RF-Lambda REMC06G18GD Quick Start Manual

Features
• Wideband EMC Solid State Power Amplifier
• Small Signal Gain 70dB typical with Digital
Attenuator 31.5dB Range, 0.5dB Step Size.
• Output Saturation Power 48dBm Typical
• Supply Voltage 110/220 VAC
• 50 Ohm Matched Input/Output
• Automatic Calibration
• Built in Temperature Compensation
• Protections:
• Over Current Protection
• Over Temperature Protection
• Current Imbalance Protection
• RF Input Protection
• VSWR protection
Electrical Specifications (T
Parameter
Frequency Range
Small Signal Gain
(without attenuation)
Gain Variation Over Temperature
(-30℃ ~ +70℃)
Input Return Loss
*Saturated Output Power (Psat)
Isolation S12
Input Max Power (No Damage)
Weight
Impedance
Power Supply Connector
Input / Output Connectors
Package
Rev 4. 01-20-2022 | Subject to change without notice
Solid State EMC Benchtop Power Amplifier
6GHz~18GHz
=+25⁰C)
A
Product Description
REMC06G18GD is a solid state EMC benchtop amplifier with a frequency
range of 6 to 18GHz.
The power output of this amplifier is 48dBm typical. The typical small signal
gain is 60dB with a gain flatness of ±10dB. This performance is achieved
through the use of GaN devices. This power amplifier works with a 110/220
VAC supply.
This product has a calibration feature which enables customer to obtain
great performance through time and temperature changes.
Typical Applications
• Wireless Infrastructure
• Military and Aerospace Applications
• Test Instrumentation
• Radar Systems
• 5G Wireless Communications
• Microwave Radio Systems
• TR Modules
• Research and Development
• Cellular Base Stations
Min Typ
6 - 18
70
±3
15
48
80
Psat – Gain
35
50
D-SUB COMBO 3POS
SMA-Female or N-Female(Input) – N-Female(Output)
4U 19" Rack-mount/Tabletop Chassis
(detail dimension in last page)
Sales: sales@rflambda.com
REMC06G18GD
Max Units
GHz
dB
dB
dB
dBm
dB
dBm
lbs
Ohms
RF-LAMBDA USA LLC: www.rflambda.com
Technical: support@rflambda.com
