- Page 1 EAX-785E AMD Turion /Athlon II Neo Processor User’s Manual Ed – March 11 2011...
- Page 2 CORRECT THE INTERFERENCE AT HIS OWN EXPENSE. Copyright Notice Copyright © 2011 Avalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
- Page 3 Avalue Technology Inc. Room 805, Building 9,No.99 Tianzhou Rd., 2F keduka-Bldg, 2-27-3 Taito, Caohejing Development Area, Taito-Ku, Tokyo 110-0016 Japan Xuhui District, Shanghai Tel: +81-3-5807-2321 Tel: +86-21-5169-3609 Fax:+86-21-5445-3266 Fax: +81-3-5807-2322 Information: sales.china@avalue.com.cn Information: sales.japan@avalue.com.tw Service: service@avalue.com.tw Service: service@avalue.com.tw EAX-785E User’s Manual 3...
-
Page 4: Table Of Contents
2.3.13.1 Signal Description – LCD Inverter Connector (JBKL1)) ......25 2.4.14 General Purpose I/O connector (JDIO1) ..........26 2.4.15 LVDS connector (JLVDS1)..............27 2.4.16 Cross fire Power connector (XFIRE_PWR1).........28 2.4.17 SPI programming connector (SPI1) ............28 2.4.18 USB connector 56 & 78 (USB56/78) .............29 3. Mechanical Drawing ....................30 4 EAX-785E User’s Manual... -
Page 5: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following items have been shipped: 1 x EAX-785E ATX Main Board 2 x SATA cable kit(SATA/power) COM 9P Cable W/O Bracket PH:2.00mm 1 x DRIVER CD (CD-R) without printed LOGO... -
Page 6: Document Amendment History
EAX-785E User’s Manual 1.3 Document Amendment History Revision Date Comment March 2011 Initial Release 6 EAX-785E User’s Manual... -
Page 7: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with EAX-785E series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 8: System Specifications
1 x eSATA 8 x USB 2.0 (4 x rear I/O, 4x pitch2.54 pin-header) IrDA 8Bit (4in/4out) 1 x KB/MS External I/O 1 x VGA Connector 1 x RS-232 (powered, 5V/12V selectable) 4 x USB 2.0/1.1 8 EAX-785E User’s Manual... - Page 9 Audio Interface Mic in, Line out Audio Amplifer TPA3005D2 Stereo 6Watt per channel Ethernet LAN 1 Intel® 82577-LM PCI-E Gigabit LAN support iAMT 6.0 LAN 2 Realtek RTL8111C PCI-E GbLAN 1000 Base-Tx Gigabit Ethernet compatible Ethernet Interface EAX-785E User’s Manual 9...
- Page 10 CPU maximum supports to TDP 95W Power Type 20pin ATX interface+ 4 pin CPU power connector Operating Temperature 0~60°C (32~140°F) Operating Humidity 0%~90% relative humidity, non-condensing Size (L x W) 12" x 9.6" (308mm x 244mm) Weight 1.32ibs(0.6Kg) 10 EAX-785E User’s Manual...
-
Page 11: Architecture Overview - Block Diagram
EAX-785E User’s Manual 1.6 Architecture Overview – Block Diagram The following block diagram shows the architecture and main components of EAX-785E. EAX-785E User’s Manual 11... -
Page 12: Hardware Configuration
EAX-785E User’s Manual 2. Hardware Configuration 12 EAX-785E User’s Manual... -
Page 13: Product Overview
EAX-785E User’s Manual 2.1 Product Overview EAX-785E User’s Manual 13... -
Page 14: Installation Procedure
Note: Make sure the heat sink and the CPU top surface are in total contact to avoid CPU overheating problem that would cause the system to hang or unstable 14 EAX-785E User’s Manual... -
Page 15: Main Memory
EAX-785E User’s Manual 2.2.1 Main Memory EAX-785E provides 4 x 240-pin DDR3 DIMM, max. up to 8GB DDR3 800/1066/1333 with ECC support. DIMM Make sure to unplug the power supply before adding or removing DIMMs or other system components. Failure to do so may cause severe damage to both the board and the components. - Page 16 (2) Static electricity can damage the electronic components of the computer or optional boards. Before starting these procedures, ensure that you are discharged of static electricity by briefly touching a grounded metal object. 16 EAX-785E User’s Manual...
-
Page 17: Jumper And Connector List
Jumpers Label Function Note Clear CMOS 3 x 1 header, pitch 2.54 mm CLRTC1 Amplifier controller 5 x 1 header, pitch 2.54 mm CN21 JCOMPWR1/2/3/4 Power Selector 3 x 2 header, pitch 2.54 mm Ring /+5V/+12V EAX-785E User’s Manual 17... - Page 18 4 x 1 wafer, pitch 5.08 mm XFIRE_PWR1 SATA1/2/3/4/5 Serial ATA connector 1/2/3/4 SPI programming connector 3 x 2 header, pitch 2.54 mm SPI1 USB connector 56 & 78 5 x 2 header, pitch 2.54 mm USB56/78 18 EAX-785E User’s Manual...
-
Page 19: Setting Jumpers & Connectors
EAX-785E User’s Manual 2.4 Setting Jumpers & Connectors 2.4.1 Clear CMOS (CLRTC1) Normal * Clear * Default 2.4.2 Amplifier Controller (CN21) VR connection* Signal PORT_A_R LOUT_RR PORT_A_L LOUT_LL * Default EAX-785E User’s Manual 19... -
Page 20: Power Selector Ring/+5V/+12V (Jcompwr1)
EAX-785E User’s Manual 2.4.3 Power selector Ring (JCOMPWR1) /+5V/+12V Ring * +12V * Default 2.4.4 Power selector Ring (JCOMPWR2/3/4) /+5V/+12V Ring * +12V 4 3 2 * Default 20 EAX-785E User’s Manual... -
Page 21: Atx Power Connector (Atxpwr1)
EAX-785E User’s Manual 2.4.5 ATX power connector (ATXPWR1) Signal PIN PIN Signal +12V +5VSB ATX_PWRGD PSON# +3.3V -12V +3.3V +3.3V 2.4.6 AT Power connector (ATX12V1) Signal PIN PIN Signal +12V_VCORE +12V_VCORE EAX-785E User’s Manual 21... -
Page 22: Azalia Front Audio Connector (Aafp1)
EAX-785E User’s Manual 2.4.7 Azalia Front audio connector (AAFP1) Signal PIN PIN Signal MIC2_L MIC2_R FP_PRES# LIN2_R SRTN1 SENSE_B LIN2_L SRTN2 2.4.8 Chassis Fan connector (CHA_FAN1) Signal +12V SFAN_TACH 22 EAX-785E User’s Manual... -
Page 23: Cpu Fan Connector (Cpu_Fan1)
EAX-785E User’s Manual 2.4.9 CPU Fan connector (CPU_FAN1) Signal +12V CFAN_TACH CFAN_PWM 2.4.10 Serial port 2/ 3/ 4 connector (COM 2/3/4) Signal PIN PIN Signal DDCD2# RRXD2 TTXD2 DDTR2# DDSR2# RRTS2# CCTS2# COM2P9SEL EAX-785E User’s Manual 23... -
Page 24: System Panel Connector (F_Panel1)
EAX-785E User’s Manual 2.4.11 System Panel connector (F_PANEL1) Signal PIN PIN Signal SYS_RST# PWRBTN# PLED- HPLED- PLED+ HDLED+ 2.4.12 Amplifier connector (JAMP1) Signal 24 EAX-785E User’s Manual... -
Page 25: Lcd Inverter Connector (Jbkl1)
For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal. 2.3.13.1 Signal Description – LCD Inverter Connector (JBKL1)) Signal Signal Description BRIGHT Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) LBKLT_EN LCD backlight ON/OFF control signal EAX-785E User’s Manual 25... -
Page 26: General Purpose I/O Connector (Jdio1)
EAX-785E User’s Manual 2.4.14 General Purpose I/O connector (JDIO1) Signal Signal GPIO0 GPIO4 GPIO1 GPIO5 GPIO2 GPIO6 GPIO3 GPIO7 +5V_USB_R 26 EAX-785E User’s Manual... -
Page 27: Lvds Connector (Jlvds1)
EAX-785E User’s Manual 2.4.15 LVDS connector (JLVDS1) Signal PIN PIN Signal +3.3V +3.3V I2C_CLK I2C_DATA B_CK+ A_CK+ B_CK- A_CK- +12V +12V EAX-785E User’s Manual 27... -
Page 28: Cross Fire Power Connector (Xfire_Pwr1)
EAX-785E User’s Manual 2.4.16 Cross fire Power connector (XFIRE_PWR1) Signal +12V 2.4.17 SPI programming connector (SPI1) Signal Signal +3.3V DATAIN DATAOUT HOLD# 28 EAX-785E User’s Manual... -
Page 29: Usb Connector 56 & 78 (Usb56/78)
EAX-785E User’s Manual 2.4.18 USB connector 56 & 78 (USB56/78) Signal Signal +USBV4567 +USBV4567 EAX-785E User’s Manual 29... -
Page 30: Mechanical Drawing
EAX-785E User’s Manual 3. Mechanical Drawing 30 EAX-785E User’s Manual... - Page 31 EAX-785E User’s Manual EAX-785E User’s Manual 31...
- Page 32 EAX-785E User’s Manual 32 EAX-785E User’s Manual...
