RF-Lambda REMC0052G200A Manual

Note: Photo is for illustration purposes only.
Please refer to outline drawing.
Features
•
Wideband EMC Solid State Power Amplifier
•
Small Signal Gain 55dB Typical
•
Output Saturation Power 53dBm Typical
•
Supply Voltage 110/220 VAC
•
50 Ohm Matched Input/Output
•
Over temperature protection
•
Over current protection
•
Auto Calibration
Electrical Specifications (T
Gain Variation Over Temperature (0⁰C to +50⁰C)
Output 1dB Compression Point (P1dB)
Saturated Output Power (Psat) (CW)
Supply Current (110V AC)
Power Added Efficiency (PAE)
Turn On/Off Speed (Switch Disable)
Turn On/Off Speed (Drain Disable)
Turn On/Off Speed (Gate Disable)
Input / Output Connectors
Rev 1. 03/16/2023 | Subject to change without notice
Wideband EMC Benchtop Power Amplifier
0.02GHz-0.52GHz
=+25⁰C)
A
Parameter
Frequency Range
Small Signal Gain
Gain Flatness
Input VSWR
Weight
Impedance
Package
Product Description
REMC0052G200A is a wideband EMC power amplifier with a frequency
range of 0.02 to 0.52GHz.
The power output of this amplifier is 53dBm typical. The typical small signal
gain is 55dB with a flatness of ±3.0dB. This excellent performance is
achieved through the use of GaN devices.
The power amplifier input connector is N-Female and output connector is N-
Female.
The operating temperature of this product is within 0⁰C to +50⁰C.
Typical Applications
•
Wireless Infrastructure
•
Military and Aerospace Applications
•
Test Instrumentation
•
Radar Systems
•
5G Wireless Communications
•
Microwave Radio Systems
•
TR Modules
•
Research and Development
•
Cellular Base Stations
Min Typ
0.02
50 55
±3.0
±3.0
1.5
50
53
30
ON 100
OFF 100
ON 500
OFF 500
ON
OFF
N-Female(Input)/N-Female (Output)
3U Rack-mount/Tabletop Chassis
Sales: sales@rflambda.com
REMC0052G200A
Max
0.52
1 7
/
/
/
50
RF-LAMBDA USA LLC:
Technical: support@rflambda.com
Units
GHz
dB
dB
dB
:1
dBm
dBm
A
%
ns
ns
us
us
us
us
lbs.
Ohms
www.rflambda.com
