to both the board and the components.
  • Page 25 • Locate the DIMM slot on the board. • Hold two edges of the DIMM module carefully. Keep away of touching its connectors. • Align the notch key on the module with the rib on the slot. • Firmly press the modules into the slot automatically snaps into the mounting notch. Do not force the DIMM module in with extra force as the DIMM module only fit in one direction.

  • Page 26: Jumper And Connector List

    ECM-5510 2.3 Jumper and Connector List You can configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.
  • Page 27 Connectors Label Function ATX power connector ATX1 System fan connector CPU fan connector TFT panel connector LVDS connector CD-ROM audio input connector Serial port 1, 2, 3, 4 connector PC/104 connector CN7 + CN8 Reserved IrDA connector CN10 Keyboard & mouse connector CN11 USB connector 0 &...

  • Page 28: Setting Jumpers & Connectors

    ECM-5510 2.4 Setting Jumpers & Connectors 2.4.1 BIOS Write Protect Select (JP1) * Default 2.4.2 TFT/CRT Select (JP2) * Default 28 ECM-5510 User’s Manual Protect* Write CRT*...

  • Page 29: Clear Cmos (Jp3)

    2.4.3 Clear CMOS (JP3) * Default 2.4.4 COM2 RS-232/422/485 Select (JP5, JP6) * Default (JP5) RS-232* RS-422 RS-485 User’s Manual Protect* Clear CMOS (JP6) RS-232* RS-422 RS-485 ECM-5510 User’s Manual 29...

  • Page 30: Com2/4/3/1 Pin 9 Select (Jp7, Jp8, Jp9, Jp10)

    ECM-5510 2.4.5 COM2/4/3/1 Pin 9 Select (JP7, JP8, JP9, JP10) * Default 2.4.6 LCD Inverter Power Select (JP11) * Default 30 ECM-5510 User’s Manual +12V Ring* +12V*...

  • Page 31: Compact Flash Mode Select (Jp13)

    2.4.7 Compact Flash Mode Select (JP13) * Default 2.4.8 DOC Memory Address Select (JP14) * Default User’s Manual Master Slave* D0000 D4000* D8000 Disabled ECM-5510 User’s Manual 31...

  • Page 32: Atx Power Connector (Atx1)

    ECM-5510 2.4.9 ATX Power Connector (ATX1) 32 ECM-5510 User’s Manual Signal Signal PS_ON PWROK +3.3V +3.3V 5VSB +12V...

  • Page 33: System Fan Connector (Cn1)

    2.4.10 System Fan Connector (CN1) 2.4.10.1 Signal Description – System Fan Connector (CN1) Signal Fan speed monitor 2.4.11 CPU Fan Connector (CN2) 2.4.11.1 Signal Description – CPU Fan Connector (CN2) Signal Fan speed monitor Signal +12V Signal Description Signal +12V Signal Description ECM-5510 User’s Manual 33 User’s Manual...

  • Page 34: Tft Panel Connector (Cn3)

    ECM-5510 2.4.12 TFT Panel Connector (CN3) 2.4.12.1 Signal Description – TFT Panel Connecter (CN3) Signal P [0:23] Flat panel data output for 18/24 bit TFT flat panels. Refer to table below for configurations for various panel types. The flat panel data and control outputs are all on-board controlled for secure power-on/off sequencing SHFCLK Shift Clock.
  • Page 35 2.4.12.2 Signal Configuration – TFT Panel Display (CN3) Signal 18-bit TFT User’s Manual 24-bit TFT ECM-5510 User’s Manual 35...

  • Page 36: Lvds Connector (Cn4)

    ECM-5510 2.4.13 LVDS Connector (CN4) 2.4.13.1 Signal Description – LVDS Connecter (CN4) Signal C interface for panel parameter EEPROM. This EERPOM is mounted on the C_DAT, I C_CLK LVDS receiver. The data in the EEPROM allows the EXT module to automatically set the proper timing parameters for a specific LCD panel.

  • Page 37: Cd-Rom Audio Input Connector (Cn5)

    2.4.14 CD-ROM Audio Input Connector (CN5) 2.4.14.1 Signal Description – CD-ROM Audio Input Connecter (CN5) Signal CD_R Right CD-IN signal CD_L Left CD-IN signal Signal CD_R CD_L Signal Description ECM-5510 User’s Manual 37 User’s Manual...

  • Page 38: Serial Port 1, 3, 4 Connector (Cn6)

    ECM-5510 2.4.15 Serial Port 1, 3, 4 Connector (CN6) 38 ECM-5510 User’s Manual Serial Port 1 (Pin 1-10) Signal Signal DCD1 DSR1 RxD1 RTS1 TxD1 CTS1 DTR1 RI1/+5V/+12V Serial Port 3 (Pin 21-30) Signal Signal DCD3 DSR3 RxD3 RTS3 TxD3 CTS3 DTR3 RI3/+5V/+12V...
  • Page 39 2.4.15.1 Signal Description – Serial Port 1, 3, 4 Connector (CN6) Signal Serial output. This signal sends serial data to the communication link. The signal is set to a marking state on hardware reset when the transmitter is empty or when loop mode operation is initiated.

  • Page 40: Serial Port 2 Connector In Rs-232 Mode (Cn6, Pin 11-20)

    ECM-5510 2.4.16 Serial Port 2 Connector in RS-232 Mode (CN6, 2.4.16.1 Signal Description – Serial Port 2 Connector in RS-232 Mode (CN6, 11-20) Signal Serial output. This signal sends serial data to the communication link. The signal is set to a marking state on hardware reset when the transmitter is empty or when loop mode operation is initiated.

  • Page 41: Serial Port 2 Connector In Rs-422 Mode (Cn6, Pin 11-20)

    2.4.17 Serial Port 2 Connector in RS-422 Mode (CN6, 2.4.17.1 Signal Description – Serial Port 2 Connector in RS-422 Mode (CN6, 11-20) Signal Serial output. This differential signal pair sends serial data to the communication TxD+/- link. Data is transferred from Serial Port 2 Transmit Buffer Register to the communication link, if the RTS register of the Serial Port 2 is set to LOW.

  • Page 42: Serial Port 2 Connector In Rs-485 Mode (Cn6, Pin 11-20)

    ECM-5510 2.4.18 Serial Port 2 Connector in RS-485 Mode (CN6, 2.4.18.1 Signal Description – Serial Port 2 Connector in RS-485 Mode (CN6, 11-20) Signal This differential signal pair sends and receives serial data to the communication link. DATA+/- register of Serial Port 2. Set the RTS register of the Serial Port 2 to LOW for transmitting, HIGH for receiving.

  • Page 43: Pc/104 Connector (Cn7 + Cn8)

    2.4.19 PC/104 Connector (CN7 + CN8) Signal BALE DACK2# IRQ3 IRQ4 IRQ5 IRQ6 IRQ7 SYS_CLK REFRESH# DRQ1 DACK1# DRQ3 DACK3# IOR# IOW# SMEMR# SMEMW# IOCHRDY +12V OWS# -12V DRQ2 IRQ9 RESETDRV IOCHK# ECM-5510 User’s Manual 43 User’s Manual Signal SA10 SA11 SA12 SA13...
  • Page 44 ECM-5510 44 ECM-5510 User’s Manual Signal Signal SD15 SD14 MASTER# SD13 SD12 DRQ7 SD11 DACK7# SD10 DRQ6 DACK6# DRQ5 MEMW# DACK5# MEMR# DRQ0 SA17 DACK0# SA18 IRQ14 SA19 IRQ15 LA20 IRQ12 LA21 IRQ11 LA22 IRQ10 LA23 IOCS16# SBHE# MEMCS16#...
  • Page 45 2.4.19.1 Signal Description – PC/104 Connector (CN7 + CN8) 2.4.19.1.1 Address Signal The address signals LA [23:17] define the selection of a 128KB section of memory space within the 16MB address range of the 16-bit data bus. These signals are active high.
  • Page 46 ECM-5510 2.4.19.1.3 Commands Signal This is an active high signal used to latch valid addresses from the current bus master on the falling edge of BALE. During DMA, refresh and alternate master BALE cycles, BALE is forced high for the duration of the transfer. BALE is driven by the permanent master with a totem-pole driver.
  • Page 47 2.4.19.1.4 Transfer Response Signal This is an active low signal driven by an I/O-mapped PC-AT/PC104 adapter indicating that the I/O device located at the address is a 16-bit device. This open IOCS16# collector signal is driven, based on SA [15:0] only (not IOR# and IOW#) when AEN is not asserted.
  • Page 48 ECM-5510 2.4.19.1.6 Interrupts Signal These signals are active high signals, which indicate the presence of an IRQ[3:7], IRQ[9:12] interrupting PC-AT/PC104 bus adapter. Due to the use of pull-ups, unused IRQ[14:15] interrupt inputs must be masked. 2.4.19.1.7 Bus Arbitration Signal These signals are active high signals driven by a DMA bus adapter to indicate a request for a DMA bus operation.

  • Page 49: Irda Connector (Cn10)

    2.4.20 IrDA Connector (CN10) 2.4.20.1 Signal Description – IrDA Connecter (CN10) Signal IRRX Infrared Receiver input IRTX Infrared Transmitter output Signal IRRX IRTX Signal Description ECM-5510 User’s Manual 49 User’s Manual...

  • Page 50: Keyboard & Mouse Connector (Cn11)

    ECM-5510 2.4.21 Keyboard & Mouse Connector (CN11) 2.4.21.1 Signal Description – Keyboard & Mouse Connector (CN11) Signal Bi-directional clock signal used to strobe data/commands from/to the PC-AT KCLK keyboard. Bi-directional serial data line used to transfer data from or commands to the PC-AT KDAT keyboard.

  • Page 51: Usb Connector 0, 1, 2 & 3 (Cn12, Cn15)

    2.4.22 USB Connector 0, 1, 2 & 3 (CN12, CN15) 2.4.22.1 Signal Description – USB Connector 0, 1, 2, 3 (CN12, CN15) Signal Differential bi-directional data signal for USB channel 0. Clock is transmitted along D0+ / D0- with the data using NRZI encoding. The signalling bit rate is up to 12 Mbs. Differential bi-directional data signal for USB channel 1.

  • Page 52: Lcd Inverter Connector (Cn13)

    ECM-5510 2.4.23 LCD Inverter Connector (CN13) Note: For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal controlled by JP12. Please see the JP12 section for detailed circuitry information. 2.4.23.1 Signal Description – LCD Inverter Connector (CN13) Signal Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) ENBKL...

  • Page 53: Primary Ide Connector (Cn14)

    2.4.24 Primary IDE Connector (CN14) User’s Manual Signal PIN PIN Signal RESET# PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15 PDREQ PDIOW# PDIOR# PIORDY PDDACK# IRQ14 PDA1 PDA0 PDA2 PDCS1# PDCS3# IDEACTP# ECM-5510 User’s Manual 53...
  • Page 54 ECM-5510 2.4.24.1 Signal Description – Primary IDE Connector (CN14) Signal IDE Address Bits. These address bits are used to access a register or data port in PDA [2:0] a device on the IDE bus. IDE Chip Selects. The chip select signals are used to select the command block PDCS1#, PDCS3# registers in an IDE device.

  • Page 55: Floppy Connector (Flp1)

    2.4.25 Floppy Connector (FLP1) User’s Manual Signal PIN PIN Signal REDWC INDEX MOTSA DRVSB DRVSA MOTEB STEP WDATA WGATE TK00 RDATA SIDE1 DSKCHG ECM-5510 User’s Manual 55...
  • Page 56 ECM-5510 2.4.25.1 Signal Description – Floppy Connector (FLP1) Signal RDATA The read data input signal from the FDD. Write data. This logic low open drain writes pre-compensation serial data to the WDATA selected FDD. An open drain output. WGATE Write enable. An open drain output. Motor A On.

  • Page 57: Digital I/O Connector (Jdio1)

    2.4.26 Digital I/O Connector (JDIO1) 2.4.26.1 Signal Description – Digital I/O Connector (JDIO1) Signal DIO [0:17] Digital input and output Data Bit 0 to Bit 17 SMB_CLK Data input for I SMB_DATA Data input for I Signal DIO0 DIO1 DIO2 DIO3 DIO4 DIO5...

  • Page 58: Front Panel Connector (Jfp1)

    ECM-5510 2.4.27 Front Panel Connector (JFP1) 2.4.27.1 Signal Description – Front Panel Connecter (JFP1) PIN No. 1, 2 Active LAN LED 3, 4 10 Mbps LAN LED 5, 6 100 Mbps LAN LED 9, 11 Reset 10, 12 HDD LED 13, 15 Power SW 14, 16...

  • Page 59: Audio Connector (Jp4)

    2.4.28 Audio Connector (JP4) 2.4.28.1 Signal Description – Audio Connecter (JP4) Signal Mic / Mic Bias The MIC signal is used for microphone input. This input is fed to the left microphone channel. Mic Bias provides 3.3V supplied through 3.2K Ω with capacitive decoupling to GND.

  • Page 60: Lcd Backlight Brightness Adjustment Connector (Jp12)

    ECM-5510 2.4.29 LCD Backlight Brightness Adjustment Connector (JP12) 2.4.30 -5V/-12V PC/104 Voltage Connector (JP15) 60 ECM-5510 User’s Manual Signal JP12 Variation Resistor (Recommended: 4.7KΩ, >1/16W) Signal -12V CN13 pin 4...

  • Page 61: Parallel Port Connector (Lpt1)

    2.4.31 Parallel Port Connector (LPT1) User’s Manual Signal Signal STB# AFD# ERR# INIT# SLIN# ACK# BUSY SLCT ECM-5510 User’s Manual 61...

  • Page 62: Power Connector (Pwr1)

    ECM-5510 2.4.31.1 Signal Description – Parallel Port Connecter (LPT1) Signal Parallel data bus from PC board to printer. The data lines are able to operate in PD[7:0] PS/2 compatible bi-directional mode. SLIN# Output line for detection of printer selection. This pin is pulled high internally. An active high input on this pin indicates that the printer is selected.

  • Page 63: Vga Connector (Vga1)

    2.4.33 VGA Connector (VGA1) 2.4.33.1 Signal Description – VGA Connecter (VGA1) Signal HSYNC CRT horizontal synchronisation output. VSYNC CRT vertical synchronisation output. Display Data Channel Clock. Used as clock signal to/from monitors with DDC interface. Display Data Channel Data. Used as data signal to/from monitors with DDC interface.

  • Page 64: Bios Setup

    ECM-5510 3 BIOS Setup 64 ECM-5510 User’s Manual...

  • Page 65: Starting Setup

    User’s Manual 3.1 Starting Setup The AwardBIOS™ is immediately activated when you first power on the computer. The BIOS reads the system information contained in the CMOS and begins the process of checking out the system and configuring it. When it finishes, the BIOS will seek an operating system on one of the disks and then launch and turn control over to the operating system.

  • Page 66: Using Setup

    ECM-5510 3.2 Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard.

  • Page 67: Getting Help

    • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “ ” pointer marks all sub menus. 3.3 Getting Help Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.

  • Page 68: Main Menu

    ECM-5510 3.5 Main Menu Once you enter the AwardBIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu.

  • Page 69: Standard Cmos Features

    3.5.1 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into few categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. 3.5.1.1 Main Menu Selection This reference table shows the selections that you may make on the Main Menu.
  • Page 70 ECM-5510 3.5.1.2 IDE Adapter Setup The IDE adapters control the hard disk drive. Use a separate sub menu to configure each hard disk drive. The below Figure will shows the IDE primary master sub menu. Item IDE HDD Auto-detection IDE Primary Master IDE Primary Slave, Access Mode The following options are selectable only if the ‘IDE Channel …’...

  • Page 71: Advanced Bios Features

    3.5.2 Advanced BIOS Features This section allows you to configure your system for basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. 3.5.2.1 Virus Warning Allows you to choose the VIRUS Warning feature for IDE Hard Disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and alarm beep.
  • Page 72 ECM-5510 3.5.2.4 First/Second/Third/Other Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. Item Floppy Floppy Device LS120 LS120 Device HDD-0~1 Hard Disk Device 0~1 SCSI SCSI Device CDROM CDROM Device ZIP100 ZIP-100 Device USB-FDD...
  • Page 73 3.5.2.10 Typematic Delay <Msec> When the typematic rate is enabled, this selection allows you to select the delay between when the key was first depressed and when the acceleration begins. The choices: 250, 500, 750, 1000. 3.5.2.11 Security Option Select whether the password is required every time the system boots or only when you enter setup.
  • Page 74 ECM-5510 3.5.2.16 Small Logo (EPA) Show This item allows you enabled/disabled the small EPA logo show on screen at the POST step. Item Enabled EPA Logo show is enabled Disabled EPA Logo show is disabled 3.5.2.17 Onboard Lan Boot ROM This item allows to boot over the network when system POST and shorten the booting time by set disabled Item...

  • Page 75: Advanced Chipset Features

    User’s Manual 3.5.3 Advanced Chipset Features This section allows you to configure the system based on the specific features of the installed chipset. This chipset manages bus speeds and access to system memory resources, such as DRAM and the external cache. It also coordinates communications between the conventional ISA bus and the PCI bus.
  • Page 76 ECM-5510 3.5.3.3 Flat Panel Configuration Item Flat Panel Type Refresh Rate HSYNC Polarity VSYNC Polarity Active SHFCLK Active Period LP Active Period 3.5.3.4 Onboard Audio This item allows you to enable the onboard audio function. The choices: Enabled, Disabled. 76 ECM-5510 User’s Manual Options This item allows to select the flat panel TFT, LVDS...

  • Page 77: Integrated Peripherals

    3.5.4 Integrated Peripherals Use this menu to specify your settings for integrated peripherals. Item On-Chip IDE Channel 1 Master Drive PIO Mode Slave Drive PIO Mode IDE Primary Master UDMA IDE Primary Slave UDMA IDE HDD Block Mode Onboard FDC Controller Options Enabled This item allows to enable On-chip IDE channel.
  • Page 78 ECM-5510 Item Onboard Serial Port 1 Onboard Serial Port 2 UART Mode Select RxD , TxD Active IR Transmission Delay UR2 Duplex Mode Use IR Pins Onboard Parallel Port Parallel Port Mode EPP Mode Select ECP Mode Use DMA Watch Dog Timer Select Onboard Serial Port 3 Onboard Serial Port 4 PC104 IO Port...

  • Page 79: Power Management Setup

    3.5.5 Power Management Setup The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. 3.5.5.1 Power Management This category allows you to select the type (or degree) of power saving. The choices: Disabled, Legacy, APM, ACPI.
  • Page 80 ECM-5510 3.5.5.4 IRQ Wakeup Events The VGA, LPT & COM, HDD & FDD, and PCI master are I/O events which can prevent the system from entering a power saving mode or can awaken the system from such a mode. When an I/O device wants to gain the attenetion of the operating system, it signals this by causing an IRQ to occur.

  • Page 81: Pnp / Pci Configuration

    3.5.6 PnP / PCI Configuration This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

  • Page 82: Pc Health Status

    ECM-5510 3.5.6.5 PCI/VGA Palette Snoop This item is to set non-standard VGA display adapters such as graphics accelerators or MPEG video cards showing colors properly. The choices: Enabled, Disabled. 3.5.7 PC Health Status This section shows the status of your CPU, Fan & System. 3.5.7.1 Shutdown Temperature This function allows to set the shutdown temperature to avoid overheating and destroying the CPU and board.

  • Page 83: Load Fail-Safe Defaults

    3.5.8 Load Fail-Safe Defaults Use this menu to load the BIOS default values for the minimal/stable performance for your system to operate. Press <Y> to load the BIOS default values for the most stable, m inimal-performance system operations. 3.5.9 Load Optimized Defaults Use this menu to load the BIOS default values that are factory settings for optimal performance system operations.

  • Page 84: Set Supervisor / User Password

    ECM-5510 3.5.10 Set Supervisor / User Password You can set either supervisor or user password, or both of them. Supervisor Password: able to enter/change the options of setup menus. User Password: able to enter but no right to change the options of setup menus. Type the password, up to eight characters in length, and press <Enter>.

  • Page 85: Save & Exit Setup

    User’s Manual PASSWORD DISABLED. When a password has been enabled, you will be prompted to enter it every time you try to enter Setup. This prevents an unauthorized person from changing any part of your system configuration. Additionally, when a password is enabled, you can also require the BIOS to request a password every time your system is rebooted.

  • Page 86: Exit Without Save

    ECM-5510 3.5.12 Exit Without Save Abandon all CMOS value changes and exit setup, and the system is restarted after exiting. 86 ECM-5510 User’s Manual...

  • Page 87: Drivers Installation

    User’s Manual 4 Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. ECM-5510 User’s Manual 87...

  • Page 88: Install Audio Driver (For Amd Gx2)

    ECM-5510 4.1 Install Audio Driver (For AMD GX2) Insert the Supporting CD-ROM to CD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Driver_Audio\NS\GX2. Note: The installation procedures and screen shots in this section are based on Windows XP operation...
  • Page 89 User’s Manual Step6. Click Continue Anyway to run the installation. Step7. Click Finish to complete the setup. ECM-5510 User’s Manual 89...

  • Page 90: Install Display Driver (For Amd Gx2)

    ECM-5510 4.2 Install Display Driver (For AMD GX2) Insert the Supporting CD-ROM to CD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Driver_Video\NS\GX2. Note: The installation procedures and screen shots in this section are based on Windows XP operation...
  • Page 91 User’s Manual Step6. Click Continue Anyway to run the installation. Step7. Click Finish to complete the setup. ECM-5510 User’s Manual 91...

  • Page 92: Install Ethernet Driver (For Realtek Rtl810X, Rtl813X Family)

    ECM-5510 4.3 Install Ethernet Driver (For Realtek RTL810x, RTL813x Family) Insert the Supporting CD-ROM to CD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Driver_Network\Realtek\ RTL810x_813X Family.

  • Page 93: Measurement Drawing

    User’s Manual 5 Measurement Drawing ECM-5510 User’s Manual 93...
  • Page 94 ECM-5510 (Unit: mm) 94 ECM-5510 User’s Manual...

  • Page 95: Appendix A: Bios Revisions

    User’s Manual Appendix A: BIOS Revisions BIOS Rev. New Features Bugs/Problems Solved Known Problems ECM-5510 User’s Manual 95...

  • Page 96: Appendix B: Award Bios Post Messages

    ECM-5510 Appendix B: AWARD BIOS POST Messages 96 ECM-5510 User’s Manual...

  • Page 97: Overview

    Overview During the Power On Self-Test (POST), if the BIOS detects an error requiring you to do something to fix, it will either sound a beep code or display a message. If a message is displayed, it will be accompanied by: PRESS F1 TO CONTINUE OR PRESS DEL TO ENTER SETUP Post Beep Currently there are two kinds of beep codes in BIOS.

  • Page 98: Display Switch Is Set Incorrectly

    ECM-5510 DISPLAY SWITCH IS SET INCORRECTLY Display switch on the motherboard can be set to either monochrome or color. This indicates the switch is set to a different setting than indicated in Setup. Determine which setting is correct, and then either turn off the system and change the jumper, or enter Setup and change the VIDEO selection.

  • Page 99: Invalid Eisa Configuration Please Run Eisa Configuration Utility

    User’s Manual 12. Invalid EISA Configuration PLEASE RUN EISA CONFIGURATION UTILITY The non-volatile memory containing EISA configuration information was programmed incorrectly or has become corrupt. Re-run EISA configuration utility to correctly program the memory. Note: When either of these errors appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility.

  • Page 100: Press A Key To Reboot

    ECM-5510 20. PRESS A KEY TO REBOOT This will be displayed at the bottom screen when an error occurs that requires you to reboot. Press any key and the system will reboot. 21. PRESS F1 TO DISABLE NMI, F2 TO REBOOT When BIOS detects a Non-maskable Interrupt condition during boot, this will allow you to disable the NMI and continue to boot, or you can reboot the system with the NMI enabled.

  • Page 101: Wrong Board In Slot Please Run Eisa Configuration Utility

    27. Wrong Board In Slot PLEASE RUN EISA CONFIGURATION UTILITY The board ID does not match the ID stored in the EISA non-volatile memory. Note: When either of these errors appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility. 28.

  • Page 102: Post Codes

    ECM-5510 40. POST Codes Please take reference to Phoenix-Award website for the latest post codes. http://www.phoenix.com/en/Customer+Services/BIOS/AwardBIOS/Award+Error+Codes.ht 40.1 Normal POST Code EISA POST codes are typically output to port address 300h. ISA POST codes are output to Note: port address 80h. Code (hex) Name Turn Off Chipset and...
  • Page 103 Code (hex) Name Early Superio Init Reserved Blank video Reserved Init KBC KB test Reserved Mouse Init Onboard Audio init Reserved Reserved CheckSum Check Reserved Auto detec EEPROM Reserved Cmos Check Reserved Chipset Default load Reserved Clock Init Reserved Identify the CPU Reserved Reserved Setup Interrupt Vector...
  • Page 104 ECM-5510 Code (hex) Name Reserved Reserved KBC final Init Reserved Initialize Video Interface Reserved Reserved Reserved Video memory test Reserved Reserved Reserved Reserved Reserved PS2 Mouse setup Reserved Test DMA Controller 0 Reserved Test DMA Controller 1 Reserved Test DMA Page Registers Reserved Reserved...
  • Page 105 Code (hex) Name Test Stuck 8259's Interrupt Bits Test 8259 Interrupt Functionality Reserved Reserved Reserved Set EISA Mode Reserved Size Base and Extended Memory Reserved Reserved Reserved Reserved Test Base and Extended Memory Reserved USB init Reserved Memory Test Reserved Reserved CPU display Reserved...
  • Page 106 ECM-5510 Code (hex) Name Reserved Reserved Setup enable Reserved Reserved Initialize & Install Mouse Reserved PS2 Mouse special Reserved ACPI init Reserved Setup Cache Controller Reserved Setup Entering Reserved Initialize Floppy Drive & Controller Reserved FDD install Reserved Reserved Reserved Initialize Hard Drive &...
  • Page 107 Code (hex) Name Reserved Reserved POST error check Reserved Reserved Security Check Write CMOS Pre-boot Enable Initialize Option ROMs Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Boot Medium detection Final Init Special KBC patch Boot Attempt Boot Description...
  • Page 108 ECM-5510 40.2 Quick POST Codes Code (hex) Name Init onboard device Early Sytem setup KBC and CMOS Init Video Init 8259 Init Memory test CPU Detect and IO init Reserved Reserved Reserved Reserved Setup Init Setup Cache Controller 108 ECM-5510 User’s Manual Description Early Initialized the super IO.
  • Page 109 Code (hex) Name Install FDD Install FDD Detect & Initialize Math Coprocessor HDD Check for Write protection Reserved Display POST error CMOS and Option ROM Init Reserved Reserved Reserved Reserved Boot Medium detection Final Init Special KBC patch Boot Attempt Boot Description Enter setup check and auto11 configuration check up Initialize...
  • Page 110 ECM-5510 40.3 S4 POST Codes Code (hex) Name Early Chipset Init Cmos Check Chipset default Prog Identify the CPU Setup Interrupt Vector Table Test CMOS Interface and Battery status KBC final Init Initialize Video Interface Video memory test Setup PS2 mouse and test DMA Test 8259 Init Boot Device...
  • Page 111 40.4 BootBlock POST Codes Code (hex) Name Base memory test KB init Install interrupt vectors Init Video Init FDD Boot Description Clear base memory area (0000:0000--9000:ffffh) Initialized KBC Install int. vector (0-77), and initialized 00-1fh to their proper place Video initializing Scan floppy and media capacity for onboard superIO Load boot sector User’s Manual...

This manual is also suitable for:

Amd geode gx466Ecm-5510

Table of Contents
