THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Up to 45 minutes
assembly time
This product is intended for domestic use only, not for commercial purposes.
Console
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Two person
assembly
Range Name: Sienna
Box 1 dimensions: W124xD47.5xH18.5 cm
Product dimensions: W110xD39.7xH80 cm
P-1-11
V-2.0
Advertisement
Related Manuals for DUSK Sienna Console
Summary of Contents for DUSK Sienna Console
- Page 1 Range Name: Sienna Box 1 dimensions: W124xD47.5xH18.5 cm Product dimensions: W110xD39.7xH80 cm Console THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Up to 45 minutes Two person assembly time assembly This product is intended for domestic use only, not for commercial purposes. P-1-11 V-2.0...
-
Page 2: Care And Maintenance
IMPORTANT ASSEMBLY TIP Before you begin, it's best to identify all of the parts and fittings to build your console frame. We advise laying these out on the floor to check you have everything, and to familiarise yourself with all of the parts and fittings before building. TOP TIP We recommend that you assemble the console in the room you'd like it to be located. -
Page 3: Parts List
Parts list P-3-11... - Page 4 Parts list Before you begin building your console, please take a moment to read through the instructions and make sure that you have all the relevant parts listed on the parts check list. Part Description Quantity Box No Part Number Bottom Panel 1 pc Box 1...
- Page 5 Fittings Please check you have all the fittings listed below with your product in box 1. M6*35mm Ø6*30mm Dowel M4*35mm Screw Handle M4*20mm Bolt Ø15*9mm Cam Lock Cam Lock Screw 37pcs+4pcs extra 37pcs+4pcs extra 16pcs+2pcs extra 19pcs+2pcs extra 3pcs 6pcs Slide Rail M4*45mm Screw Cover...
- Page 6 1. Attach fitting and Slide Rail to Middle Panel (2) two sides, then attach Middle Panel (2) to the Bottom Panel (1). 180° Ø6*30mm Dowel Slide Rail M3*10mm Screw M4*45mm Screw 4pcs 4pcs 4pcs 12pcs 2. Attach Back Panel (4) to the Frame. M4*35mm Screw Ø6*30mm Dowel P-6-11...
- Page 7 3. Attach M4*35mm Screws to Back Panel (4). M4*35mm Screw 2pcs 4. Attach fitting and Slide Rail to Legs (6,7). M6*35mm Slide Rail M3*10mm Screw Cam Lock Screw 6pcs 12pcs 2pcs P-7-11...
- Page 8 5. Attach the Right Leg (7) to the Frame of back and Back Support Bar (5). Ø6*30mm Dowel M4*45mm Screw Ø15*9mm Cam Lock 6. Attached the Left Leg (6) to the Frame of back, and attach the Wall Brackets to the Legs (6,7).
- Page 9 7. Attach Cam Lock Screw to Top Panel (8). M6*35mm Cam Lock Screw 13pcs 8. Attach Top Panel (8) to the Frame. Ø6*30mm Dowel Ø15*9mm Cam Lock P-9-11...
- Page 10 9. Assemble the drawer by following the steps shown in the illustration below. M4*35mm Screw Slide Rail M3*10mm Screw 6pcs 18pcs 12pcs 10. Align and attach the handle to the drawer front (9,10,11), then secure the drawer front to the frame. M6*35mm Cover M4*20mm Bolt...
- Page 11 11. Fix the wall bracket to the wall by drilling holes, inserting wall anchors, and securing it with screws. Slide the Drawers into the Frame. M4*35mm Screw Wall Anchor 2pcs P-11-11...
