Christie CP2000-ZX Quick Setup Manual

INTRODUCTION
Use the following instructions when replacing or upgrading a Processor Control Module (PCM) in
CP2000-ZX and CP2000-M/MR projectors.
The entire procedure requires access to the cardcage, complete removal of the PCM assembly, and in
CP2000-M/MR 119-101101-01 models installing a new faceplate when upgrading from a 3.1 PCM
(001-100536-03/04) to a 4.1 PCM (001-100536-06). The entire procedure can take up to 20 minutes to
complete and should be performed by a qualified service technician.
KITS REQUIRED
003-002884-01 PCM Kit (includes PCM #001-100536-06 board only)
003-100536-06 PCM Kit (includes PCM #001-100536-06 board, faceplates for CP2000-ZX and
CP2000-M/MR and required hardware)
CP2000-ZX faceplate.
SAFETY AND WARNING GUIDELINES
HIGH VOLTAGES MAY BE EXPOSED: Always power down and disconnect power
sources prior to servicing. Once the projector is powered down, allow the cooling fans to
automatically turn OFF before disconnecting from AC and opening the projector. Depending on
your projector model this can take 10-15 minutes.
procedures must be performed by qualified service technicians.
disconnect from AC prior to disassembly.
OBSERVE ALL ELECTROSTATIC PRECAUTIONS: Use a grounded wrist strap
when handling electronic assemblies.
Never operate the projector (or the fans) without all the covers installed.
Replacing the PCM Instruction Sheet
020-100369-01 Rev. 1 (06-2009)
NOTE: The PCM comes pre-assembled with the
QUALIFIED SERVICE TECHNICIANS REQUIRED: All module replacement
NON-INSULATED DANGEROUS VOLTAGES MAY BE EXPOSED: Always
https://manual-hub.com/
Replacing the PCM
Instruction Sheet
1 of 5
