DUSK Sienna 5 Drawer Chest Instruction Booklet

Product dimensions:w80xd45xh99.5 cm
Hide thumbs

Advertisement

Quick Links

Download this manual
Range Name: Sienna
Box 1 dimensions:W94xD52.5xH25 cm
Product dimensions:W80xD45xH99.5 cm
5 Drawer Chest
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Up to 1 hour
Two person
assembly time
assembly
This product is intended for domestic use only, not for commercial purposes.
P-1-16
V-2.0
