- Page 1 Operation Manual Series 300 General Purpose Incubator Thank you for Choosing Biolab products. Please read the “Operating Instructions” and “Warranty” before operating this unit to assure proper operation.
-
Page 2: Table Of Contents
General Purpose Incubator BIGP 300 series Index 1. Summary ..........................03 2. Structure features......................03 3. Product diagram .......................04 4. Technical Parameter Table....................04 5. Inner Chamber temperature distribution map............05 6. Curve table Temperature rising special curve............05 7. Working conditions......................06 8. Safety information......................06 9. -
Page 3: Summary
General Purpose Incubator BIGP 300 series Summary It is suitable for culture and scientific research of bacteria and microbe. It is the important test equipment in practice of industries of modern medicine, pharmaceutical, biology and biochemistry. Structure Features 1. The casing of this instrument adopts high quality cold-roll steel sheet. The surface treated by coating technology. -
Page 4: Product Diagram
General Purpose Incubator BIGP 300 series Product Diagram Technical Parameter Temperature Model BIGP-301 BIGP-302 BIGP-303 BIGP-304 Working voltage 220~240V 50Hz/60Hz Temperature Room temperature +5~65℃ Range Temperature ±0.5℃ Motion Heating power 250W 500W 600W Shelf load 15kg Inner Chamber 350×350×350 400×350×350 500×450×550... -
Page 5: Inner Chamber Temperature Distribution Map
General Purpose Incubator BIGP 300 series Inner Chamber Temperature Distribution Map Temperature Temperature Temperature Temperature ℃ ℃ point point 3 7 2 6 3 6. 5 0 ① ⑤ 3 6 . 3 0 ⑥ ② 3 7 2 1 ③... -
Page 6: Working Conditions
General Purpose Incubator BIGP 300 series Working Conditions 1．Environment temperature ： 5 ~65 ℃ ℃ 2．Relative humidity ： 50%RH ≤ 3．Pressure: 80-106Kpa 4．No violent shake and corrosive gas around the incubator. 5．Avoid direct sun or effect from other cooling and heating sources. -
Page 7: Controller Operation Instruction
General Purpose Incubator BIGP 300 series surface. The neutral washing detergent could be used for regular cleaning, then wipe by dry cloth. 6. When the equipment stops, cutoff the power and keep interior and exterior dry and clean. Controller Operation Instruction TST series intellectual temperature controller is the new temperature controller which adopts microcomputer control and applied with resistance temperature and thermocouple. - Page 8 General Purpose Incubator BIGP 300 series . Temperature time operation ⅱ The normal display of instrument, the upper row digital tube displays measured temperature, the lower row digital tube displays the setting temperature. Press the set key, enter temperature setting state.
- Page 9 General Purpose Incubator BIGP 300 series Regulate the required time by ▲ or ▼，then press for confirmation, back to normal display page. Note: If there is no setting number over 5 seconds in the picture, the instrument will back to normal display page automatically, operate again for setting. If set the time as 0, it has no timing function.
- Page 10 General Purpose Incubator BIGP 300 series 3. When temperature alarm, the buzzer will sound," ALM" lights. If a change in temperature setting and over-temperature alarm, "ALM" lights up, but no songs buzzer. 4. When the buzzer sounds, it can be muted by pressing any button.
- Page 11 General Purpose Incubator BIGP 300 series Parameter list-1: (Setting Parameter Instruction of the Parameter’s Name range)factory set indicator function value when Lc=3 ,then we can see and Password modify parameters When temperature is beyond “SP+AL”, the Alarm indicator turns Alarming setting (0～100 ) 5...
-
Page 12: Wiring
General Purpose Incubator BIGP 300 series mode En = 0 end of run off output; End of operation En = 1 end run to constant (0～1) 1 temperature temperature; Range of temp (0～100.0 ) ℃ The value of temperature setting. -
Page 13: Fault Analysis
General Purpose Incubator BIGP 300 series Fault Analysis Fault site Cause analysis Treatment method Power indicating lamp is not No power Check the outlet working. The temp. controller The fuse is fused Replace the fuse displays “0000” The temp. cannot go down... - Page 14 General Purpose Incubator BIGP 300 series BIOLAB SCIENTIFIC LTD. 3660 Midland Avenue, Suite 300, Toronto, Ontario M1V 0B8 Canada Email: contact@biolabscientific.com Tel: +1 707 533 1445 Website: www.biolabscientific.com www.biolabscientific.com...
