RF-Lambda REMC0218GD Manual

Features
• Wideband EMC S Benchtop Power Amplifier
• Small Signal Gain 50dB Typical
• Output Saturation Power 47dBm Typical
• Supply Voltage 110/220 VAC
• 50 Ohm Matched Input/Output
• Overvoltage Protection
• Overcurrent Protection
• Auto Calibration
Electrical Specifications (T
Frequency Range
Small Signal Gain
Gain Flatness
Gain Variation Over Temperature (-40⁰C to +85⁰C)
*Output 1dB Compression Point (P1dB)
*Saturated Output Power (Psat)
Supply Current (110V/ 220V AC)
Efficiency at Psat
Input / Output Connectors
Rev 2. 06-25-2021 | Subject to change without notice
Wideband EMC Benchtop Power Amplifier
=+25⁰C)
A
Parameter
Input VSWR
Isolation S12
Weight
Impedance
2GHz-18GHz
Product Description
The REMC0218GD is a wideband EMC power amplifier with a frequency
range of 2 to 18GHz.
The power output of this amplifier is 47dBm typical. The typical small signal
gain is 50dB with a gain flatness of ±5 dB.
The power amplifier's input connector is SMA-Female and output connector
is N-Female. This product has a calibration feature which enables customer
to obtain great performance through time and temperature changes.
The operating temperature of this product is within -40 to +85⁰C.
Typical Applications
• Wireless Infrastructure
• Military and Aerospace Applications
• Test Instrumentation
• Radar Systems
• 5G Wireless Communications
• Microwave Radio Systems
• TR Modules
• Research and Development
• Cellular Base Stations
Min
47
SMA-Female(Input)-N-Female(Output)
Sales:
REMC0218GD
Typ Max
2 – 18
50
±5
±3
2
45
47
60
4
10
22.53
50
RF-LAMBDA USA LLC:
sales@rflambda.com Technical:
Units
GHz
dB
dB
dB
:1
dBm
dBm
dB
A
%
lbs.
Ohms
www.rflambda.com
support@rflambda.com
