- Page 1 Operation Manual BBBF-106 Blood Bank Refrigerator Thank you for Choosing Biolab products. Please read the “Operating Instructions” and “Warranty” before operating this unit to assure proper operation.
- Page 2 Blood Bank Refrigerator BBBF-106 Thank you for buying 4 storage refrigerator freezer! ℃ For your personal safety and better performance of this unit, please read this Operation Manual thoroughly and save it properly for future reference. Failure to read, understand and follow the instructions in this manual may result in damage to the unit, injury to operating personnel and poor equipment performance.
-
Page 3: Table Of Contents
Blood Bank Refrigerator BBBF-106 Index 1. Schematic Picture and Description.......................04 2. Pre Installation..............................05 3. Operation Direction............................06 4. Unused-Maintenance..........................09 5. Service After Sale............................09 6. Specifications..............................10 7. Circuit Diagram............................11 www.biolabscientific.com... -
Page 4: Schematic Picture And Description
Blood Bank Refrigerator BBBF-106 Schematic Picture and Description Temperature Recorder Control Panel Lamp Switch Door Heating Door Heating Door Handle Door Cabinet Because the freezer amelioration and the model different, the actual product may not the same as the photo, please follow the actual refrigerator. -
Page 5: Pre Installation
Blood Bank Refrigerator BBBF-106 Pre Installation 1. How to transport: Pick up the unit from the bottom of tank and a slant plane within 45° is acceptable. All transportation should be carefully. 2. Remove all wrappers. 3. Check accessories and documents according to package list. -
Page 6: Operation Direction
Blood Bank Refrigerator BBBF-106 Operation Direction Function Introduction for Display Panel （ ） 1. With unit °C under normal running condition and display different hint string under set condition: Refer follows for details （ ） 2. Comp RUN: when compressor running, will light. - Page 7 Blood Bank Refrigerator BBBF-106 First Use （ ） 1. Connect the power supply and switch the on-off on the back of freezer working status; 2. Set temperature: the default temperature is set as 4 ℃ in factory. Please don’t set any other temperature value.
- Page 8 Blood Bank Refrigerator BBBF-106 print key of printer to automatically print recorded data. All data are printed per 5 miniatures with a format as “Year, Month, Day, Time, temperature. When the print finishes, the buzzer buzzes for 5 seconds, then the system exits the print mode. To cancel print midway, press “Print”...
-
Page 9: Unused-Maintenance
Blood Bank Refrigerator BBBF-106 Unused-Maintenance 1. Leave Unused: If the unit is not used for long time, please disconnect power supply and maintain as the following procedures. For next time operation, ensure there is not any water around the liners to avoid the seal of door is frozen. -
Page 10: Specifications
Blood Bank Refrigerator BBBF-106 The door is not closed properly or is opened too frequently. than setting Overfull materials are put into chamber. Ambient temperature is too high. Freezer is not leveled well. Too great noise Freezer leans upon the wall. -
Page 11: Circuit Diagram
Blood Bank Refrigerator BBBF-106 Package List: Name Operation Manual Quality Certificate Plastic Bag Amount Circuit Diagram All technical parameters and circuit diagram in nameplate are final ones for your units. www.biolabscientific.com... - Page 12 BIOLAB SCIENTIFIC LTD. 3660 Midland Avenue, Suite 300, Toronto, Ontario M1V 0B8 Canada Email: contact@biolabscientific.com Tel: +1 707 533 1445 Website: www.biolabscientific.com...
