Hytronik HC038V Instruction Manual

DETACHED VERSION, MODEL NO.:HC038V / HCD038 + SAM8/SAM11+HC034RF
PRODUCT TYPE:
OPERATING VOLTAGE:
HF SYSTEM:
RATED LOAD (for HC038V):
OUTPUT (for HCD038):
DETECTION ANGLE:
POWER CONSUMPTION:
DETECTION RANGE (DxH):
HOLD TIME:
DAYLIGHT SENSOR:
STAND-BY PERIOD:
STAND-BY DIMMING LEVEL:
MOUNTING:
WORKING TEMP.:
120
Model: SAM8 (RF grouping by remote control HRC-04)
Buzzer
RF antenna
Cable entry
Installation hole
Model: SAM11 (RF grouping by rotary switch or remote control HRC-04)
RF antenna
Rotary switch
Model: HC034RF (RF receiver can serve as slave only, RF grouping by rotary switch or remote control HRC-04)
Rotary switch
Infrared remote receiver
1-10V+
1-10V
HYTRONIK INDUSTRIAL LIMITED
Room D, 10/f, Tower A, Billion Center, 1 wang Kwong Road,
Kowloon Bay, Kowloon, Hongkong
T: 00852-35197525
E: info@hytronik.com
INSTRUCTION MANUAL FOR RF WIRELESS SENSOR
Technical Specifications
Microwave Motion Sensor
220-240VAC
5.8GHz CW radar
400W (capacitive load)
Max. 15 devices, Max. 30mA
30° ~ 150°
<0.5W
Max. 12 x 6m
30s ~ 30min.
2 ~ 20Lux; disable
0s, 10s ~ 30min, +∞
10% ~50%
Indoors, ceiling & wall mounted
-20 ~ +60℃
LED indication
Antenna module
Infrared remote receiver
Daylight sensor
Antenna module
Buzzer
Daylight sensor
Installation hole
Infrared remote receiver
LED indication
RF antenna
Installation hole
N N L
L'
-
F: 00852-30116936
RJ12 connector
50Hz/60Hz
1-10V-
1-10V+
RJ12 connector
32.5
43.3
52.5
57.5
63.6
71.5
71.5
78.2
87
CHINA FACTORY
3rd Floor, block C, complex building, 155#, Bai'gang road south,
Bai'gang village, Xiao Jin Kou town, Huicheng district, Huizhou 516023
Tel:86-752-2772020 F:86-752-2777877
E: info@hytronik.com W:www.hytronik.com
HC038V
HCD038
110.5
Push
L'
N
N
L
DALI
DALI
Push
N
L
