- Page 1 EMX-NM70 Intel® Celeron® Processor Mini ITX Motherboard with Intel® NM70 Express Chipset User’s Manual Ed – 18 July 2013 Part No. E2047NM7000R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
-
Page 3: Table Of Contents
Starting Setup ....................26 Using Setup ....................27 Getting Help ....................28 In Case of Problems ..................28 BIOS setup ....................29 3.6.1 Main Menu .................... 29 3.6.1.1 System Language ................29 3.6.1.2 System Date .................. 29 EMX-NM70 User’s Manual 3... - Page 4 Save & Exit .................... 46 3.6.6.1 Save Changes and Reset .............. 46 3.6.6.2 Discard Changes and Reset ............46 The setup step of setting Triple display on EMX-NM70-GPU ....... 47 4. Drivers Installation....................... 49 Install Chipset Driver ..................50 Install VGA Driver ..................51 Install LAN Driver (For Realtek 8111E Gigabit Ethernet) ......
-
Page 5: Getting Started
Quick Installation Guide X 1 Driver/Utility CD X 1 Serial ATA Signal Cable X 1 Serial ATA Power Cable X 1 IO Shield COM Cable X 1 Screw X 3 Motherboard X 1 EMX-NM70 User’s Manual 5... -
Page 6: Document Amendment History
EMX-NM70 User’s Manual 1.3 Document Amendment History Revision Date Comment July 2013 Avalue Initial Release 6 EMX-NM70 User’s Manual... -
Page 7: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up EMX-NM70 series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 8: Specifications
1 x 2 x 2 pin ATX power connector for DC 19V input 1 x 2 x 20 pin , pitch 1.00mm connector for LVDS 1 x 5 pin , pitch 2.54mm connector for Inverter 8 EMX-NM70 User’s Manual... - Page 9 ACPI 3.0 Compliant Operating Temp. 0°C ~60°C Storage Temp. -40°C ~75°C Operating 0%~90% relative humidity, non-condensing Humidity Size (L x W) 6.7" x 6.7" (170mm x 170mm) Weight 0.40 kg EMX-NM70 User’s Manual 9...
-
Page 10: Architecture Overview-Block Diagram
EMX-NM70 User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EMX-NM70. 10 EMX-NM70 User’s Manual... - Page 11 EMX-NM70 User’s Manual The following block diagram shows the architecture and main components of EMX-NM70-GPU. EMX-NM70 User’s Manual 11...
-
Page 12: Hardware Configuration
EMX-NM70 User’s Manual 2. Hardware Configuration 12 EMX-NM70 User’s Manual... -
Page 13: Product Overview
EMX-NM70 User’s Manual 2.1 Product Overview EMX-NM70 User’s Manual 13... -
Page 14: Installation Procedure
6. Enter the BIOS setup by pressing the delete key during boot up. Use the "Save & Exit \ Restore Defaults" feature. 7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before connecting the display cable and turning on the power. 14 EMX-NM70 User’s Manual... -
Page 15: Jumper And Connector List
Connectors Label Function Note F_MIC Mic-in audio jack 3.5mm phone jack F_OUT Line-out audio jack 3.5mm phone jack USB1/2 USB connector1/2 Stack USB 2.00 connector RJ-45 Ethernet connector RJ45 w/ indicator connector DCIN DC power-in connector EMX-NM70 User’s Manual 15... - Page 16 USB Connector 1 – USB2.0 2 x 5 header, pitch 2.54 mm FUSB1 D-SUB 15pin VGA connector Half size MPCIE Mini-PCIe SO-DIMM 204Pin DIMM1 DDR3 SODIMM connector1 Power connector 2 x 2 wafer, pitch 4.20 mm 16 EMX-NM70 User’s Manual...
-
Page 17: Setting Jumpers & Connectors
2.4.1 mSATA/Mini PCIe function Jumper (JS1/JS2) MINIPCIE* M-SATA Signal M-SATA * Default MINIPCIE 2.4.2 Jumper for LVDS power (PWR_LVDS) +3.3V* +12V Signal Max current +3.3V * Default Note: This jumper is working for LVDS power. +12V EMX-NM70 User’s Manual 17... -
Page 18: Jumper For Inverter Power (Adj_Pwr)
Jumper for inverter power (ADJ_PWR) +5V* +3.3V Signal Max current * Default +3.3V Note: This jumper is working for inverter power. 2.4.4 Serial port 1/2 connector (JCOM1/2) Signal PIN PIN Signal JCOM2 JCOM1 Note: Com 1/2 Pin9 without power. 18 EMX-NM70 User’s Manual... -
Page 19: Front Panel Switches (Fpanel)
EMX-NM70 User’s Manual 2.4.5 Front Panel Switches (FPANEL) Signal PIN PIN Signal HD_LED+ PWR_LED+ HD_LED- PWR_LED- RESET PWR_ON RESET PWR_ON 2.4.6 LCD Inverter connector (INCN1) Signal Max current +12V BLK_ON Brightness EMX-NM70 User’s Manual 19... -
Page 20: Lvds Connector (Jlvds1)
PIN PIN Signal VDDPAEA VDDPAEA VDDPAEA VDDPAEA LVDS1_N0 LVDS0_N0 Note: LVDS1_P0 LVDS0_P0 Mapping connector DF13-40DS-1.25C (1.0mm). LVDS1_N1 LVDS0_N1 LVDS1_P1 LVDS0_P1 LVDS1_N2 LVDS0_N2 LVDS1_P2 LVDS0_P2 LVDS1_CLKN LVDS0_CLKN LVDS1_CLKP LVDS0_CLKP LVDS_DDCPDATA 32 LVDS_DDCPCLK LVDS1_N3 LVDS0_N3 LVDS1_P3 LVDS0_P3 LVDS_VCON 20 EMX-NM70 User’s Manual... -
Page 21: General Purpose I/O (Gpio1)
EMX-NM70 User’s Manual 2.4.8 General Purpose I/O (GPIO1) Signal PIN PIN Signal +3.3V GPIO0 GPIO68 GPIO1 GPIO69 GPIO6 GPIO70 GPIO16 GPIO71 2.4.9 USB Connector 1 - USB2.0 (FUSB1) Signal PIN PIN Signal DATA- DATA- DATA+ DATA+ EMX-NM70 User’s Manual 21... -
Page 22: Cir Connector (Cir)
EMX-NM70 User’s Manual 2.4.10 CIR connector (CIR) Signal 5VSB RX/TX 2.4.11 Speaker Headers (JSPK) Signal INTSPL+ INTSPL- INTSPR+ INTSPR- Support 3W 4ΩX 2 speaker. Note: Mapping connector PHR-4. 22 EMX-NM70 User’s Manual... -
Page 23: Power Connector (J1)
EMX-NM70 User’s Manual 2.4.12 Power connector (J1) Signal PIN PIN Signal +19V +19V Note: Power input +19V only. EMX-NM70 User’s Manual 23... -
Page 24: Sata Power Connector 1/2 (Vsata1/2)
EMX-NM70 User’s Manual 2.4.13 SATA Power connector 1/2 (VSATA1/2) Signal Max current VSATA2 VSATA1 24 EMX-NM70 User’s Manual... -
Page 25: Bios Setup
EMX-NM70 User’s Manual 3.BIOS Setup EMX-NM70 User’s Manual 25... -
Page 26: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press DEL to enter setup, F11 to popup menu 26 EMX-NM70 User’s Manual... -
Page 27: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. EMX-NM70 User’s Manual 27... -
Page 28: Getting Help
AMI and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 28 EMX-NM70 User’s Manual... -
Page 29: Bios Setup
Note: BIOS setup screens shown in this chapter are for reference only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. EMX-NM70 User’s Manual 29... -
Page 30: Advanced Bios Settings
This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 3.6.2.1 CPU Configuration Use the CPU configuration menu to view detailed CPU specification and configure the CPU. 30 EMX-NM70 User’s Manual... -
Page 31: Onboard Device Configuration
Enable or disable internal HDMI codec for Internal HDMI Audio Control Enabled Azalia. Disabled Mini Pcie Control (Port4) Enable or disable the Mini Pcie Port. Enabled[Default] Disabled USB Control Enable or disable the USB Port. Enabled[Default] EMX-NM70 User’s Manual 31... -
Page 32: Usb Legacy Features
The EHCI ownership change Enabled should be claimed by EHCI driver. Enables I/O port 60h/64h emulation support. Disabled This should be enabled for the complete USB Port 60/64 Emulation Enabled[Default] keyboard legacy support for non-USB aware OSes. 32 EMX-NM70 User’s Manual... -
Page 33: Inter® Rapid Start Technology
EMX-NM70 User’s Manual 3.6.2.4 Inter® Rapid Start Technology 3.6.2.5 Advanced Power Management Item Options Description ACPI Sleep State Suspend Disabled Select ACPI sleep state the system will enter EMX-NM70 User’s Manual 33... -
Page 34: Super Io Configuration
You can use this item to set up or change the Super IO configuration for FDD controllers, parallel ports and serial ports. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). 34 EMX-NM70 User’s Manual... -
Page 35: Serial Port 1 Configuration
Disabled Enable or Disable Serial Port Serial Port Enabled[Default] (COM). Auto[Default] IO=3F8h; IRQ=4; IO=3F8h; IRQ=3,4,5,6,7,,10,11,12; Select an optimal setting for Change Settings IO=2F8h; IRQ=3,4,5,6,7,10,11,12; Super IO device. IO=3E8h; IRQ=3,4,5,6,7,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,10,11,12; 3.6.2.6.2 Serial Port 2 Configuration EMX-NM70 User’s Manual 35... -
Page 36: Hw Monitor
Change Settings IO=2F8h; IRQ=3,4,5,6,7,10,11,12; Super IO device. IO=3E8h; IRQ=3,4,5,6,7,10,11,12; IO=2E8h; IRQ=3,4,5,6,7,10,11,12; 3.6.2.7 HW Monitor The H/W Monitor shows the operating temperature, fan speeds and system voltages. Item Description Smart Fan Function Enable or Disable Smart Fan. 36 EMX-NM70 User’s Manual... -
Page 37: Watchdog Configuration
EMX-NM70 User’s Manual 3.6.2.8 Watchdog Configuration Item Options Description Second[Default] Watchdog Count Mode WatchDog Count Mode Selection. Minute Fill WatchDog TimeOut Value, 0 means Watchdog TimeOut Value 0[Default] disabled. EMX-NM70 User’s Manual 37... -
Page 38: Serial Port Console Redirection
EMX-NM70 User’s Manual 3.6.2.9 Serial Port Console Redirection Item Options Description Disabled[Default] Console Redirection Console Redirection Enable or Disable. Enabled 38 EMX-NM70 User’s Manual... -
Page 39: Chipset
EMX-NM70 User’s Manual 3.6.3 Chipset Item Description SB Configuration PCH Parameters. North Bridge Parameters. NB Configuration 3.6.3.1 SB Configuration EMX-NM70 User’s Manual 39... -
Page 40: Nb Configuration
160M/192M/224M/256M/288M DVMT Pre-Allocated Graphics Memory size used by the Internal /320M/352M/384M/416M/448 Graphics Device. M/480M/512M/1024M Select DVMT 5.0 Total Graphics Memory size DVMT Total Gfx Mem 128M/256M[Default]/MAX used by the Internal Graphics Device. LCD Control LCD Control. 40 EMX-NM70 User’s Manual... -
Page 41: Lcd Control
1600x900 24/2 1024x768 24/1 1280x800 18/1 1920x1080 24/2 2048x1536 24/2 Auto[Default] Select the LCD panel scaling option used by Panel Scaling the Internal Graphics Device. Force Scaling PWM Inverted[Default] Backlight Control Back Light Control Setting. PWM Normal EMX-NM70 User’s Manual 41... -
Page 42: Nb Configuration-Gpu
Auto Select which of IGFX/PEG/PCI Graphics Primary Display IGFX device should be Primary Display Or select PEG[Default] SG for Switchable Gfx. Disabled Enable PEG Enabled[Default] To enable or disable the PEG. Auto LCD Control. LCD Control 42 EMX-NM70 User’s Manual... -
Page 43: Lcd Control-Gpu
Select the LCD panel scaling option used by Panel Scaling the Internal Graphics Device. Force Scaling PWM Inverted[Default] Backlight Control Back Light Control Setting. PWM Normal 18 Bit[Default] Panel Color Depth Select the LFP Panel Color Depth. 24 Bit EMX-NM70 User’s Manual 43... -
Page 44: Boot Settings
Disabled it for update ME region. Enabled[Default] Auto: If the 1 boot HDD is GPT Auto[Default] then enable UEFI boot options, UEFI Boot Enabled otherwise disable. Enabled: Disabled Enable all UEFI boot options. Disabled all UEFI boot options. 44 EMX-NM70 User’s Manual... -
Page 45: Security
If only the User's password is set, then this is a power on password and must be entered to boot or enter the BIOS setup program. In the BIOS setup program, the User will have Administrator rights. By default, no password is specified. EMX-NM70 User’s Manual 45... -
Page 46: Save & Exit
Any changes made to BIOS settings are stored in NVRAM. The setup program then exits and reboots the controller. 3.6.6.2 Discard Changes and Reset Any changes made to BIOS settings during this session of the BIOS setup program are discarded. The setup program then exits and reboots the controller. 46 EMX-NM70 User’s Manual... -
Page 47: The Setup Step Of Setting Triple Display On Emx-Nm70-Gpu
EMX-NM70 User’s Manual The setup step of setting Triple display on EMX-NM70-GPU BIOS Settings: Before change BIOS setting to enable LVDS, please to connect CRT/HDMI monitor for show your screen and connect LVDS panel. BIOS chipset NB Configuration Primary Display IGFX. - Page 48 EMX-NM70 User’s Manual EMX-NM70-GPU at Windows Setup Step. PEGCRT, HDMI: nVidia Graphic. To choice different kind of Graphic on BIOS IGFXLVDS: Intel Chipset Boot Display: VBIOS DefaultCRT+HDMI LCD Panel Type: Default is 1024x768 18/1 VBIOS Default BIOS/DOS: IGFX+PEGLVDS only , PEGCRT only...
-
Page 49: Drivers Installation
EMX-NM70 User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. EMX-NM70 User’s Manual 49... -
Page 50: Install Chipset Driver
4.1 Install Chipset Driver Insert the Supporting DVD-ROM to DVD-ROM drive, click on “start” icon and it should show the index page of Avalue’s products automatically. If not, locate the folder HTML and choose the product from the targeted folder. -
Page 51: Install Vga Driver
4.2 Install VGA Driver Insert the Supporting DVD-ROM to DVD-ROM drive, click on “start” icon and it should show the index page of Avalue’s products automatically. If not, locate the folder HTML and choose the product from the targeted folder. - Page 52 EMX-NM70 User’s Manual Step 7. Select Finish to complete Installation. 52 EMX-NM70 User’s Manual...
-
Page 53: Install Lan Driver (For Realtek 8111E Gigabit Ethernet)
4.3 Install LAN Driver (For Realtek 8111E Gigabit Ethernet) Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or... -
Page 54: Install Me Driver
4.4 Install ME Driver Insert the Supporting DVD-ROM to DVD-ROM drive, click on “start” icon and it should show the index page of Avalue’s products automatically. If not, locate the folder HTML and choose the product from the targeted folder. -
Page 55: Install Audio Driver (For Realtek Alc661 Hd Audio)
4.5 Install Audio Driver (For Realtek ALC661 HD Audio) Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Driver_Audio\EMX-NM70_Audio. -
Page 56: Install Cir Driver
4.6 Install CIR Driver Insert the Supporting DVD-ROM to DVD-ROM drive, and it should show the index page of Avalue’s products automatically. If not, locate Index.htm and choose the product from the menu left, or link to \Utility\EMX-NM70_CIR Note: The installation procedures and screen shots in this section are based on Windows 7 operation system. -
Page 57: Install Vga Driver For Emx-Nm70-Gpu Board Only
EMX-NM70 User’s Manual 4.7 Install VGA Driver for EMX-NM70-GPU Board only Insert the Supporting DVD-ROM to DVD-ROM drive, click on “start” icon and it should show the index page of Avalue’s products automatically. If not, locate the folder HTML and choose the product from the targeted folder. -
Page 58: Mechanical Drawing
EMX-NM70 User’s Manual 5. Mechanical Drawing 58 EMX-NM70 User’s Manual... - Page 59 EMX-NM70 User’s Manual Unit: mm EMX-NM70 User’s Manual 59...
- Page 60 EMX-NM70 User’s Manual Unit: mm 60 EMX-NM70 User’s Manual...
