RF-Lambda REMC0727GB Quick Start Manual

Features

•
Wideband EMC Solid State Power Amplifier
•
Small Signal Gain 57dB Typical
•
Output Saturation Power 53dBm Typical
•
Supply Voltage 110/220 VAC
•
50 Ohm Matched Input/Output
•
Overvoltage Protection
•
Overcurrent Protection
•
Auto Calibration
Electrical Specifications (T
Gain Variation Over Temperature (0⁰C to +50⁰C)
Output 1dB Compression Point (P1dB)
Saturated Output Power (Psat)
Supply Current (220V AC)
Power Added Efficiency (PAE)
Turn On/Off Speed (Switch Disable)
Turn On/Off Speed (Drain Disable)
Turn On/Off Speed (Gate Disable)
Input / Output Connectors
Rev 1. 06-28-2023 | Subject to change without notice
Wideband EMC Benchtop Power Amplifier
0.7GHz-2.7GHz
=+25⁰C)
A
Parameter
Frequency Range
Small Signal Gain
Gain Flatness
Input VSWR
IM3
Weight
Impedance
Package

Product Description

REMC0727GB is a wideband EMC power amplifier with a frequency range
of 0.7 to 2.7GHz.
The power output of this amplifier is 53dBm typical. The typical small signal
gain is 57dB with a flatness of ±2.0dB. This excellent performance is
achieved through the use of GaN devices.
The power amplifier's input / Output connector is N-Female. This product
has a calibration feature which enables customer to obtain great
performance through time and temperature changes. The operating
temperature of this product is within 0⁰C to +50⁰C.

Typical Applications

•
Wireless Infrastructure
•
Military and Aerospace Applications
•
Test Instrumentation
•
Radar Systems
•
5G Wireless Communications
•
Microwave Radio Systems
•
TR Modules
•
Research and Development
•
Cellular Base Stations
Min Typ
0.7
50 57
±2.0
±3.0
1.5
50
53
-28
10
ON 250
OFF 250
ON 500
OFF 250
ON 1500
OFF 250
3U Rack-mount/Tabletop Chassis
